Service Manual M2460PHU Revision List Version Date Revision History TPV Model Name Editors/ Redactor Jul-25-2012 Initial release HKCAT76BBVA2DNJ TPV-BJ-Winner PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Service Manual M2460PHU 1. Monitor Specifications 1.1 Product Features Model number M2460PHU Driving system TFT Color LCD Viewable Image Size 61.0 cm diagonal Pixel pitch 0.27675mm(H) x 0.27675 mm(V) Panel Video R, G, B Analog Interface & Digital Interface &...
M2460PHU 2. Setup 2.1 Contents in Box Note: Not all signal cables (HDMI cables) will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Service Manual M2460PHU 2.2 Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove: 2.3 Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor's angle to your own preference.
Service Manual M2460PHU 2.4 Connecting the Monitor Cable Connections In Back of Monitor and Computer: 1. USB 2. Power 3. HDMI 4. DVI 5. Analog (DB-15 VGA cable) 6. Line in To protect equipment, always turn off the PC and LCD monitor before connecting.
5. Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Note : VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Service Manual M2460PHU 3. Operation Instructions 3.1 Hotkeys Source / Auto / Exit Eco (DCR / i-Care) / < Volume / > Menu / Enter Power Power Press the Power button to turn on/off the monitor. Menu/Enter Press to display the OSD or confirm the selection.
Service Manual M2460PHU 3.2 OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press < or > to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it.
Page 12
Service Manual M2460PHU Luminance 1. Press (Menu) to display menu. 2. Press < or > to select (Luminance), and press to enter. 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust.
Page 13
Service Manual M2460PHU 5. Press to exit. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Page 14
Service Manual M2460PHU Image Setup 1. Press (Menu) to display menu. 2. Press < or > to select (Image Setup), and press to enter. 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust.
Page 15
Service Manual M2460PHU 5. Press to exit. Color Setup 1. Press (Menu) to display menu. 2. Press < or > to select (Color Setup), and press to enter. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Page 16
Service Manual M2460PHU 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust. 5. Press to exit. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Page 17
Service Manual M2460PHU Picture Boost 1. Press (Menu) to display menu. 2. Press < or > to select (Picture Boost), and press to enter. 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust.
Page 18
Service Manual M2460PHU OSD Setup 1. Press (Menu) to display menu. 2. Press < or > to select (OSD Setup), and press to enter. 3. Press < or > to select submenu, and press to enter. PDF 文件使用 "pdfFactory Pro" 试用版本创建...
Page 19
Service Manual M2460PHU 4. Press < or > to adjust. 5. Press to exit. Extra 1. Press (Menu) to display menu. 2. Press < or > to select (Extra), and press to enter. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Page 20
Service Manual M2460PHU 3. Press < or > to select submenu, and press to enter. 4. Press < or > to adjust. 5. Press to exit. Exit 1. Press (Menu) to display menu. PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Service Manual M2460PHU 2. Press < or > to select (Exit), and press to enter. 3. Press to exit. Exit Exit the main OSD 3.3 LED Indicator status LED Color Full Power Mode Green or Blue Active-off Mode Orange or Blue PDF 文件使用...
Service Manual M2460PHU 4. Interface description 4.1 D-Sub 15pin Interface Pin No. Description Pin No. Description Red Input +5VDC Green Input Blue Input SDA- DDC-Serial Data Connection detect H Sync Red GND V Sync Green GND SCL- DDC-Serial Clock Blue GND VGA Connector layout 4.2 DVI Interface...
Service Manual M2460PHU 5. Panel Feature This specification applies to the 24 inch-wide Color TFT-LCD Module M240HW02. The display supports the Full HD - 1920(H) x 1080(V) screen format and 16.7M colors (RGB 8-bits data). All input signals are dual channel LVDS interface and this module doesn’t contain an inverter board for backlight.
Service Manual M2460PHU 5.2 Absolute Maximum Ratings Absolute maximum ratings of the module are as follows: Item Symbol Unit Conditions Logic/LCD Drive [Volt] Note 1, Note 2 LED Current ICFL [mA] Note 1, Note 2 Operating Temperature [℃] Note 3 Glass surface [℃]...
Page 26
Service Manual M2460PHU (2)Signal Electrical Characteristics Characteristics of each signal are as following: Backlight Unit 5.3.2. Parameter guideline for LED driving is under stable conditions at 25 ℃ Room temperature: Symbol Parameter Min. Typ. Max. Unit Note IRLED LED Operation Current...
Service Manual M2460PHU 6. Block Diagram 6.1 LCD Block Diagram The LCD Monitor will contain main board, power board, key board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC main board chips each voltage. and the Inverter voltage DC to AC to drive...
Service Manual M2460PHU 6.3 Power Board Block Diagram Fuse smoothing Rectifier Transformer Rectifier capacitor AC input 100-240V Rectifier IC-PWM Switching Rectifier Power adapter Part Sense resistor regulating Photo Couple Sampling DC-AC Resonance NET High Voltage 12V DC Switching MOS Transformer...
Service Manual M2460PHU 6.4 Software Flow Chart Software Flow Chart Start Initial_MCU Check if DataBuffer Is blank To Write default values Check if Sum is changed ? Brightness Contrast Language Read parameter_from Buffer InputType InputTimingStableCounter Init_GlobalVariables OsdCounter PowerDownCounter Initial_MCU Device...
Service Manual M2460PHU 9. Maintainability 9.1 Trouble Shooting Main Board--- No Power No power Check flow chart For the no power Press power key and look if the picture is normal Please reinsert and make sure the AC 100-240V is normal ? Reinsert or check the power section Check 5V-CN101, 3.3V-U103-2;...
Page 48
Service Manual M2460PHU No picture (LED orange) No picture heck flow chart for the no signal Check signal wire Replace signal wire Check U103 Vout=3.3V; U104-out=1.8V replaceU103,U104,Q104, &around device check X401 waveform replace X401 Check CN402-HS/VS waveform Check Correspondent component...
Page 49
Service Manual M2460PHU Power Board--- No Power 5V/12V Check flow chart Check CN901 For the no power 100-240V Check AC supply Check rectified voltage-C905 Check FuseF901/ BD901 L902/BD901/C901/C902 Check voltage of IC901-8pin check component R905/R920 Check T901(1-3)out-Vcc Check D901/R910/C911 Check IC901-drive out...
Page 50
Service Manual M2460PHU No Backlight of panel Check flow chart for the Check voltage of C804-16V Inverter No Backlight Open C804 voltage-16V Return check Power Check ON/OFFsignal After Power off, check Check main board C804/C811/Q805/Q806 Check IC801—11pin=5V After Power off, check...
Service Manual M2460PHU Key Board--- OSD no working OSD is unstable or not Check flow chart working For the key board Is Key Pad Board connecting Connect Key Pad Board normally Is Button Switch normally Replace Button Switch Is Key Pad Board normally...
Service Manual M2460PHU 9.3 Factory mode adjustment After replacing the Main board and the Panel, Check if white-balance is within the specs, then re-writing DDC is necessary. Check for enter the Factory mode: Press button and hold, reinsert the Power cord, then, press MENU, the monitor will may enter Factory OSD Menu.
Service Manual M2460PHU 9.4 Writing DDC program step 1. Prepared the PC with Windows XP system, DDC recording device (12V) 2. Connect the DDC recording device and the PC through PC parallel port 3. setup“Port95nt” driver program to PC , 4.
Page 54
Service Manual M2460PHU PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
Page 72
Service Manual M2460PHU USBAQU4J USB BOARD G2727-T01-AUS-X-3-110522 CN707 033G3802 8B YH CONNECTOR 8PIN 2.0PITCH CN707 033G3802 8B YH CONNECTOR 8P 2.0 CN705 088G 3527A2 CL USB CONN A TYPE R/A 4P BLACK H=6.8 CN705 088G 3527A2 XH USB CONN A TYPE R/A 4P BLACK H=6.8...
Page 73
Service Manual M2460PHU Q744 057G 417511 MMBT3904 Q741 057G 763 3 AO4411 SO-8 BY AOS R750 061G0402000 JY RST CHIPR MAX 0R05 OHM 1/16W YAGEO R753 061G0402000 JY RST CHIPR MAX 0R05 OHM 1/16W YAGEO R776 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN...
Page 74
Service Manual M2460PHU FB752 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN R740 061G0603000 JY RST CHIPR MAX0R05 1/10W YAGEO R762 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN R758 061G0603155 Y RST CHIPR 1.5 MOHM +-5% 1/10W YAGEO...
Page 75
Service Manual M2460PHU C784 065G0402105A5K CAP 0402 1UF 10% 10V X5R C763 065G0402105A5K CAP 0402 1UF 10% 10V X5R C761 065G0402105A5K CAP 0402 1UF 10% 10V X5R C776 065G0402224A5K CAP 0402 0.22UF K X5R C770 065G060310432K CAP 0603 100NF 10% 50V X7R...
Page 76
Service Manual M2460PHU ZD740 093G 39S 48 T DIODE ZENER RLZ6.2B ROHM ZD740 093G 39S957 T ZENER RLZ6V2B 6.2V 0.5W LL-34 FB749 373G0603107CJM CHIP INDUCTOR 10NH 5% 0.6A 0.2R FB750 373G0603107CJM CHIP INDUCTOR 10NH 5% 0.6A 0.2R E715 715G5370T0E000004L USB PCB FR4 DS 111.2*43*1.6MM PDF 文件使用...
