Service Manual
Refrigerator
Model: FR-454
(For Australia)
DAEWOO ELECTRONICS Corp.
http://svc.dwe.co.kr
S/M No. : FR45400000
Feb. 2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-454 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daewoo FR-454

  • Page 1 S/M No. : FR45400000 Service Manual Refrigerator Model: FR-454 (For Australia) DAEWOO ELECTRONICS Corp. http://svc.dwe.co.kr Feb. 2003...
  • Page 2: Main Components

    1. SPECIFICATION FR-454 ◈ Classification Contents FR-454 Electric Freezing room Capacity(L) Rfrigerating room Total Dimensions Width(W) (mm) Depth(D) Height(H) 1741 Net weight 88kg Cooling System Fan Cooling Convection Cooling and Dfrost System Air Forced Convection Dfrost System Fin evaporator Forced...
  • Page 3: Name Of Parts

    3. NAME OF PARTS...
  • Page 4: Refrigerant Cycle Diagram

    4. REFRIGERANT CYCLE DIAGRAM...
  • Page 5: Machine Room View And Part List

    5. MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME COMPRESSOR DRYER AS BASE COMP CABLE TIE BOLT COMP FIX SEALING DRYER ABSORBER COMP PIPE CONN HOT FIX COMP WASH PIPE CONN SUC CASTER *B ABSORBER PIPE SHAFT CASTER CORD POWER AS CASE VAPORI BAND RELAY...
  • Page 6: Methods Of Exchanging Main Parts

    6. METHODS OF EXCHANGING MAIN PARTS (1) Freezing room louver 1) Unscrew, remove the F-louver by pulling forward with inserting screwdriver into the hole of F louver. 2) Assemble it by pressing triangle shape (▲) by hand. (2) Multi-Duct 1) Disassemble the R-Window by inserting a finger in the lower part and pulling forward while pushing upward slightly.
  • Page 7 Methods of exchanging main parts 4) The specific part of the multi duct is shown below. --- Check after repair --- 1. Put all the parts into the right places and attach the seal and tape to their original positions. 2.
  • Page 8 Methods of exchanging main parts Soldering (5) Freezer Sensor F-louver insulator Heat tube 1) Remove the aluminum tape from louver insulator. Take off the freezer sensor. 2) Replacement procedure of the freezer sensor. 1.Cut off the lead wire of old sensor and insert the heat tube into a new sensor's lead wire.
  • Page 9 Methods of exchanging main parts Evaporator fastening screw 3) Move the entire eveporator upward the pipe center to the arrow's direction. (Do not crumble the part A of the accumulator during the process.) 4) Cut the both ends of glass tube heater tube heater lead wires and insulate and Raise upward seal lead tip remaining in refrigerator...
  • Page 10 7) Place the glass tube heater lead wire AL tape Frontside Lead wire shown as below and fasten the shaded area with type. 8) Fin insert the lead wire connection terminals. (Same colored lead wires) 9) Set the evaporator on normal position and secure the fastening screws.
  • Page 11 7. EXPLODE VIEW AND PARTS LIST 1. Expoloded views AUSTRALIA NEC (NEC, FR-454) -10-...
  • Page 12: Parts List

    2) PARTS LIST PART CODE PART NAME DESCRIPTION Q'TY REMARK ASS'Y CAB URT HCFC-141B 3012500200 GUIDE DRN 4018G54120 PIPE DRN AL T1.0 3012801000 HEATER GLAS TUBE AS 220V / 148W 3011408202 COVER HTR *T GALVANIED 3011408101 COVER HTR *U GALVANIED 3017044704 EVAPORATOR FIN AS NO ACCUM 400EL21214 FUSE TEMP AS...
  • Page 13 PART CODE PART NAME DESCRIPTION Q'TY REMARK 42-1 4010G26030 INSULATOR DAMP B F-PS 42-2 4010G26401 R DAMPER AS 42-3 3013304901 INSULATOR M/F DUCT F-PS 42-4 4017G31152 KNOB DAMP 42-5 3011408803 COVER M/F DUCT HIPS 3015500703 WINDOW R GPPS 3011301200 POWER CORD AS 250V 7.5A 3012400502 GRILLE 3017804700 SHELF F...
  • Page 14 *** EVAPORATOR FIN AS *** - OLD (Refrigerant : 170g) ACCUMULATOR - NEW (Refrigerant : 105g) date : 2002. 9. NONE...
