802.11a/n High Power
Wireless Outdoor
Bridge / AP
WLO-15814N / WLO-15802N
Quick Installation Guide
Ver 1.08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLO-15814N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PheeNet WLO-15814N

Summary of Contents for PheeNet WLO-15814N

  • Page 1 802.11a/n High Power Wireless Outdoor Bridge / AP WLO-15814N / WLO-15802N Quick Installation Guide Ver 1.08...

  • Page 2: Package Contents

    Ethernet connection for a local access. PheeNet High Power Wireless Outdoor Bridge/AP can be used for different purposes in different modes. In the AP mode, it can be deployed either as traditional fixed wireless Access Point (AP), or combination of AP and WDS (AP+WDS). In the WDS mode, it’s only used to expand or bridge Ethernet networks and deployed as a main base, relay based or...

  • Page 3: System Overview

    Quick Installation Guide WLO-15814N / WLO-15802N System Overview  Front Panel Rear Panel Reboot Button : Unscrew the screw and click Reset button to restart system or reset to default configurations. Press and hold the Reset button for 2 seconds and release to restart system. The LED except Power indicator will be off before restarting.

  • Page 4: Hardware Installation

    Quick Installation Guide WLO-15814N / WLO-15802N Hardware Installation  Please follow the steps mentioned below to install the hardware of WLO-15802N : WLO-15802N Front Panel Rear Panel Connect N-type antenna to the N-type connector on the rear panel. Connect PSE to the PoE connector on the front panel.

  • Page 5: Getting Started

    IP Segment Set-up for Administrator's PC/NB Set the IP segment of the administrator's computer to be in the same range as WLO-15814N / WLO-15802N for accessing the system. Do not duplicate the IP Address used here with IP Address of WLO-15814N / WLO-15802N or...
  • Page 6 Quick Installation Guide WLO-15814N / WLO-15802N System Login The system manager Login Page then appears. Enter “root” as User name and “default” as Password, and then click OK to login to the system; the root manager account is used as an example here.

  • Page 7: Quick Setup

    WLO-15814N / WLO-15802N Quick Setup  WLO-15814N / WLO-15802N is a multiple mode system which can be configured either as a gateway or an access point as desired. This section provides a step-by-step configuration procedure for basic installation for AP Mode, WDS Mode, CPE Mode and Client Bridge + Universal Repeater.
  • Page 8 Quick Installation Guide WLO-15814N / WLO-15802N Step 3 : LAN IP Settings Click System -> LAN, and then LAN Setup page appears. Enable “Static IP” and “DNS”, and enter the related information in the field marked. Click Save button to save the settings.
  • Page 9 Quick Installation Guide WLO-15814N / WLO-15802N Step 5 : SSID Settings Click Wireless -> Virtual AP Setup, and then Virtual AP Overview page appears. Click “Edit” on the Primary AP and then Primary AP Setup page appears. Setup the broadcast SSID for easy identification of the system when device is trying to associate the service.
  • Page 10 Quick Installation Guide WLO-15814N / WLO-15802N Enter the WEP key information required in the WEP settings field, the same information will also be used to set up devices using WLO-15814N / WLO-15802N's services. Click Reboot to activate all settings configured above. Congratulation!
  • Page 11 Quick Installation Guide WLO-15814N / WLO-15802N Setup In WDS Mode Step 1 : Mode Confirmation Ensure the Operating Mode is currently at WDS mode; the web management UI can be viewed at the Status section under the System Overview page.
  • Page 12 Quick Installation Guide WLO-15814N / WLO-15802N Step 4 : Time Zone settings Click System -> Time Server, and then Time Server Setup page appears. Enable “NTP Client”, and then enter the related information. Click Save button to save the settings.
  • Page 13 Quick Installation Guide WLO-15814N / WLO-15802N Step 6 : Wireless General Settings Click Wireless -> General Setup, and then General Setup page appears. Select the “Transmit Rate Control” and “Channel” information required in the General Setup field. The information must be the same as other WDS devices.
  • Page 14 Quick Installation Guide WLO-15814N / WLO-15802N Setup In CPE Mode Step 1 : Mode Confirmation Ensure the Operating Mode is currently at CPE mode; the web management UI can be viewed at the Status section under the System Overview page.
  • Page 15 Quick Installation Guide WLO-15814N / WLO-15802N Step 3 : LAN IP Settings Click System -> LAN, and then LAN Setup page appears. Enter the “IP Address” and “IP Netmask” of the LAN Setup. Step 4 : Time Zone settings Click System -> Time Server, and then Time Server Setup page appears. Enable “NTP Client”, and then enter the related information.
  • Page 16 Quick Installation Guide WLO-15814N / WLO-15802N Step 6 : Site Survey Click Wireless -> Site Survey, and then Station Site Survey page appears. The system will automatically scan and display the scan results of all AP existing near by the system.
  • Page 17 Quick Installation Guide WLO-15814N / WLO-15802N Click Reboot button to activate all settings configured above. Congratulation! The CPE mode is now successfully configured.
  • Page 18 Quick Installation Guide WLO-15814N / WLO-15802N Setup In Client Bridge + Universal Repeater Mode Step 1 : Mode Confirmation Ensure the Operating Mode is currently at Client Bridge + Universal Repeater mode; the web management UI can be viewed at the Status section under the System Overview page.
  • Page 19 Quick Installation Guide WLO-15814N / WLO-15802N Step 3 : LAN IP Settings Click System -> LAN, and then LAN Setup page appears. Enter the “IP Address” and “IP Netmask” of the LAN Setup. Step 4 : Time Zone settings Click System -> Time Server, and then Time Server Setup page appears. Enable “NTP Client”, and then enter the related information.
  • Page 20 Quick Installation Guide WLO-15814N / WLO-15802N Step 6 : Select AP to be Associated Search for the AP to be associated with from the Scan Result list provided in Step 3; use 211AP0 as an example here where the AP is encrypted via WEP security type.
  • Page 21 Quick Installation Guide WLO-15814N / WLO-15802N Select WEP in “Security Type“ drop-down list. The WEP setting field will show up immediately. Enter the WEP key information required in the WEP settings field, the same information will also be used to set up devices using WLO- 15814N / WLO-15802N's services.
