To Use The Brakes; To Attach And Operate The Front Wheels; To Adjust And Secure The Harness - Redkite push me fusion Instruction Leaflet

Slide the spindle of the rear wheels into the
axle unit (Fig.5) and push inwards until they
lock in place (Fig.6) . The wheels can easily be
removed by pressing the button (Fig.7) and
pulling the wheel out.

To use the brakes

To use the brakes, push the lever down to
engage them and lift up to release (Fig.8) .
WARNING Apply all the brakes whenever you
park the stroller.

To attach and operate the front wheels

Slide the stems on the front wheels into the
wheel holders and push up (Fig.9) . To select
fixed or swivel wheels, push the button on the
top (Fig.10) . To remove the front wheels, push
the wheel release button on the side and pull
the wheel down.

To adjust and secure the harness

Slide the waist harness (A) in to the
shoulder strap (B) and then push in to the
central buckle housing (C).
To release the buckles simply push
the button in the centre of the buckle
housing.
WARNING Always use the crotch strap in
combination with the waist belt.
A
Shoulder strap
Waist harness
B
Release button
C
Fig 5
Fig 6
Fig 8
Fig 9
Fig 10
Buckle housing
Axle unit
Brake lever
Wheel holder
Rear
wheel
Fig 7
Button
Wheel holder
Front wheel
Fixed / swivel button
Wheel release
button
