Quidel Virena WR11 Installation Instructions

If this is the first time setting up Sofia, please review the Sofia User Manual to enable the features on your new
Sofia.

Virena Package Contents

The following system components are supplied with the router.
 Virena WR11 Router
 Cellular Antenna
 Ethernet Cable
 Power Supply
 Installation Instructions
Note: If any item is missing or damaged, please contact Quidel Technical Support at 800.874.1517 (in the U.S.),
858.552.1100 (outside the U.S.) or e-mail technicalsupport@quidel.com.

Sofia and Virena Surveillance Installation Overview

There are a few simple steps required in order to set up your Virena WR11 Router and Sofia. Let's begin with
the Virena WR11 Router:

Virena Router Installation and Connection

1. Connect the Cellular Antenna: Connect the cellular antenna to the
connector on the router (Figure 1). The antenna provides improved
signal strength resulting in better performance.
2. Connect the Power Supply: Connect the plug end of the 5 volt power
supply to the power connector on the router. Insert power supply end
fully and rotate clockwise to engage and lock (Figure 2). Then plug the
other end into a wall outlet.
3. Connectivity Verification: After powering on the Virena WR11 Router,
wait 5 minutes before confirming the following lights are illuminated
for connection purposes (Figure 3).
Sofia Surveillance Mode Installation Instructions for Virena WR11 Router
Figure 2
Sofia Surveillance Mode
Installation Instructions
for Virena WR11 Router
*Only authorized users approved by the Healthcare
Provider's Organizational Administrator have
access to registering on MyVirena.com.
Figure 3
Figure 1
Page 1 of 4
