CUMMINS ALLISON jetscan User Manual

Two-pocket currency scanner
Hide thumbs Also See for jetscan:

Advertisement

Quick Links

See also: Operating Manual , User Manual
JetScan
®
Two-pocket currency scanner
User guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the jetscan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CUMMINS ALLISON jetscan

Summary of Contents for CUMMINS ALLISON jetscan

  • Page 1 JetScan ® Two-pocket currency scanner User guide...

  • Page 2: Safety Information, Power Specifications

    Do not attempt repairs. Repairs must be made by authorized Cummins Allison personnel. Use grounded plug and properly grounded outlet. Read and understand all instructions before use. Only use Cummins Allison supplied power adapter. Helv. Bold Oblique 41.29 Use of any other power adapter may damage equipment.

  • Page 3: Table Of Contents

    • Flexible configurations. Two or more processing functions can be combined to maximize productivity. • Several counterfeit detection options. • A bar-code reading option. For more information, contact a Cummins Allison representative. About this guide | Two-pocket JetScan currency scanner | 3 ®...

  • Page 4: Machine Diagram

    Black feed rollers Release lever Release lever Power switch/ power cord on back of unit Stacker wheels Stacker sensor Pocket one Stacker mirror Stacker wheels Stacker sensor Pocket two Stacker mirror 4 | Two-pocket JetScan currency scanner | Machine diagram ®...
  • Page 5 Turning the dial to the left, so a positive number is at the top, increases the spacing between the rollers, allowing notes to pass through more easily. Machine diagram | Two-pocket JetScan currency scanner | 5 ®...

  • Page 6: Getting Started

    Getting started This section outlines basic features and functions of the two-pocket JetScan currency scanner. Powering ON/OFF High-voltage levels may be present. Risk of electric shock. Turn power OFF and unplug power cord from machine before cleaning. Do not attempt repairs. Repairs must be made by authorized Cummins Allison personnel.
  • Page 7 Press to prompt the STRAP SETTINGS screen, where STRAP strap limits are set and strap counts are cleared. CONT Press to start the motor and clear totals on the screen. (Continue) Getting started | Two-pocket JetScan currency scanner | 7 ®...
  • Page 8 Press to prompt the MODE SELECTION screen, which displays all processing modes that are enabled in MODE SETUP. Press to prompt the MAIN SUB MENU, which provides access to additional menus for reports and machine MENU adjustments. 8 | Two-pocket JetScan currency scanner | Getting started ®...
  • Page 9 (Stranger 2) The machine stops and presents no-call, suspect- document or stranger notes, as well as double, chain or spacing errors, in the current sorting pocket. Getting started | Two-pocket JetScan currency scanner | 9 ®...
  • Page 10 Double, chain or spacing errors stop in the current sorting pocket. Suspect documents stop in the pocket with the same facing or orientation. A grand total is provided. 10 | Two-pocket JetScan currency scanner | Getting started ®...
  • Page 11 The machine stops and presents no calls or suspect documents, as well as double, chain or spacing errors, in the current sorting pocket. A grand total is provided. Getting started | Two-pocket JetScan currency scanner | 11 ®...
  • Page 12 If FACE or ORINT is also selected, non-faced/ non-oriented notes of the target denomination are counted and offsorted to the lower pocket but are not included in the strap count. 12 | Two-pocket JetScan currency scanner | Getting started ®...
  • Page 13 A day total is the grand total of deposits processed since the last time day totals were cleared. Day total tracks individual amounts and provides a total by category, as well as a grand total. Available in all operating modes. Getting started | Two-pocket JetScan currency scanner | 13 ®...
  • Page 14 To clear all note strap counts to 0, press CLEAR followed by ALL. If STRAPS CLEAR is set to ENDBT in SETUP, then ending a batch automatically clears all strap counts. 14 | Two-pocket JetScan currency scanner | Getting started...
  • Page 15 • The next four digits represent the batch number. • The final three digits represent the sub-batch number. Batch report example BATCH REPORT 00004-0001-000 DENOM UNIT VALUE BATCH 1430 TOTAL Getting started | Two-pocket JetScan currency scanner | 15 ®...

  • Page 16: Stopping Conditions And Recovery Steps

    CONT. The machine reverts to the note count that preceded the error with no impact on strap, sub-batch and day counts. 16 | Two-pocket JetScan currency scanner | Stopping conditions and recovery steps ®...
  • Page 17 If the note should not be counted, remove it and press CONT. The machine restarts without adding the NO CALL note to the count. Stopping conditions and recovery steps | Two-pocket JetScan currency scanner | 17 ®...
  • Page 18 Condition The machine identified a sorting error. Action Remove all notes from the pocket indicated on the screen and place them in the hopper. Then press CONT. 18 | Two-pocket JetScan currency scanner | Stopping conditions and recovery steps ®...
  • Page 19 • Worn note • Incorrect note paper • Soiled note • Incorrect note paper • Machine-washed note • Taped note * Multiple codes may appear on a screen Stopping conditions and recovery steps | Two-pocket JetScan currency scanner | 19 ®...
  • Page 20 • Worn note of a super note * These error codes are most common among super notes, which are high-quality counterfeits. Notes producing these codes should be carefully examined. 20 | Two-pocket JetScan currency scanner | Stopping conditions and recovery steps ®...
  • Page 21 Remove all notes from the hopper and both pockets. Remove hopper. Remove feeder plate. Raise the two red plastic “T” handles at the same time and hook them onto the metal shaft. Stopping conditions and recovery steps | Two-pocket JetScan currency scanner | 21 ®...
  • Page 22 Curved edge Replace the hopper. Press CONT. Reprocess all notes that were in the hopper and both pockets at the time of the jam. 22 | Two-pocket JetScan currency scanner | Stopping conditions and recovery steps ®...

  • Page 23: Daily Cleaning Procedures

    Daily cleaning procedures Daily cleaning of the two-pocket JetScan currency scanner is recommended to ensure maximum productivity and reliability, especially for high-volume applications, as well as for those processing highly circulated (dirty) notes. Recommended cleaning materials Simple Green, the recommended cleaning agent, can be an eye irritant.
  • Page 24 Clean the black start sensor with a microfiber towel. Remove feeder plate. Firmly push down on left and right release levers and pull front enclosure open for access to paper path. 24 | Two-pocket JetScan currency scanner | Daily cleaning procedures ®...
  • Page 25 In each pocket, use a microfiber towel or vacuum to clean the stacker-sensor lens located between the two gray stacker wheels. Next, use a microfiber towel or vacuum to clean the stacker mirror located directly across from the stacker-sensor lens. Daily cleaning procedures | Two-pocket JetScan currency scanner | 25 ®...
  • Page 26 Clean remaining hard-plastic exterior surfaces as necessary with a Simple Green Safety Towel. Carefully reconnect power cord on the back of the machine. Turn power switch ON (rocker panel to I). Perform a test run with some notes. 26 | Two-pocket JetScan currency scanner | Daily cleaning procedures ®...
  • Page 27 022-1308-00 How to order To place an order in the United States, visit store.cumminsallison.com. To place an order outside of the United States, contact your local Cummins Allison representative. Daily cleaning procedures | Two-pocket JetScan currency scanner | 27 ®...
  • Page 28 This manual contains proprietary information of Cummins Allison. It is intended solely for the information and use of parties authorized by Cummins Allison to maintain the equipment described herein. Such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose without express written permission of Cummins Allison.
