Introducing your Meridian 1 telephone

This guide introduces you to your new Meridian 1 telephone set. It provides you with a description of the controls
on your telephone, and a description of each feature that is available to you.
Your Meridian 1 Modular telephone gives you easy access to a wide range of business communication features
available with your Meridian 1 telephone system.
Parts of your telephone set
Display Module
LCD Indicators
Speaker
Handset
Release (Rls) Key
Hold Key
Message Waiting Light
Feature Keys
Microphone
Volume Bar
Main Extension Key
or Directory Number (DN) Key
Key Expansion Module
The M2006 has six feature keys; the M2008/M2008HF has eight feature keys; the M2616, shown above, has 16
feature keys and a built-in microphone.
A Display Module Option is available for the M2008/M2008HF and the M2616 models. The M2616 can also
accommodate up to two Key Expansion Modules.
