- Page 1 Thunderbird-E3100 Mini-ITX Motherboard Technical Manual TME-ITX-E3100-R0V8.doc Revision 0.8 / April 11 © LIPPERT Embedded Computers GmbH Hans-Thoma-Str. 11 D-68163 Mannheim http://www.lippertembedded.com/...
- Page 2 LiPPERT Embedded Computers GmbH assumes no liability for any damages incurred directly or indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the technical manual.
-
Page 3: Table Of Contents
Table of Contents Overview Introduction ..................1 Features ....................1 Block Diagram ..................2 Ordering Information ................3 Thunderbird-E3100 Models ............... 3 Cable Sets and Accessories ............... 3 Specifications ..................4 Electrical Specifications ................4 Environmental Specifications ..............4 MTBF ..................... 4 Mechanical .................... - Page 4 USB 0…3 ....................17 USB 4…5 ....................17 SATA Ports ..................... 18 Serial Ports .................... 18 COM Connector ..................18 RS485-Termination Jumpers ..............19 On Board Power Supply ................. 20 Power Connector ..................20 Real Time Clock Backup ................20 System Panel Connector ................
- Page 5 DMA Channels ..................37 Troubleshooting Appendix A, Contact Information Appendix B, Getting Help Appendix C, Further Resources Appendix D, Revision History TME-ITX-E3100-R0V8.doc Rev 0.8...
-
Page 6: Overview
The brand name for the product is defined as Thunderbird-E3100. The Mini ITX board Thunderbird-E3100 is designed for applications where a high performance x86 compatible dual core processor board is necessary. The board concept offers a lot of standard I/O interfaces. -
Page 7: Block Diagram
Block Diagram TME-ITX-E3100-R0V8.doc Rev 0.8 Page 2 of 38... -
Page 8: Ordering Information
Thunderbird-E3100 Models Order number Description 705-0010-10 Thunderbird-E3100 Mini-ITX CPU board with T9400 Intel Core 2 Processor (1.9 GHz, 6MB L2 cache, 800 MHz FSB) Operating temp. range: 0°C … +60°C 705-0010-11 Thunderbird-E3100 Mini-ITX CPU board with T7500 Intel Core 2 Processor (2.2 GHz, 4MB L2 cache, 800 MHz FSB) -
Page 9: Specifications
1.3 Specifications Electrical Specifications Supply voltage 12V ± 5% or ATX power supply +3.3V, +5V, +5VSB, +12V Rise time < 10 ms Supply voltage ripple ± 50 mV Inrush current 12 V Power supply: 3A Power consumption 705-0010-10 ATX Power supply: typical values +5VSB: 0.17A... -
Page 10: Mounting In Mini-Itx Enclosure
Caution Never create a short circuit with the components located around the mounting holes when the board is mounted on metal spacers. This can damage the board! Mounting in Mini-ITX enclosure In a Mini-ITX enclosure the board is mounted by using the 4 standard mounting holes. Only one PCI Express x 4 Slot is useable at the slot bracket. -
Page 11: Getting Started Connector Locations
2. Getting Started 2.1 Connector Locations SATA4 SATA1 SATA2 SATA0 Power Supply SATA3 SATA5 System Chassis Panel 2x USB (µDOC) Mini-PCIe PCI Express x4 Slot0 Slot1 DDR2 DIMM Sockets Ethernet Ethernet (82573) (82574) Serial Ports COM1 top with &2xUSB COM2 Bottom &2xUSB TME-ITX-E3100-R0V8.doc Rev 0.8... -
Page 12: Bottom
Bottom Backlight LVDS TME-ITX-E3100-R0V8.doc Rev 0.8 Page 7 of 38... -
Page 13: Jumper Locations
Jumper Locations Jumper Jumper-Pos. Function 1 – 2 Init CMOS – load setup def. – 1 – 2 Init CMOS NL (def.) 1 – 3 LCD Voltage Selection 3.3V (def.) 3 – 5 LCD Voltage Selection 5V 2 – 4 Backlight Voltage Selection 12V (def.) 4 –... - Page 14 JP’s X19 1 3 5 7 2 4 6 8 TME-ITX-E3100-R0V8.doc Rev 0.8 Page 9 of 38...
-
Page 15: Led Indicators
LED Indicators To facilitate problem solving, the Thunderbird-E3100 provides LED indicators for the following conditions: Name Function WWAN Status of wireless add-in card (WAN) WLAN Status of wireless add-in card (LAN) WPAN Status of wireless add-in card (PAN) Harddisk: SATA accesses... -
Page 16: Hardware Setup
If you need to load the BIOS default values, press the <Insert> key during startup. This forces the BIOS to load the factory settings from FlashPROM. The Thunderbird-E3100 can boot from CD drives, USB floppy, USB stick, harddisk, or network. Provided that any of these is connected and contains a valid operating system image, the display then shows the boot screen of your operating system. -
Page 17: Module Description Processor
3. Module Description 3.1 Processor ® Intel Core 2 Duo Processor, 1.9 GHz (T9400) … 2.2 GHz (T7500). The Penryn processor on 45-nanometer process technology is the next generation high-performance, low-power mobile processor based on the Intel® Core™ microarchitecture. Available in: ·... -
Page 18: Graphics Controller (Xgi, Volari™ Z9M Series)
A Intel® 3100 Chipset system implementation consists of: • One processor socket operating at 100/133/167/200 MHz • One Intel® 3100 Chipset • One to four DDR2-400 DIMMs (a maximum of 4 ranks are supported) • Bridge devices providing I/O subsystem connectivity •... -
Page 19: Lvds Transmitter / Connector (Optional)
LVDS Transmitter / Connector (optional) Note The LVDS and VGA port are using same timing and resolution parameters. The VGA controller does not support using both interfaces at the same time, either VGA is active (standard) or LVDS is active (optional). Therefore the LVDS port is intended to be used in special consumer applications only. -
Page 20: Display Backlight Connector (Optional)
Display Backlight Connector (optional) Connector type: Hirose DF13 8 pin header 1.25 mm Matching connector: Hirose DF13-8S-1.25C, part number 536-0007-0 00 Signal +12V Caution: Maximum current on all +12V supply pins is 1A! VCC_BL is switched Inverter Power. EN is Backlight Enable Signal with 3.3V leveling. -
Page 21: Gigabit Ethernet
3.4 Gigabit Ethernet There are two Ethernet ports available on two standard 3-port stackable ETH/USB connectors. One Ethernet by 82573V with ASF and the other by 82574IT Connector type: Amphenol G71M132611AEU Matching connector: 8P8C (RJ45) plug Signal Signal MX1+ MX1- MX2+ MX2- MX3+... -
Page 22: Usb 2.0 Ports
3.5 USB 2.0 Ports There are 6 USB 2.0 ports available on three different connectors. USB 0…3 Four USB ports from the chipset are available on two standard 3-port stackable ETH/USB connectors. Connector type: Amphenol G71M132611AEU Matching connector: 8P8C (RJ45) plug Signal Signal USB_VCC... -
Page 23: Sata Ports
3.6 SATA Ports There are six SATA ports available for the application on six SATA connectors. Connector type: SATA THT MOLEX 67800-8001 Matching connector: 7 pin Serial ATA plug Signal RS232 3.7 Serial Ports Two serial ports are located on the board. They can either work in RS232 or in RS422/RS485 mode, selectable via BIOS setting. -
Page 24: Rs485-Termination Jumpers
(e.g. RX+ and RX-, on the right picture) Additionally, positive/negative receive lines are pulled up/down with 10kW to 5V/GND in order to protect the transceivers of the Thunderbird-E3100 from over voltages. It is recommended to protect the ports of the external device in the same way! -
Page 25: On Board Power Supply
3.8 On Board Power Supply Power Connector Connector type: ATX-Power connector (X26) Matching connector: Molex Mini-Fit Jr.™ Receptacle Housing, Dual Row, UL 94V-2, 20 Circuits, 5556 series and Mini-Fit Plus HCS™ Crimp Terminal 45750 Signal Signal +3,3 V +3,3 V -12 V +3,3 V Power Supply ON... -
Page 26: System Panel Connector
3.9 System Panel Connector That connector is used by a different kind of signals. There is no standard cable adapter available. Connector type: IDC12 pin header 2.54 mm (X27) Matching connector: IDC12 pin female connector 2.54 mm Power-Button The Power-Button signal is located on the IDC10 Header. To power up/down the board the signal Power-Button must be pulled to GND. -
Page 27: Watchdog-Led
Watchdog-LED The "Watchdog-LED" signal is located on the IDC10 Header. A LED can be connected between Pin10 and Pin12. The signal WATCHDOG will go low on a watchdog event. Signal Signal +3,3V +3.3V (via 330 R) HDD_LED- n.c. PWR_BTN+ MICH_INTRUDER# RST_BTN+ +3.3 V (via 330R) Watchdog#... -
Page 28: Mini-Pcie
3.10 Mini-PCIe Connector type: Mini-PCIe Matching part Mini-PCI-Express Card / MiniCard Signal Signal WAKE# Reserved Reserved CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP Reserved Reserved W_DISABLE# PERST# PERn0 3V3aux PERp0 SMB_CLK PETn0 SMB_DATA PETp0 USB_D- Reserved USB_D+ Reserved Reserved LED_WWAN# Reserved LED_WLAN#... -
Page 29: Lemt Functions
Vendor / Board / Serial number Board Specific LEMT function - Get Voltage The onboard Microcontroller of the Thunderbird-E3100 implements a Voltage Monitor and samples 7 Onboard-Voltages. The Voltages can be ready by calling the LEMT function “Get Voltages”. The function returns a 16 Bit value divided in Hi-Byte and Lo-Byte. -
Page 30: Asf System Management
3.14 CPU Fan Supply The Thunderbird-E3100 provides a connector to power a CPU fan, if the module is actively cooled. The output voltage is minimum 7V and is regulated to the temperature of the CPU. Connector type: AMP-640456-3Pin Matching connector: Molex 2.54mm (.100") Pitch KK®... -
Page 31: Using The Module
4. Using the Module 4.1 BIOS The Thunderbird-E3100 is delivered with a standard PC BIOS. By default, all setup settings are done to have a “ready to run” system, even without a BIOS setup backup battery. The BIOS is located in a Flash PROM and can be easily updated on-board. -
Page 32: Reload Default Bios Values
Reload default BIOS values To reload the default values automatically at power up JP1 must be plugged before power up. On power up the bios will recognize plugged JP1 and load the setup defaults. You will see the following message : Then press <F1>... -
Page 33: Bios Screens
BIOS Screens The BIOS setup utility allows setting of various board parameters. The following pictures show the different setup menus. The Cool RoadRunner-PM specific settings are explained here. Standard CMOS Features Advanced BIOS Features TME-ITX-E3100-R0V8.doc Rev 0.8 Page 28 of 38... - Page 34 Advanced BIOS Features – CPU Feature Advanced Chipset Features TME-ITX-E3100-R0V8.doc Rev 0.8 Page 29 of 38...
- Page 35 Integrated Peripherals Integrated Peripherals – SuperIO Device TME-ITX-E3100-R0V8.doc Rev 0.8 Page 30 of 38...
- Page 36 Frequency/Voltage Control The CPU clock ratio is set by the BIOS, depending on the processor version used. Usually, this is the best setting possible. Changing these values is only recommended for very experienced users and should only be attempted after studying the processor's datasheet. Caution Use this feature on your own risk.
- Page 37 PnP/PCI Configurations Special Features This page is reserved for upcoming special features of the board. TME-ITX-E3100-R0V8.doc Rev 0.8 Page 32 of 38...
- Page 38 Power Management Setup, part 1 S1: POS – Power On Suspend No instructions are executed by the processor, RAM contents are preserved S3: Suspend To RAM (STR), Standby The current processor context is saved to RAM, the processor itself and most peripherals are switched off.
-
Page 39: Address Maps
5. Address Maps This section describes the mapping of the CPU memory and I/O address spaces. Also covered in this section is the PCI configuration space mapping. Note - Depending on enabled or disabled functions in the BIOS, other or more resources may be used. Memory Address Map Address Range (Hex) Description... -
Page 40: I/O Address Map
I/O Address Map The system chipset implements a number of registers in I/O address space. These registers occupy the following map in the I/O space (depending on enabled or disabled functions in the BIOS other or more resources may be used). Address Range (Hex) Description 0000-000F... -
Page 41: Interrupts
Address Range (Hex) Description 0FD00-0FD0F IDE Controller 0FE00-0FE1F USB Controller 0FF00-0FF1F USB Controller Interrupts IRQ (Bus) System Resource Parity Error 0 (ISA) Timer 3 (ISA) Serial Port 2 4 (ISA) Serial Port 1 6 (ISA) Not used 7 (ISA) Not used 8 (ISA) Real Time Clock 9 (ISA) -
Page 42: Dma Channels
DMA Channels System Resource User available User available User available User available DMA Controller User Available User Available User Available TME-ITX-E3100-R0V8.doc Rev 0.8 Page 37 of 38... -
Page 43: Troubleshooting
If system comes up then load at first the OPTIMIZED DEFAULTS in the BIOS setup and reboot. If you need to send the board to LiPPERT for repair, be sure you get a Return Material Authorization number (RMA) first. Check also Appendix B (Getting Help). -
Page 44: Appendix A, Contact Information
Appendix A, Contact Information Headquarters LiPPERT Embedded Computers GmbH Hans-Thoma-Straße 11 68163 Mannheim Germany Phone +49 621 432140 +49 621 4321430 E-mail sales@lippertembedded.com support@lippertembedded.com Website www.lippertembedded.com US Office LiPPERT Embedded Computers, Inc. 2220 Northmont Parkway, Suite 250 Duluth, GA 30096... -
Page 45: Appendix B, Getting Help
Please allow one working day for an answer! Technical manuals as well as other literature for all LiPPERT products can be found in the Products section of LiPPERT's website www.lippertembedded.com. Simply locate the product in question and follow the link to its manual. -
Page 46: Appendix C, Further Resources
Appendix C, Further Resources http://www.lippertembedded.com LiPPERT Embedded Computers' website with news and detailed information. http://www.intel.com Datasheet of the CPU, Chipset and Ethernet-Controller. http://www.smbus.org Information about the System Management Bus (SMBus) http://www.phoenix.com/en/customer+services/bios/awardbios Additional BIOS information. TME-ITX-E3100-R0V8.doc Rev 0.8 Appendix C... -
Page 47: Appendix D, Revision History
Appendix D, Revision History Filename Date Edited by Change TME-ITX-E3100-R0V0 2008-12-22 Ulrich Walther Prerelease Matthias Fellhauer TME-ITX-E3100-R0V1 2008-12-29 Matthias Fellhauer Added: 1.3. Power consumption values 1.3 Mounting options 3.9 Intruder Detect input TME-ITX-E3100-R0V2 2009-02-03 Jürgen Stauffer 3.1. Small corrections 3.12. LEMT functions corrected 3.12.
