User Manual: CoboPin-VT3001C(-I/-T)
■ Technical data COBOPIN-VT3001C-I
Panels/Output.............................................................................1 panel, 540 lm
LED configuration...........................1×20W COB-TriLED (1x5W-R, 1x7W-G, 1x7W-B)
Optics............................................................................Secondary, 30 degrees
DMX Control & protocol............................................3-5 Channels DMX 512 (1990)
IP Rating.........................................................................................20 (indoor)
Mains Input......................................................................AC100-250V~ 50/60Hz
Power supply type, max. consumption..........................................switch mode, 29W
DMX connections.........................................................3 pin XLR (Male / Female)
Modulation Type...................................................Pulse Density Modulation (PDM)
Dimensions (without bracket) WxHxD................................ ..100.0 x 99.0 x 202.0mm
Dimensions (with bracket) WxHxD.....................................115.0 x 213.0 x 202.0mm
Weight....................................................................................................1.5kg
Technical data COBOPIN-VT3001C-T
Panels/Output.............................................................................1 panel, 540 lm
LED configuration...........................1×20W COB-TriLED (1x5W-R, 1x7W-G, 1x7W-B)
Optics............................................................................Secondary, 30 degrees
DMX Control & protocol............................................3-5 Channels DMX 512 (1990)
IP Rating.........................................................................................20 (indoor)
Mains Input......................................................................AC100-250V~ 50/60Hz
Power supply type, max. consumption..........................................switch mode, 29W
DMX connections.........................................................3 pin XLR (Male / Female)
Modulation Type...................................................Pulse Density Modulation (PDM)
Dimensions (without bracket) WxHxD................................ ..100.0 x 99.0 x 202.0mm
Dimensions (with bracket) WxHxD.....................................151.0 x 213.0 x 202.0mm
Weight....................................................................................................1.6kg
■ Standards
This product complies with the following standards:
EU electrical safety................................................EN60598-1:2008, EN60598-2-1:1989
EU general safety....................................................................... EN60598-2-17
EU photobiological safety.........................................................................EN 62471:2008
EU EMC......................................EN55015: 2006 + A1:2007, EN61547:1995 + A1:2000
EU Harmonics ...................................................................................EN61000-3-2:2006
EU Flicker ............................................................................EN61000-3-3:2008
US safety ..........................................................................................UL60065
US EMC........................................................................................FCC Part 15
This product meets both the EMC Directive 2004/108/EC and the Low Voltage Directive
2006/95/EC.
Ask your dealer or visit
www.multiform-lighting.com
V1.00 (10-2013)
for more information.
16
USER MANUAL
COBOPIN-VT3001C(-I/-T)
High-Power RGB LED Lighting Fixture
For firmware 50-010-0018-00111-1-00 (RevL)
ENGLISH Page 2-16
Updated versions of this document may be available at
WWW.MULTIFORM-LIGHTING.COM
RevA 10/2013 Order code: 12-010-0403-80101-1-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Multiform COBOPIN-VT3001C-I
Summary of Contents for Multiform COBOPIN-VT3001C-I
- Page 1 User Manual: CoboPin-VT3001C(-I/-T) ■ Technical data COBOPIN-VT3001C-I Panels/Output…………………………………………………………….…….1 panel, 540 lm USER MANUAL LED configuration….………………..…1×20W COB-TriLED (1x5W-R, 1x7W-G, 1x7W-B) Optics………………………………………………………………….Secondary, 30 degrees DMX Control & protocol……………………………..……...3-5 Channels DMX 512 (1990) COBOPIN-VT3001C(-I/-T) IP Rating………………………………………………………………………..……20 (indoor) High-Power RGB LED Lighting Fixture Mains Input…………………………………………………………….AC100-250V~ 50/60Hz Power supply type, max.
- Page 2 Multiform-branded item and the trust having been put in us with this decision. Multiform is one of the leading global manufacturers of If none of the buttons is pressed for more than approximately 25 seconds the display is professional lighting equipment and has decades of experience in design, production switched off.
- Page 3 User Manual: CoboPin-VT3001C(-I/-T) User Manual: CoboPin-VT3001C(-I/-T) The unit receives DMX values on a packet of four channels and mirrors the received data on the DMX output (9). If a DMX signal is present the DMX LED (3) will turn on. WARNING! Shock hazard.
- Page 4 User Manual: CoboPin-VT3001C(-I/-T) User Manual: CoboPin-VT3001C(-I/-T) Protection from electric shock: The unit receives DMX values on a packet of four channels and mirrors the received Only connect this unit to a mains socket outlet with protective earth data on the DMX output (9). If a DMX signal is present the DMX LED (3) will turn on. connection, ground-fault (earth-fault) and overload protection.
- Page 5 User Manual: CoboPin-VT3001C(-I/-T) User Manual: CoboPin-VT3001C(-I/-T) Available colour presets: The surface of the device may get hot during operation, and heat sink areas may reach to or exceed the limits of EN60950. Do not all off Frog touch heat sink areas of the device during operation, and allow 20 Lavender minutes of cool-down time after powering off before touching.
- Page 6 User Manual: CoboPin-VT3001C(-I/-T) User Manual: CoboPin-VT3001C(-I/-T) ■ LED Lifetime advice Description Function of Knob (1) All off none LED lifetime is determined by the gradually declining brightness of a LED over time, Static scene Colour with a point of 50% brightness reduction marking the defined end of its lifetime. The Soft fade red-green Speed Soft fade green-blue...
- Page 7 User Manual: CoboPin-VT3001C(-I/-T) User Manual: CoboPin-VT3001C(-I/-T) User interface overview: ■ Getting started: secure mounting In A-Mode: Speed Control (except A1 = Mix Control) The CoboPin-VT3001C can be positioned for operation in various ways: In C-Mode: Level-Control Display showing the Mode, DMX-address, LOC-function etc. Floor standing operation (only –T touring version) Indicates presence of a DMX signal Indicates the sound-activated mode (internal microphone)
- Page 8 User Manual: CoboPin-VT3001C(-I/-T) User Manual: CoboPin-VT3001C(-I/-T) ■ Getting started: making AC supply connections ■ Operation Risk of fire / Safety risk VT3001-I (install version) The CoboPin-VT3001C requires an AC power source with sufficient power carriage and correct grounding to ensure safe operation. The AC power source must be equipped with a circuit breaker and earth leakage detector.
