Professional Karaoke Mixing Station Quick Start Owner’s Manual BOX CONTENTS Manual de inicio rápido del usuario CONTENIDO DE LA CAJA Schnellbedienungsanleitung BOX CONTENTS Manuale Rapido di Utilizzazione CONTENUTO DELLA CONFEZIONE Guide d’utilisation simplifié CONTENU DE LA BOÎTE KMX02 CD MIXING STATION •...
Make sure all items listed on the front of this guide are included in the box. READ SAFETY INSTRUCTION BOOKLET BEFORE USING THE PRODUCT. Study this setup diagram. Place mix station in an appropriate position for operation. Make sure all devices are turned off and all faders and gain knobs are set to “zero”...
1. Channel Inputs: Unbalanced RCA jacks for connecting external sources. The Phono/Line input is selected using the toggle switch on the front panel. Turntables, HiFi VCRs, cassette and reel- to-reel tape decks, DAT machines, CD players, laser discs, tuners, even synthesizers or other mixing consoles can be connected using these jacks.
DJ Mic 1: This section has the gain and tone controls for the ¼”/XLR combination mic input. Mic 2: This section has the gain and tone controls for Mic 2 Mic 3: This section has the gain and tone controls for Mic 3 Mic 2&3 Echo: This knob controls the echo effect amount on microphones 2 and 3.
OPEN/CLOSE (Disc Tray Open/Close) - Press to load or eject the disc. Each press will open or close the disc tray on the transport. NOTE: Tray will not open unless the disc has been paused. Tray will automatically close after 30 seconds. TIME (Time Button) - Switches the time display between elapsed playing time and remaining time on the track...
CUE - Pressing the CUE button during play provides a return to the position at which play was started. If PAUSE is used before CUE, that will become the cue point. Alternately pressing the PLAY button and the CUE button allows the CD to be played from the same position any number of times.
Page 7
PLAY / PAUSE & CUE OPERATIONS PLAY & CUE Press "PLAY/PAUSE" Press "CUE" return to to start music last starting point Play Interval Position on Disc Back Cue Operation Pressing the “PLAY/PAUSE” button starts the disc. Pressing the “CUE” button will reset the disc to the last place where the disc was started.
Match the tempo by monitoring the music of both PLAYER 1 and PLAYER 2 by ear and adjusting the pitch. When the tempo of the music of the selected CD player is slow compared to the tempo of the other player, move the slider to the ( + ) side and match the tempo. When faster, move the pitch slider to the ( - ) side.
Page 9
EXAMPLE OF MIXING USING BOTH PLAYERS OF YOUR CD PLAYER While playing a disc on PLAYER 1, load a disc into PLAYER 2 and select your next track, match its pitch to the track playing on PLAYER1 and when you are ready use the crossfader on your mixer to fade from PLAYER 1 to PLAYER 2.
Page 10
INSTALACIÓN RÁPIDA (ESPAÑOL) Asegúrese de que todos los artículos incluidos al inicio de este manual están incluidos en la caja. LEA EL FOLLETO DE INSTRUCCIONES DE SEGURIDAD ANTES DE UTILIZAR EL PRODUCTO. Estudie este diagrama de instalación. Coloque la estación de mezclas en una posición adecuada para su funcionamiento.
Entradas de canal: Jacks RCA no balanceados para la conexión de fuentes externas. La salida de Phono/Línea es seleccionada utilizando el interruptor de palanca del panel delantero. Giradiscos, reproductores de video de alta fidelidad (HiFi), casetes y unidades de cinta magnética reel-to-reel, máquinas DAT (Digital Audio Tape), reproductores de CD, discos láser, sintonizadores e incluso sintetizadores u otros instrumentos pueden ser conectados utilizando estos jacks.
Page 12
LAS CARACTERÍSTICAS DEL PANEL FRONTAL 1. DJ Mic 1: Esta sección tiene los controles del aumento y del tono para la combinación mic de 6.3mm/XLR entrado. 2. Mic 2: Esta sección tiene los controles del aumento y del tono para Mic 2 3.
Page 13
ABRIR/CERRAR (Bandeja de disco Abrir/Cerrar) – Púlselo para introducir o expulsar el disco. Cada vez que lo pulse se abrirá o cerrará la bandeja del disco en la unidad. NOTA: La bandeja no se abrirá a menos que el disco haya sido detenido. La bandeja se cerrará...
Page 14
PLAY: Está activo si la unidad está reproduciendo un CD en ese momento. PAUSE: Está activo si la unidad está en pausa. CUE: Parpadea si la unidad está determinando un punto cue. Se ilumina de forma continua si la unidad está detenida en un punto cue.
Page 15
MODIFICACIÓN DEL PUNTO CUE Ajuste el punto "CUE" con la rueda de avance lento (jog wheel). Pulse "PLAY/PLAUSE" para que comience la m úsica Si la rueda interna se gira cuando se establece un punto cue, podrá hallarse un nuevo punto cue. El reproductor de CD reproducirá...
Page 16
Una vez haya igualado los BPM, ajuste el pitch provisionalmente como se muestra a continuación: Cuando el reproductor 2 esté adelantado, gire la rueda de avance lento (jog wheel) en el sentido contrario a las agujas del reloj El pitch cambia de forma automática a medida que se gira la rueda de avance lento. Cuanto más rápido gire la rueda, más cambiará.
Page 17
KMX02 SCHNELLAUFBAU (DEUTSCH) Versichern Sie sich, daß alle auf der Vorderseite dieser Anleitung aufgeführten Gegenstände in der Schachtel enthalten sind. LESEN SIE DIE SICHERHEITSHINWEISE, BEVOR SIE DAS PRODUKT IN BETRIEB NEHMEN. Sehen Sie sich dieses Aufbaudiagramm genau an. Stellen Sie das CDMIX-Bedienpult an eine für den Betrieb geeignete Stelle.
Kanalanschlüsse: Unbalancierte RCA- Buchsen zum Anschluss von externen Quellen. Der Phono/Line-Anschluss wird über den Kippschalter an der Vorderseite des Gerätes selektiert. Plattenspieler, HiFi VCRs, Kassetten- und Tonbanddecks, DAT- Maschinen, CD-Spieler, Laser Discs, Tuner, sogar Synthesizer oder andere Mix- Bedienpulte können über diese Buchsen angeschlossen werden.
Page 19
1. DJ Mikrofon 1: Dieser Bereich hat einen 6.3 mm Klinken/XLR Kombinations Stecker mit Gainregelung und Klangregelung. 2. Mikrofon 2: Dieser Bereich hat einen Gainregler und eine Klangregler. 3. Mikrofon 3: Dieser Bereich hat einen Gainregler und eine Klangregler. 4. Mikro 2 und 3 Echo: Dieser Regler kontolliert das Echo für das Mikrofon 2 und 3.
Page 20
AUF/ZU (Disc-Einlegevorrichtung Auf/Zu) – Drücken Sie hier, um die Disc einzulegen oder herauszunehmen. Jedes Betätigen wird die Einlegevorrichtung auf der Schiene öffnen oder schliessen. HINWEIS: Die Einlegevorrichtung öffnet nur dann, wenn die CD pausiert ist. Die Einlegevorrichtung schliesst nach 30 Sekunden automatisch.
Page 21
PLAY: Aktiviert, während das Gerät eine CD abspielt. PAUSE: Aktiviert, wenn das Gerät pausiert. CUE: Blinkt, wenn das Gerät einen Cue-Punkt setzt. Leuchtet ununterbrochen, wenn das Gerät an einem Cue-Punkt pausiert. PROGRAM: Wird verwendet, um die Titelfolge, welches das Gerät automatisch abspielen soll, vorzuprogrammieren.
Page 22
PLAY/PAUSE & CUE-FUNKTIONEN: PLAY & CUE: Drücken Sie "PLAY/PAUSE", Drücken Sie "CUE", um zum letzten um Musik abzuspielen. Anfangspunkt zurückzukehren Position auf Disc Abspielintervall Rück-Cue-Funktion Ein Drücken der “PLAY/PAUSE”-Taste startet die Disc. Wird die “CUE”-Taste gedrückt, wird die Disc zum letzten Anfangspunkt zurückgesetzt.
Page 23
VERWENDUNG DER TPM-ANZEIGEFUNKTION Drücken Sie die TPM-Taste, um die TPM-Funktion in der Anzeige auf der Seite jenes CD-Spielers, welchen Sie einstellen möchten, auszuwählen. Tippen Sie die Zählertaste im Takt der Musik an. Die TPM-Anzahl erscheint in der Anzeige. Je öfter Sie antippen, umso genauer wird diese Anzahl sein. Wenn Sie den Tonlagen- Schieberegler einstellen, wird sich diese Anzahl um einen entsprechenden Prozentsatz ändern.
Page 24
MONTAGGIO RAPIDO KMX02 (ITALIANO) Verificare che tutti gli elementi elencati sul frontespizio di questo manuale siano inclusi nella confezione. PRIMA DI UTILIZZARE IL PRODOTTO LEGGERE IL LIBRETTO DELLE ISTRUZIONI DI SICUREZZA. Esaminare attentamente lo schema di montaggio. Posizionare la console CDMIX in modo adeguato all’operazione.
Ingressi Canale: Jack RCA non bilanciati per il collegamento di sorgenti esterne. L’ingresso Phono/Linea viene selezionato utilizzando il commutatore situato sul pannello anteriore. Utilizzando questi jack è possibile collegare giradischi, VCR HiFi, macchine a cassette e reel-to- reel, macchine DAT, lettori CD, laser disc, tuner, e perfino sintetizzatori o altre console di missaggio.
Page 26
1. DJ Mic 1: Questa sezione ha i comandi di tono e di guadagno per la combinazione 6.3mm/XLR ingresso microfono. 2. Mic 2: Questa sezione ha i comandi di tono e di guadagno per Mic 2 3. Mic 3: Questa sezione ha i comandi di tono e di guadagno per Mic 3 4.
Page 27
OPEN/CLOSE (Apertura/Chiusura del Vassoio del Disco) – Va premuto per caricare o estrarre il disco. Ciascuna pressione aprirà o chiuderà il vassoio. NOTA: Se il disco non è stato messo in pausa il vassoio non si aprirà. Il vassoio si chiuderà automaticamente dopo 30 secondi.
Page 28
PLAY: Ativo quando l’apparecchio riproduce un CD. PAUSE: Attivo quando l’apparecchio è in pausa. CUE: Lampeggia quando l’apparecchio sta impostando un punto cue. È acceso in maniera fissa in pausa e al punto cue. PROGRAM: Usato per pre-programmare l’ordine di riproduzione automatica delle tracce.
Page 29
PLAY e CUE Premere "PLAY/PAUSE" per avviare la musica Intervallo di Riproduzione Premendo il tasto “PLAY/PAUSE” il disco viene avviato. La pressione del tasto “CUE” imposterà il disco sull’ultima posizione in cui era stato avviato. Questo viene chiamato punto cue. Premendo i tasti “PLAY/PAUSE” e “CUE” in maniera alternata, il disco può tornare ad essere avviato dal punto cue quante volte si vuole.
Page 30
USO DEL DISPLAY BPM Premere il tasto BPM per selezionare la funzione BPM a display dal lato del lettore CD che si desidera impostare. Battere il tasto Counter al ritmo della musica. A display apparirà il numero di BPM. Più volte si batte, più il numero sarà preciso. Quando viene regolato il cursore del pitch il numero a display varierà...
Page 31
GUIDE D’INSTALLATION SIMPLIFIÉE Assurez-vous que tous les articles énumérés sur la page couverture de ce guide sont inclus dans la boîte. LIRE LE LIVRET DES CONSIGNES DE SÉCURITÉ AVANT D’UTILISER LE PRODUIT. Examinez bien le schéma d’installation. Placer la station de mixage CDMIX dans une position appropriée pour l’utilisation.
Entrées canaux : Des entrées RCA asymétriques pour brancher des sources externes. L’entrée Phono/Line est sélectionnée en activant l’interrupteur sur le panneau avant. Tourne- disques, magnétoscopes à vidéocassette HIFI, magnétophones à bobines, appareils audionumériques, lecteurs CD, disques lasers, syntoniseurs, même des synthétiseurs ou autres consoleS de mixage peuvent être connectés à...
1. DJ Mic 1: Cette section a les commandes de gain et de tonalité pour la combinaison mic de 6.3mm/XLR entré. 2. Mic 2: Cette section a les commandes de gain et de tonalité pour Mic 2 3. Mic 3: Cette section a les commandes de gain et de tonalité...
Page 34
OPEN/CLOSE (Ouvrir/fermer compartiment à disque) - Appuyez pour insérer ou éjecter un disque. Chaque fois que vous appuyez sur cette touche, le plateau s’ouvre ou se ferme. NOTE : Le plateau ne s’ouvre que si le disque est en mode pause.
Page 35
PLAY : Activé lorsque le lecteur est en mode lecture. PAUSE : Activé lorsque le lecteur est en mode pausé. CUE : Clignote lorsque le lecteur programme un point de référence. Allumé lorsque le lecteur est en mode pause au point de référence. PROGRAM : Activé...
Page 36
FONCTIONS DE LECTURE/PAUSE ET DE PRÉ-ÉCOUTE LECTURE ET PRÉ-ÉCOUTE Appuyez sur la touche PLAY/PAUSE pour commencer la lecture du disque. Jouez l'intervalle Fonction lecture de recherche inversée Appuyez sur la touche PLAY/PAUSE pour commencer la lecture du disque. Appuyer sur la touche CUE renvoie la lecture du disque au dernier point de départ.
Page 37
UTILISATION DE LA FONCTION D’AFFICHAGE DU BPM Appuyez sur la touche BPM pour sélectionner la fonction BPM sur l’afficheur sur le lecteur que vous désirez programmer. Tapez la touche COUNTER au rythme de la musique. Le nombre de BPM devrait apparaître sur l’afficheur. Plus vous tapez souvent, plus le nombre sera précis. Lorsque vous ajustez l’atténuateur de tonalité, le nombre change d’un pourcentage égal.
Specifications: Model KMX02A, Dual front loading CD player with mixer. 2. POWER DC12V 3.0A 3. DIMENSION 445 (W) x 258 (D) x156 (H)mm 4. WEIGHT 5.4 Kgs 5. FEATURES: (1) 3 band EQ for master output. (2) Super wide viewing angle display. (3) Power on/off muting.
