- Page 1 Instruction Manual...
-
Page 3: Table Of Contents
Contents Safety Information Page 4 Visual Guide Page 5 Installing iButton Reader Panel Page 6 Installing Recoilers Page 7 Setting up the i3 Alarm Unit Page 9 Calibration Page 9 Attaching MultiSensors Page 12 Arming the alarm Page 14 Resetting the alarm after activation Page 15 Adding User iButton Keys Page 16... -
Page 4: Safety Information
Safety Information · Use the power supply and lead supplied for this product. · Use correct fuse. · Do not remove cover. · If you use this product in a manner other than that specified, the safety of this product may be impaired. ·... -
Page 5: Visual Guide
Visual Guide i3 Livelink Alarm Unit Ventilation Holes Not used DIP Switches Mains power socket RS232 and Aux Used to connect i3 Livelink to Live InfoCentre Ventilation Holes iButton earth connector iButton Reader Socket Alarm Ports iButton Reader Panel iButton Reader Display iButton Earth Lead www.stacey-europe.com... -
Page 6: Installing Ibutton Reader Panel
These are accessed by lifting the flaps on either side of the reader face. www.stacey-europe.com > Remove the backing from the flaps to expose the adhesive. > Stick the flaps to the backing plate to cover the fixing screws. Hold the flaps in place for a few seconds to allow the adhesive to set. -
Page 7: Installing Recoilers
Installing Recoilers If using an alternative Display Option (e.g LivePost or Cable Cartridge) follow the separate installation instructions as supplied with the Display Option, and move on to the next section of this manual. Ø 22mm > Drill a hole 22mm diameter where the Recoiler and Cradle are to be positioned >... - Page 8 Installing Recoilers > Thread the cable through the Cradle, and align Cradle with hole and engage the peg of the Cradle into the pilot hole. > Reassemble two halves of Recoiler insert over the Recoiler cable so that the cable goes through the centre of the completed insert.
-
Page 9: Setting Up The I3 Alarm Unit
> Position the switches on the DIP switch as follows: 1,2,3,4 in the down position 5,6 in the up position > Press and hold the Program button on the iButton Reader panel. At the same time turn on the mains power. www.stacey-europe.com... - Page 10 > The unit will chirp 5 times when the power is connected. When the chirps have sounded, release the Program button. > The iButton Reader display will now show E. www.stacey-europe.com > Disconnect the power > Position all of the DIP switches in the up position.
- Page 11 Setting up the i3 Alarm Unit > If using a Charging Interface, install following the separate instructions supplied with the item. > Connect the static leads of the Recoilers (alarm connection cable if using Cradle Cartridge or Charging Interface) to the alarm ports on the unit.
-
Page 12: Attaching Multisensors
Attaching MultiSensors BEFORE USING THE MULTISENSOR, FULLY CHARGE THE HANDSET USING THE MANUFACTURERS’ CHARGER > Attach handset specific HotSwap Charge Lead to the mini USB socket at the end of the MultiSensor. Move the HotSwap Charge Lead from side to side whilst inserting to ensure it is fully engaged. >... - Page 13 Attaching MultiSensors > Remove the shaded portion of Tag from the RJ12 Plug on the dynamic cable. > Connect the RJ12 plug to the RJ12 Socket on the MultiSensor > Place locking plate onto rear of MultiSensor and use the security screw and screwdriver to secure locking plate.
-
Page 14: Arming The Alarm
> Press the Program button. This starts the Program Cycle. The system checks all 8 ports and will display the port numbers 1-8 briefly. www.stacey-europe.com > When P is visible on the display, the cycle is complete. Touch the Black User Key onto the iButton reader to arm the alarm. -
Page 15: Resetting The Alarm After Activation
> Note the number being displayed on the iButton Reader. This number identifies the handset that triggered the alarm. www.stacey-europe.com When the system is in program mode all handsets are unprotected by the alarm. Staff should be alert to any person(s) near the display once the above action has commenced. -
Page 16: Adding User Ibutton Keys
> Touch the red master key onto the iButton Reader until the reader gives two short beeps every two seconds. www.stacey-europe.com > Touch black user key you wish to program onto reader. # If the beeps stop then the key is programmed # If the reader gives a prolonged beep then the key has already been programmed. -
Page 17: Removing User Ibutton Keys
Deleted keys can be re-added at a later date following the instructions on the previous page. > Touch the red master key onto the iButton Reader. www.stacey-europe.com > After a few seconds, touch the red master key onto the iButton Reader again. The reader will give a continuous beep. -
Page 18: Remerchandising
> Touch the Black User Key onto the iButton reader. This will put the system into program mode. When in program mode the alarm will make a beep at regular intervals. www.stacey-europe.com When the system is in program mode all handsets are unprotected by the alarm. Staff should be alert to any person(s) near the display once the above action has commenced. -
Page 19: Removing Multisensors
Removing MultiSensors > Disarm the alarm. > Use the security screwdriver to remove the security screw and locking plate. > Use a small screwdriver (or similar implement) to release the locking tab on the RJ12 connector > Remove the Charge Lead from the handset. >... -
Page 20: Fault Finding
Daily Maintenance Checks To ensure the minimum number of false alarms check the following daily: • All connections into the i3 Livelink alarm unit are good • Recoilers are connected firmly into the MultiSensors • HotSwap Charge Leads are firmly connected into the MultiSensor and the product... -
Page 21: Ibutton Reader Display Messages
Press and hold Prog. button Program mode – i3 Livelink is in to start program cycle. When Beep every 3 seconds Program mode completed, touch black user key onto reader Program complete –... -
Page 22: Technical Specifications
76mm (w) x 46mm(h) x 30mm(d) (Aperture cut out - 57mm(w) x 42mm(h)) i3 Livelink Instruction Manual v2 - January 2011 © Stacey Europe Ltd 2011 i3 Livelink is a trademark of Stacey Europe Ltd iButton is a trademark of Dallas Semiconductor... - Page 23 This page has been left blank for your notes:...
