Copyright 1996 Carrier Corporation
Product
Data
38YCB 50 Hz
38YCB Sizes 024 thru 060
The 38YCB 50 Hertz Outdoor
Sections of Split-System Heat Pumps
are designed for quiet, reliable heating
during the winter and cooling during
the summer. With a SEER up to 10.0
and COP up to 3.0, these heat pump
systems provide economy of
operation through energy
conservation when used with
components designated by
manufacturer. They recover heat for
indoor comfort from outdoor air
during the heating season and, by
automatically reversing the
refrigerant system, remove indoor
heat and excess humidity during the
cooling season.

FEATURES/BENEFITS

Electrical Range — Units are offered
in single phase 220–240v. Three-
phase units are available in sizes 036,
048, and 060 in 400v.
Size Range — The 38YCB is
available in nominal sizes 024, 036,
048 and 060 to meet the needs of
residential and light commercial
applications.
Compressor — Designed
specifically for heat pump duty, with
energy efficiency during heating and
cooling operation. Each compressor is
hermetically sealed against
contamination to assure long life and
dependable performance, internally
sprung (units with reciprocating
compressor) and externally mounted
on rubber isolators for quiet operation.
Continuous compressor operation is
approved down to –30 ° F (–34.4 ° C)
in the heating mode, and down to
55 ° F (12.8 ° C) in the cooling mode.
Form 38YCB-C2PD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 38YCB and is the answer not in the manual?

Questions and answers

Related Manuals for Carrier 38YCB

Summary of Contents for Carrier 38YCB

  • Page 1 220–240v. Three- phase units are available in sizes 036, 048, and 060 in 400v. Size Range — The 38YCB is available in nominal sizes 024, 036, 048 and 060 to meet the needs of residential and light commercial applications.

  • Page 2: Model Number Nomenclature

    The 38YCB has sweat Discharge Silencer — Minimizes low field connections. frequency sound and pressure All screws on cabinet exterior are...

  • Page 3: Physical Data

    Physical data UNIT SIZE SERIES 70, 90 70, 90, 92 90, 92 OPERATING WT (Lb/Kg) 145 / 65.9 222 / 100.9 225 / 102 261 / 118.6 COMPRESSOR Manufacturer & Type Copeland & Recip Copeland & Recip Millennium & Scroll Millennium &Scroll REFRIGERANT Control...
  • Page 4 Accessories ORDERING NUMBER DESCRIPTION KAAWS0101AAA Winter Start Control — All Sizes KAATD0101TDR Time-Delay Relay — All Sizes KAAFT0101AAA Evaporator Freeze Thermostat† — All Sizes KHAIR0101AAA Isolation Relay† — All Sizes KSACY0101AAA Cycle Protector — Sizes 024, 036 Standard Cycle Protector — Sizes 036 (71), 048, 060 Compressor Start Assist (Capacitor/Relay) —...

  • Page 5: Accessory Description And Usage

    Accessory Description and Usage 1. Compressor Start Assist-Capacitor/Relay Type Start capacitor and start relay gives “hard” boost to compressor motor at each start-up. SUGGESTED USE: Installations where interconnecting tube length exceeds 50 ft (15.24m). Installations where outdoor design temperature exceeds 105 ° F (40.6 ° C). Replacement installations with hard shutoff expansion valve or liquid line solenoid on indoor coil.

  • Page 6: Electrical Data

    Electrical data MAX FUSE† MIN WIRE LENGTH LENGTH OR HACR OPER VOLTS* COMPRESSOR OUTDOOR SIZE** (Ft)‡ (m)‡ TYPE CKT UNIT V/PH 60°C/ 75°C 60°C/ 75°C 60°C/ 75°C BKR AMPS 024-70 68.0 11.5 15.8 14/14 55/39 16.7/11.9 036-70 230-1 94.0 16.5 22.2 12/12 65/47...
  • Page 7 Detailed cooling capacities* (S.I.) CONDENSER ENTERING AIR TEMPERATURES °C COIL Capacity Capacity Capacity Capacity Capacity Capacity Capacity Sys. Sys. Sys. Sys. Sys. Sys. Sys. Kw† Kw† Kw† Kw† Kw† Kw† Kw† Power Power Power Power Power Power Power Total Sens‡ Total Sens‡...
  • Page 8 Detailed cooling capacities* (S.I.) continued CONDENSER ENTERING AIR TEMPERATURES °C COIL Capacity Capacity Capacity Capacity Capacity Capacity Capacity Sys. Sys. Sys. Sys. Sys. Sys. Sys. Kw† Kw† Kw† Kw† Kw† Kw† Kw† Power Power Power Power Power Power Power Total Sens‡ Total Sens‡...
  • Page 9 Detailed cooling capacities* (English) CONDENSER ENTERING AIR TEMPERATURES °F COIL Capacity Capacity Capacity Capacity Capacity Capacity Sys. Sys. Sys. Sys. Sys. Sys. MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Power Power Power Power Power Power Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡...
  • Page 10 Detailed cooling capacities* (English) continued CONDENSER ENTERING AIR TEMPERATURES °F COIL Capacity Capacity Capacity Capacity Capacity Capacity Sys. Sys. Sys. Sys. Sys. Sys. MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† MBtuh† Power Power Power Power Power Power Total Sens‡ Total Sens‡ Total Sens‡...
  • Page 11 Heat pump heating performance (S.I.) ° OUTDOOR COIL ENTERING AIR TEMPERATURES –16 –8 INDOOR Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Power Power Power Power Power Power Power Power L/ S Total Integ† Kw* Total Integ†...
  • Page 12 Heat pump heating performance (S.I.) continued ° OUTDOOR COIL ENTERING AIR TEMPERATURES –16 –8 INDOOR Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Power Power Power Power Power Power Power Power L/ S Total Integ† Kw* Total Integ†...
  • Page 13 Heat pump heating performance (English) ° OUTDOOR COIL ENTERING AIR TEMPERATURES –3 INDOOR Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Power Power Power Power Power Power Power Power CFM Total Integ† Kw* Total Integ†...
  • Page 14 Heat pump heating performance (English) continued ° OUTDOOR COIL ENTERING AIR TEMPERATURES –3 INDOOR Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Capacity Total Power Power Power Power Power Power Power Power CFM Total Integ† Kw* Total Integ†...
  • Page 15 Certified drawing—38YCB S.I. SHIPPING ELECTRICAL UNIT WEIGHT CHARACTERISTICS 38YCB024 571.5 862.0 81.0 15.9 93.6 460.4 501.7 549.3 365.1 479.4 560.4 317.5 304.8 355.6 65.9 38YCB036 762.0 1014.4 82.6 19.1 165.1 596.9 692.2 739.8 508.0 669.9 750.9 381.0 400.1 393.7 100.9 38YCB036 762.0...
  • Page 16 BUILDING HEAT LOSS, KW UNIT INTEGRATED HEATING CAPACITY, KW A94370...
  • Page 17 BUILDING HEAT LOSS, 1000 BTU/HR UNIT INTEGRATED HEATING CAPACITY, 1000 BTU/HR A94369...

  • Page 18: Guide Specifications

    Guide specifications Air-Cooled, Split-System Heat Pump 38YCB 2 To 5 Tons Nominal (7 To 17.5 Kw) GENERAL Condenser fan motors will be totally enclosed, 1-phase type with class B insulation and permanently lubricated bearings. System Description Shafts will be corrosion resistant.
  • Page 20 Syracuse, New York 13221 6-96 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations Book Page 20 Catalog No. 013-881 Printed in U.S.A. PC 101 Form 38YCB-C2PD Replaces: 38YCB-C1PD 5a 5a...
