Page 1
Operating Manual Waffl e Makers *308.070 (12-40701) *308.071 (12-40702) 308070-71 en ma 2012-07...
Page 2
INDEX Technical data ................................................. Installation ..................................................Mounting ..................................................Before fi rst use ............................................... Function check ............................................... Maintenance ................................................Instructions for the user ..........................................Operating instructions ..........................................Safety at work ................................................Cleaning .................................................... Faults - repairs ................................................ For your safety ..............................................General features ..............................................
TECHNICAL DATA Waffl e machines - cast iron plates Ice Waffl e Iron art.-no. 1 2-40710DT 230 V / 2,2 kW Waffl e Iron Hearts on a Stick art.-no. 1 2-40711DT 230 V / 2,2 kW Lorraine Waffl e Iron on a Stick art.-no.
If the unit has to be set-up close to walls, partition panels, kitchen cabinets, decorative edgings, etc. you have to make sure that these have not been made from infl ammable material. Otherwise they have to be insulated with a heat-resistant and non-infl ammable covering. Please adhere to the fi re prevention regulations.
OPERATING INSTRUCTIONS The baking plates or cast plates become very hot during Operation. Use the unit only for the explicit purposes, i.e. for baking and cooking cake mixtures (with wheat fl our, potato fl our or wholemeal fl our). We strictly advise against inappropriate use. Do not use the baking plate for heating up pots or pans.
Page 6
THERE IS NO GUARANTEE ON THE COATING! Operating knobs/Temperature setting: The desired temperature of the baking plates is set by the regulators. By turning the knob the pilot light will go on which means that the unit is switched on. REMEMBER: the pilot light goes on - the unit is being heated...
Page 7
FAULTS - REPAIRS Thermostat faults: If the control lamp remains on. the regulator might be defect. In this case the unit will be heated con- tinuously for a period longer than 30 minutes. Heating element faults: The pilot light is switched on for more than 30 minutes, but the unit does not become hot. In these two cases, please disconnect the unit from the power supply/pull out the plug.
