    MANUAL NAVICO NAIS-300 Class B Transceiver English...

  • Page 2

    © 2007 Navico AS The technical data, information and illustrations contained in this publication were to the best of our knowledge correct at the time of going to print. We reserve the right to change specifications, equipment, installation and maintenance instructions without notice as part of our policy of continuous development and improvement.

  • Page 3: Table Of Contents

    Contents 1 Introduction 1.1 General overview 1. SimNet/NMEA000 2 Installation .1 General . Mounting . Cabling .4 SimNet/NMEA000 cable SimNet (00-N model only) NMEA000 (00-L model only) .5 NMEA018-HS (RS) .6 NMEA018-HS (RS485) .7 Transmit disable switch .8 GPS antenna .9 VHF antenna 3 Configuration .1 General...

  • Page 4: Table Of Contents

    4. Enable/disable switch (Silent Mode) 5 Appendix 5.1 Maintenance 5. Troubleshooting 5. Accessories 5.4 Product specifications 5.5 Dimensions 5.6 Service and warranty 5.7 Declaration of Conformity (EU) 4 Contents...

  • Page 5: Introduction, General Overview

    1 Introduction 1.1 General overview The NAIS-00 is a Class B Transponder that’s purpose is to transmit the position and other information about your vessel, to other AIS equipped vessels. It is housed in a rugged waterproof enclosure to withstand the rigors of the marine environment.

  • Page 6

    1.2 SimNet/NMEA2000 SimNet is Navico’s proprietary high speed data bus network compatible with NMEA000. It provides intelligent sharing of data and control information between a wide range of marine electronics and instruments. 6 Introduction...

  • Page 7: Installation, General, Mounting

    2 Installation 2.1 General The NAIS-00 is designed to be mounted on a flat surface somewhere out of sight, but easily accessible. However, to determine the best possible location, you need to consider how and where, you are going to run the cabling from the sides of the unit.

  • Page 8: Cabling

    2.3 Cabling Once you have secured your NAIS-00 to a flat surface, you will need to connect the power, SimNet/NMEA000 and RS cables supplied with the unit. The RS485 cable and switch are not supplied, but would be fitted in the same manner.

  • Page 9

    Choose the nipples directly above the parts of the connector you want to wire into and cut off the top section to the required diameter. Pass the power and RS cables through the cradle and then through the hole in the respective nipple. Bare the ends of the cables and wire into the correct section of the connector.

  • Page 10: Transmit Disable Switch, Gps Antenna

    NMEA2000 (300-L model only) With the supplied cable connected to the NAIS-00, connect the other end into the supplied T-connector, then connect this into the vessels NMEA000 network. 2.5 NMEA0183-HS ( RS232 supplied This data cable is used to connect the NAIS-00 to a PC or laptop in order to configure it, and for AIS enabled PC chartplotter applications.

  • Page 11: Vhf Antenna

      The cable can be routed in the molding to drop down directly underneath, or by breaking out the thin traps, the cable can be routed out of the side of the antenna. Alternatively, the antenna may be fixed on a standard 1” threaded mounting pole (Not supplied).

  • Page 12

    The most important factor in the performance of any AIS transceiver will be the quality and positioning of the antenna. As the range of VHF signals are governed by line of sight, the antenna should be placed as high as possible, while remaining clear of any metallic objects.

  • Page 13

    The antenna cable should terminate in a standard marine PL59 plug fitting. Connect the antenna plug to the socket on the side of the unit and screw the retaining collar down. Figure ..   To avoid possible water damage to the transceiver, it is recommended that all cables are looped to provide a drip path.

  • Page 14

    14 Installation...

  • Page 15: Configuration, General, Connecting To A Computer

    3 Configuration 3.1 General Before the NAIS-00 can become fully functional, it will be necessary to load the following information about your vessel into the unit: • Vessels Name • Call Sign • MMSI Number • Vessels Dimensions • Vessel Type In order to enter this information, you will need to connect your NAIS-00 to your PC or laptop through the supplied RS cable.

  • Page 16

    For security reasons the MMSI of the vessel cannot be changed once programmed. Do not programme the MMSI unless you are certain you have the correct information. Please check the number entered carefully. If the MMSI programmed is incorrect the AIS transponder will need to be returned to the supplier for factory reset.

  • Page 17: Operation, General, Indicators, Biit (built In Integrity Test)

    4 Operation 4.1 General The NAIS-00 has a limited user interface, consisting of a transmit enable/disable switch, (not supplied), and four indicators on the top of the unit, they are: • PWR [Green] - Power/GPS Lock Status/Silent Mode • BIIT [Red] - Built In Integrity Test •...

  • Page 18: Enable/disable Switch (silent Mode)

    6 flashes - noise threshold exceeded 7 flashes - voltage supply fault The “BIIT” message will remain there until the fault is cleared by the NAIS-00 circuitry, or the unit has been repaired. After the initial five seconds the LED will then go out. It will light for one second every time the unit transmits its AIS data.

  • Page 19: Appendix, Maintenance, Troubleshooting, Accessories

    5 Appendix 5.1 Maintenance Periodically check that the cables are secure and that the connectors have not worked their way loose. 5.2 Troubleshooting These simple checks should be carried out before seeking technical assistance and may save time and expense. General Symptom Unit will not switch on Faulty connector to power...

  • Page 20: Product Specifications

    5.4 Product specifications AIS Type Class B for use on non-SOLAS craft VHF Receiver Receiver type Sensitivity Transmit power Type Approval Meets GPS Receiver Receiver type IEC60945 Power Voltage Current SimNet/NMEA000 Connectors VHF Antenna GPS Antenna Compass mounting Safe distance...

  • Page 21

    NMEA2000 AIS PGNs 1908 Class A Position Report 1909 AClass B Position Report 19040 Class B Extended Position Report 1979 DGNSS Broadcast Binary Message 1979 UTC and Date Report 19794 Class A Static and Voyage Related Data 19795 Addressed Binary Message 19796 Acknowledge 19797...

  • Page 22

    5.5 Dimensions 210mm (8.27in) 167.5mm (6.6in) Figure 5.1 - NAIS-300 dimensions Figure 5.2 - GPS Antenna dimensions 5.6 Service and warranty If it is necessary to have a unit repaired, please contact your local authorized dealer. For worldwide warranty details and a list of authorised Navico agents please refer to the Warranty Card supplied with this unit.

  • Page 23

    5.7 Declaration of Conformity (EU) English Hereby, Navico AS declares that this NAIS-300 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Finnish Navico AS vakuuttaa täten että NAIS-300 tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. Dutch Hierbij verklaart Navico AS dat het toestel NAIS-300 in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/ French Par la présente, Navico AS déclare que ce NAIS-300 est conforme aux exigences essentielles et aux autres dispositions de la directive 1999/5/CE qui lui sont applicables.

  • Page 24
