- Page 1 XR4116 INSTALLATION/OWNER'S MANUAL AM/FM Receiver...
-
Page 2: Getting Started
XR4116 INSTALLATION Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. -
Page 3: Wiring Diagram
XR4116 INSTALLATION Wiring Diagram Antenna Connector 10 AMP AGC Fuse FUSE When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The unit uses one 10 amp AGC fuse located... -
Page 4: Operation
XR4116 OPERATION Control Locations Power Preset 3 / Intro Volume Knob Preset 2 / Random Audio / Menu Preset 1 / Repeat USB Port Display Reset Tune Up Auxiliary Input Tune Down Preset 6 / Folder Up Band / Go Back... -
Page 5: General Operation
XR4116 OPERATION General Operation Power On/Off Press or any other button to turn the unit on. Press again to turn the unit off. Mode Press MODE to select between AM/FM, USB or auxiliary input modes. Modes of operation are indicated in the display. USB mode will not appear unless a USB device is connected. - Page 6 XR4116 OPERATION General Operation Press the volume knob to select between Bass, Treble, Audio / Menu Balance, Fader, Loudness, Distance and Stereo. STEREO BASS TREBLE BALANCE FADER LOUDNESS DISTANCE Press the volume knob until BAS appears. Bass Rotate the volume knob left/right to adjust. (-7 minimum / +7 maximum) Press the volume knob until TRE appears.
-
Page 7: Am/Fm Tuner Operation
XR4116 OPERATION AM/FM Tuner Operation Press TUNE or TUNE momentarily to seek to the Seek Tuning next strong station. Press and hold TUNE or TUNE until "MANUAL" Manual Tuning appears, then press TUNE or TUNE momentarily to change radio frequency up or down one step at a time. - Page 8 XR4116 OPERATION USB Operation Repeat Press RPT to choose between: • Current Song - Continuously repeats selected track. • Current Folder - Continuously repeats all files in folder. Random Press RDM to choose between: • Off - Cancels RDM function. • All Songs - Plays all tracks in random order.
- Page 9 XR4116 OPERATION USB Operation Playback Capacity • Maximum number of files: 1024 • Maximum number of folders: 512 • Maximum number of folder levels (sub folders): 8 Note: If the number of files/folders exceeds the maximum outlined above, the additional files/folders will be ignored.
-
Page 10: Troubleshooting
XR4116 OPERATION Troubleshooting Problem Cause Action Yellow wire not connected or incorrect Check connections for proper voltage Red wire not connected or Unit will not turn on voltage (11~16VDC) incorrect voltage (no power) Black wire not connected Check connection to ground Fuse blown Replace fuse... -
Page 11: Limited One Year Warranty
2. If you require service during the the original purchase. warranty period, you must carefully pack the product (preferably in the Dual Electronics Corp. agrees, at our original package) and ship it by prepaid option, during the warranty period, transportation with a copy of the original... -
Page 12: Specifications
XR4116 OPERATION Specifications FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 25dbu Stereo separation @ 1kHz: >30dB Frequency response: 30Hz-13kHz AM Tuner Tuning range: 530kHz-1710kHz Usable sensitivity: <42dBu Frequency response: 30Hz-2.2kHz General Speaker output impedance: 4~8 ohms Line output voltage: 2 Volts RMS... -
Page 13: Fcc Compliance
XR4116 OPERATION FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
