Ernitec Hawk SX Bullet
User's Manual
Ver1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hawk SX Series and is the answer not in the manual?

Questions and answers

Related Manuals for ERNITEC Hawk SX Series

Summary of Contents for ERNITEC Hawk SX Series

  • Page 1 Ernitec Hawk SX Bullet User’s Manual Ver1.5...
  • Page 2 Ernitec Hawk SX Camera Series User’s Manual Caution and Preventive Tips  Handle with care, do not drop the unit  Mount the unit in an equipment rack or place it on a solid, stable surface  Indoor use only. Do not place the unit in a humid, dusty, oily, or smoky site ...
  • Page 3 Ernitec Hawk SX Camera Series User’s Manual Important Information Before proceeding, please read and observe all instructions and warnings in this manual. Retain this manual with the original bill of sale for future reference and, if necessary, warranty service. When unpacking your unit, check for missing or damaged items. If any item is missing, or if damage is evident, DO NOT INSTALL OR OPERATE THIS PRODUCT.

  • Page 4: Table Of Contents

    Ernitec Hawk SX Camera Series User’s Manual Table of Contents Overview ..........................4 Features ........................4 Package Contents ....................... 5 Dimensions ........................6 Connectors ........................7 Camera Cabling ........................9 Connect Power ......................9 Connect Ethernet Cable....................9 Connect Alarm I/O .......................

  • Page 5: Overview

    Ernitec Hawk SX Camera Series User’s Manual Overview Supported with both H.264 and MJPEG standard, the product series not only features in superior Full HD resolution for real-time streaming at 25/30 fps, but also supplies D1 real-time streaming. With more computing power, the IP Camera could provide more flexibility for users and system managers.

  • Page 6: Package Contents

    Ernitec Hawk SX Camera Series User’s Manual Package Contents Please check the package contains the following items listed below. IR Bullet IP Camera (Cable included) Power Terminal Block (x1) M4 Inner Hex Wrench (x1) Alarm Terminal Block (x1) Plastic Screw Anchors (×3) M4 Self Tapping Screws (×3)

  • Page 7: Dimensions

    Ernitec Hawk SX Camera Series User’s Manual Dimensions The IP Camera’s dimensions are shown below. v.1.5.0912 www.ernitec.com...

  • Page 8: Connectors

    Ernitec Hawk SX Camera Series User’s Manual Connectors The diagram below shows the IP Dome Camera’s reset button and various connectors. Definition for each connector will be given as follows. All-in-one Cable Cable Definition Remarks Network (with PoE) RJ-45 connector with LED...
  • Page 9 Ernitec Hawk SX Camera Series User’s Manual Micro SD Card Slot/ Reset Button Follow the steps below to reach the Micro SD Card Slot, Reboot Button and Factory Default Button on IP Camera: Step 1: Unscrew the screw on the Camera...

  • Page 10: Camera Cabling

    Ernitec Hawk SX Camera Series User’s Manual Camera Cabling Please follow the instructions below to complete IP Camera connection. Connect Power Please refer to Section: Connectors. Alternatively, connect the Ethernet cable to the camera’s PoE port and plug the other end of the cable into a PoE switch.

  • Page 11: Installation

    Ernitec Hawk SX Camera Series User’s Manual Installation Please read the instructions provided in this chapter thoroughly before installing the IP Dome Camera. Ceiling/Wall Mounting The IR Bullet IP Camera can be installed directly on a wall or ceiling with the integrated 2-axis adjustable Bracket Mount.

  • Page 12: Lens Adjustment (Vari-Focal Lens Only)

    Ernitec Hawk SX Camera Series User’s Manual Lens Adjustment (Vari-focal Lens only) Step 1: Unscrew the screw on the Camera Housing and remove the Front Housing. Step 2: Power up the IP Camera. Please refer to Section: Connectors for more cabling installing details.

  • Page 13: System Requirements

    Ernitec Hawk SX Camera Series User’s Manual System Requirements To perform the IP Camera via web browser, please ensure your PC is in good network connection, and meet system requirements as described below. Items System Requirement ® ® 1. Intel Pentium M, 2.16 GHz or...

  • Page 14: Access Camera

    Ernitec Hawk SX Camera Series User’s Manual Access Camera For initial access to the IP Camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Device Search Software Setup Step 1: Double click on the program Device Search.exe.
  • Page 15 Ernitec Hawk SX Camera Series User’s Manual Additionally, users can change the IP Camera’s network property, either DHCP or Static IP, directly in the device finding list. Refer to the following section for changing the IP Camera’s network property. Example of Changing IP Camera’s Network Property Users can directly change an IP Camera’s network property, ex.
  • Page 16 Ernitec Hawk SX Camera Series User’s Manual The download procedure of DC Viewer software is specified as follows. Step 1: In the DC Viewer installation window, click on <Next> to start installation. Step 2: The status bar will show the installation progress. After the installation is completed, click on <Finish>...
  • Page 17 Ernitec Hawk SX Camera Series User’s Manual Motorized Lens Model Image and Focus Adjustment The image displays on the Home page when successfully accessing to the IP Camera. Adjust zoom and focus as necessary to produce a clear image. Note: Please refer to Full HD Multiple Streams IP Camera Menu Tree for more button function detail.

  • Page 18: Setup Video Resolution

    Ernitec Hawk SX Camera Series User’s Manual Setup Video Resolution Users can setup Video Resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default value of Video Resolution is as below: H.264- 1920 x 1080 (15 fps) + H.264- 1280 x 720 (30 fps)

  • Page 19: Configuration Files Export/ Import

    Ernitec Hawk SX Camera Series User’s Manual Configuration Files Export/ Import To export/ import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the IP Camera.

  • Page 20: Appendix A: Technical Specifications

    Ernitec Hawk SX Camera Series User’s Manual Appendix A: Technical Specifications Camera 2M Real time 1/2.7” Progressive CMOS Image Sensor Effective Pixels 1920(H) x 1080(V) 0.2 lux (Color) Minimum Illumination 0.02 lux (B/W) White Balance Manual / AWB / ATW Shutter Speed 1~ 1/10000 sec.
  • Page 21 Ernitec Hawk SX Camera Series User’s Manual Mechanical Working distance up to 25 m Built-in IR Wavelength 850 nm Illuminator Number of LEDs LED Indicator Power / Link / ACT Alarm 4 Pin Terminal Block Power 3 Pin Terminal Block...
  • Page 22 Ernitec Hawk SX Camera Series User’s Manual Camera 1/2.7” Progressive CMOS 1/2.5” 5M Progressive CMOS Image Sensor Effective Pixels 2048(H) x 1536(V) 2592(H) x 1944(V) 0.2 lux (Color) Minimum Illumination 0.02 lux (B/W) White Balance Manual / AWB/ ATW Shutter Speed 1~ 1/10000 sec.
  • Page 23 Ernitec Hawk SX Camera Series User’s Manual Mechanical Working distance up to 25 m Built-in IR Wavelength 850 nm Illuminator* Number of LEDs LED Indicator Power / Link / ACT Alarm 4 Pin Terminal Block Power 3 Pin Terminal Block...

  • Page 24: Appendix B: Delete The Existing Dc Viewer

    Ernitec Hawk SX Camera Series User’s Manual Appendix B: Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first remove the existing DC Viewer from the PC before accessing to the IP Camera.

  • Page 25: Appendix C: Setup Internet Security

    Ernitec Hawk SX Camera Series User’s Manual Appendix C: Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE).

  • Page 26: Appendix D: Video Resolution

    Ernitec Hawk SX Camera Series User’s Manual Appendix D: Video Resolution 2M- Quad Streams H.264 + H.264 + H.264 + H.264 / MJPEG H.264-4 / H.264-1 H.264-2 H.264-3 MJPEG 720 x 480 352 x 240 (15 fps) (30 fps) 1280 x 1024...
  • Page 27 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-4 / H.264-1 H.264-2 H.264-3 MJPEG 352 x 240 352 x 240 (30 fps) (30 fps) 720 x 480 (30 fps) 720 x 480...
  • Page 28 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 640 x 480 (15 fps) (30 fps) 352 x 240...
  • Page 29 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 720 x 480 640 x 480 (30 fps) (30 fps) 352 x 240...
  • Page 30 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 1280 x 720 (30 fps) (15 fps) 640 x 480 (30 fps) 1280 x 720...
  • Page 31 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 352 x 240 (30 fps) 640 x 480 640 x 480 (30 fps) (30 fps) 352 x 240...
  • Page 32 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 640 x 480 352 x 240 1024 x 768 (30 fps) (30 fps) (30 fps) 352 x 240...
  • Page 33 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 640 x 480 640 x 480 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps)

  • Page 34: Triple Streams

    Ernitec Hawk SX Camera Series User’s Manual 2M- Triple Streams H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (15 fps) 720 x 480 (15 fps) 1280 x 1024 (15 fps) 640 x 480 (15 fps)
  • Page 35 Ernitec Hawk SX Camera Series User’s Manual H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (30 fps) 352 x 240 (30 fps) 1024 x 768 (30 fps) 352 x 240 (30 fps) 800 x 600 (30 fps)

  • Page 36: Dual Streams

    Ernitec Hawk SX Camera Series User’s Manual 2M- Dual Streams H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT 1280 x 1024 (15 fps) 1280 x 720 (30 fps) 1024 x 768 (30 fps) 1920 x 1080 (15 fps) 800 x 600 (30 fps) √...
  • Page 37 Ernitec Hawk SX Camera Series User’s Manual MJPEG Only √ 1920 x 1080 (15 fps) √ 1280 x 1024 (30 fps) √ 1280 x 720 (30 fps) √ 1024 x 768 (30 fps) √ 800 x 600 (30 fps) √...

  • Page 38: Real Time / 3M / 5M- Quad Streams

    Ernitec Hawk SX Camera Series User’s Manual 2M Real time / 3M / 5M- Quad Streams H.264 + H.264 + H.264 + H.264 / MJPEG H.264-4 / H.264-1 H.264-2 H.264-3 MJPEG 720 x 480 352 x 240 (10 fps) (10 fps)
  • Page 39 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 352 x 240 (15 fps) 352 x 240 352 x 240 (15 fps) (15 fps) 352 x 240...
  • Page 40 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (15 fps) 1280 x 720 640 x 480 (15 fps) (15 fps) 352 x 240...
  • Page 41 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 352 x 240 352 x 240 (30 fps) (30 fps) 720 x 480 (30 fps) 800 x 600...
  • Page 42 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 1280 x 720 (30 fps) (15 fps) 640 x 480 (30 fps) 1280 x 720...
  • Page 43 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 800 x 600 (30 fps) (30 fps) 640 x 480 800 x 600 (30 fps)
  • Page 44 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 352 x 240 (30 fps) (30 fps) 720 x 480 352 x 240 1280 x 720...
  • Page 45 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 352 x 240 (30 fps) 720 x 480 (30 fps) 720 x 480 640 x 480 (30 fps)
  • Page 46 Ernitec Hawk SX Camera Series User’s Manual H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 352 x 240 (30 fps) (30 fps) 720 x 480 (30 fps) 720 x 480...
  • Page 47 Ernitec Hawk SX Camera Series User’s Manual v.1.5.0912 www.ernitec.com...

  • Page 48: Real Time / 3M / 5M- Triple Streams

    Ernitec Hawk SX Camera Series User’s Manual 2M Real time / 3M / 5M- Triple Streams H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 720 x 480 (10 fps) 720 x 480 (10 fps) 640 x 480 (10 fps)
  • Page 49 Ernitec Hawk SX Camera Series User’s Manual H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (30 fps) 1280 x 1024 (15 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 1280 x 1024 (30 fps)
  • Page 50 Ernitec Hawk SX Camera Series User’s Manual H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (30 fps) 720 x 480 (30 fps) 800 x 600 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps)

  • Page 51: Real Time / 3M / 5M- Dual Streams

    Ernitec Hawk SX Camera Series User’s Manual 2M Real time / 3M / 5M- Dual Streams H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG 720 x 480 (10 fps) 2952 x 1944 (10 fps) 640 x 480 (10 fps) 352 x 240 (10 fps) *The resolution is for 5M Model only.
  • Page 52 Ernitec Hawk SX Camera Series User’s Manual H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT √ 352 x 240 (30 fps) 352 x 240 (30 fps) 352 x 240 (30 fps) v.1.5.0912 www.ernitec.com...

  • Page 53: Real Time / 3M / 5M- Single Streams

    Ernitec Hawk SX Camera Series User’s Manual 2M Real time / 3M / 5M- Single Streams H.264 Only 2592 x 1944 (10 fps)* 2048 x 1536 (15 fps)** 1920 x 1080 (30 fps) Low Latency*** √ 1920 x 1080 (30 fps) √...
