HLLY Electronics TX-30S Instruction Manual

FM Transmitter instruction manual

Mode: HLLY TX-30S

v1.0

Table of Contents

Need help?

Do you have a question about the TX-30S and is the answer not in the manual?

Page 1 FM Transmitter instruction manual Mode: HLLY TX-30S v1.0...
Page 2 ———————————————————————————————————————————————— Front Panel Back Panel ———————————————————————————————————————————————— Main display schematic diagram...
Page 3 ———————————————————————————————————————————————— List of operating functions 1）Operation Manual（Push the code switch knob, the transmitter will enter the Function selecting menu, select the function by Rotating the Knob, after select the function, push the knob you will enter the setting menu, left rotate to min , right rotate to max Push knob to confirm and return to MENU .
Page 4 Exit. 2）Parameters supply Power DC12-13.8V Recommend 12.8V Maximum operating current: Ambient temperature: -5~40℃ Frequency Range: 87MHz~108MHz Frequency Step 100KHz Frequency Stabilize Style: Pre-emphasize Default 50µs Optional 75µs Output power: 0 to 1000mW±10% Output resistance: 50 OHM 10. Modulate Style: ±75KHz 11.
Page 5 Note ：This is the spectrum picture when transmitter work at 98Mhz ,， There is no stray radiation and signal is very clear. Almost no second harmonics。 For warranty service, contact your dealer or HLLY Electronics :...
