Opera Audio Consonance Isolde User Manual page 9

6. Adjust the tone arm 's VTA.
As mentioned on the point 2 not screw the arm base tighten, raising or lowering oil cup and then
tightening set screws when correct VTA is obtained. Please note that can not be forced in order to
avoid damage the tone arm. Normally the correct VTA is subject to the tone arm centerline
parallels to the LP record, the high or low of VTA is very important for the sound, this is also fun of
LP playing.
TECHNICAL SPECIFICATION
Mounting distance arm base
Tone arm length
Arm tube made of
Overhang
Offset
Cartridge weight
Down force range
Weight(without counterweight)
Counterweight
214mm
9''
carbon-fibre
16mm
23 degree
4-22g
10-35mN
37g
65g
9
