Important: to prevent condensation for-
ming, place the seal on the top half of the
housing (C) only.
fig.4
To complete the installation of the external part,
compartment of the electronic housing,
round (fig. 7).
fig.6
10GB
Joint silicone
after lifting the cover,
CFI EXTEL TOPTEL200- 02/2010 - V1
fig.5
M
-
insert four 1.5 V - LR 20 alkaline batteries in the battery
take care they are inserted the right way
fig.7
M- White
M+ Grey
S- Pink
S+ Purple
C- Black
C+ red
M S S C C
+ - + - +
