RO-MAN
REVERSE OSMOSIS SYSTEM INSTALLATION GUIDE
FOR 200, 300 & 450 GPD RO SYSTEMS
Standard Installation Kit Contents:
Reverse Osmosis System
Membranes
Sediment Filter
Carbon Filter
Multi Media Filter
2 Metres Red Pipe
2 Metres Blue Pipe
Waste Saddle
Saddle Valve Mains ¼"
Roll PTFE Tape
Filter Wrench
PLEASE READ THIS ENTIRE GUIDE PRIOR TO BEGINNING INSTALLATION
IF AT ANY TIME YOU ARE USNURE HOW TO PROCEED PLEASE CONTACT THE SUPPORT
TEAM BY EMAILING: HELPDESK@RO-MAN.COM OR CALLING: 018236 98813.
This water system has been designed for quick and simple installation and maintenance.
By carefully reading this instruction manual and following the operational guidelines you will
ensure a successful installation and reliable operation. Routine maintenance is essential to the
longevity and performance f the system. Filters should be changed every two to six months
depending on the quality of the feed water supply and quantity of water produced.
!!CAUTION!!
DO NOT USE THIS SYSTEM WHERE THE WATER IS MICROBIOLOGICALLY
UNSAFE OR OF UNKNOWN QUALITY
Advertisement
Table of Contents
Related Manuals for Ro-Man 200 GPD
Summary of Contents for Ro-Man 200 GPD
- Page 1 PLEASE READ THIS ENTIRE GUIDE PRIOR TO BEGINNING INSTALLATION IF AT ANY TIME YOU ARE USNURE HOW TO PROCEED PLEASE CONTACT THE SUPPORT TEAM BY EMAILING: HELPDESK@RO-MAN.COM OR CALLING: 018236 98813. This water system has been designed for quick and simple installation and maintenance.
-
Page 2: Conditions For Operation
Conditions for Operation Source Water Supply - TEC Community / Private Non-Chlorinated – or Chlorinated as long as the carbon filter is in place and replaced every 6 months or after RECOMMENDED gallon throughput, which comes first. Membranes are damaged by chlorine. System Pressure (Pre-Filtration) 0-75 PSI Membrane Pressure Range... -
Page 3: Fitting The Membrane
Note on Fit Connections / Quick Connectors: The Push Fit Connectors are opened by pushing down on the collet ring with two fingernails and pulling the hose at the same time. If your nails are not user friendly, then use a pair of pliers, a small spanner or any tool that can apply pressure on both sides of the quick connectors collet. -
Page 4: Maintenance
Flushing the System with the Flush Valve All RO-MAN systems are fitted with a flush valve, this valve is to extend the life of the membrane, the more often you can put the system in flush mode the better. Daily flushing is best but weekly is OK. All you need to do is open the flush valve for 2-3 minutes each time, this lets the water blast away any build up in the membrane. -
Page 5: Troubleshooting
“System Support “ option using the down arrow select your RO-Man system and then input your psi , temperature and if known your input TDS. Click on “Calculate” if the answer to this calculation in UK gallons is markedly higher than what you are producing please contact helpdesk@ro-man.com. -
Page 6: Ro-Man Options
95% Rejection is GOOD 98%+ Rejection is EXCELLENT. RO-MAN Integrated Pump Box We have developed a pump box that will increase the water pressure that drives the membrane. This pump box contains a pump, high pressure switch, to protect and help extend the life of the pump. The pump box also has a solenoid valve to stop... - Page 7 How do you know how pure your water is when using a RO system? We measure how well RO systems work with a Total Dissolved Solids (TDS) meter, with measuring how well your water filter is running you are going through the process of making pure water without knowing if it is actually pure.. Total Dissolved Solids (TDS) are the total amount of mobile charged ions, including minerals, salts or metals dissolved in a given volume of water, expressed in units of MG per unit volume of water (MG/L), also referred to as parts per million (PPM).
-
Page 8: Temperature Correction Factor
RO-MAN Thin Film Membrane Information Permeate Flow Rate Minimum Salt Stabilized Salts Gals/Day US Litres/Day Rejection (%) Rejection (%) Dimensions Inches Inch Inches 11.63 10.0 Recommended Operation Conditions Maximum Operating Pressure 125 PSI (0.86 MPa) Maximum Feed Flow Rate 2 GPM Maximum Operating Temperature 113°F (45°C) - Page 9 Example Question: If a thin-film membrane permeate rate at 77 degrees Fahrenheit = 100 gallons/day. What is the permeate rate at 59 degrees Fahrenheit? Answer: Temperature correction factor (from table above) = 1.47permeate flow at 59 degrees Fahrenheit = 100÷1.47 = 68.03 gallons (us)/day.
- Page 10 RO-MAN For assistance and enquiries please contact the support team: helpdesk@ro-man.com or telephone 018236 98813 10 of 10 Page...
