- Page 1 BASRTP-B Portable ® BACnet Multi-Network Router Installation Guide TD070210-0ID For Firmware Versions 2.x...
- Page 2 Contemporary Control Systems, Inc. reserves the right to make changes in the specifications of the product described within this manual at any time without notice and without obligation of Contemporary Control Systems, Inc. to notify any person of such revision or change. TD070210-0ID...
-
Page 3: Table Of Contents
Contents Introduction ..............4 Specifications ............... 5 Electrical ..............5 Environmental .............. 5 Functional ..............5 Electromagnetic Compatibility ........5 Connectors ..............6 Mechanical ..............6 Power................7 Operation ..............9 MS/TP Port ..............9 Ethernet Port ..............9 IP Address Reset Switch ..........9 LEDS ................ -
Page 4: Introduction
Thus, only a straight-through CAT5 cable is needed for hook-up. The USB port is strictly used to power the BASRTP-B. No communications is supported via the USB port. The BASRTP-B features a user-accessible switch to reset the IP address, subnet mask and gateway address to the factory defaults. -
Page 5: Specifications
Specifications Electrical INPUT USB (Type B Port) Voltage (V, nominal) 5 VDC Current (mA, typical) Power: 2.5 W Environmental Operating temperature: 0°C to 60°C Storage temperature: –40°C to +85°C Relative humidity: 10–95%, non-condensing Functional Ethernet MS/TP Signalling: 10BASE-T EIA-485 100BASE-TX (ANSI/ASHRAE 135-2008) Cable length limit: 100 m... -
Page 6: Connectors
Connectors 3-pin (MS/TP) Pin Assignments (Also explained on product label) Figure 1 — 3-pin Connector RJ-11 (MS/TP) Pin Assignments RT – RT + Figure 2 — RJ-11 Connector (All other pins are unused.) RJ-45 (MDI Ethernet) Pin Assignments TD + RD + TD –... -
Page 7: Power
Power The BASRTP-B features a USB 2.0 Full Speed Device Port that accepts the USB cable with Type B plug that is included in the box. It takes 5 VDC from a host computer, while typically drawing 300 mA of current. - Page 8 Figure 6 — 3-wire MS/TP Bus Wiring TD070210-0ID...
-
Page 9: Operation
Operation MS/TP Port The MS/TP port uses an isolated EIA-485 transceiver that is connected to both a removable 3-pin connector (Figure 1) and an RJ-11 jack. Either connector can be used for the MS/TP line. The EIA-485 transceiver’s + and – lines tie to + and – pins of both connectors. -
Page 10: Webpage Configuration
BASRTP-B, a computer for configuration, and a connection to the MS/TP network. Make sure that a USB cable connects between the PC and the BASRTP-B so it can be powered. To configure the router, attach it to a computer with an Ethernet connection and a standard web browser. - Page 11 On some systems, this option is: ―My Network Places‖. Figure 9 — Steps for Changing the IP Address of the PC Used for Setup TD070210-0ID...
- Page 12 After entering the router’s IP address into your browser’s address field, you will see the Router Configuration Page with the default values as shown in Figure 10 — using Windows Internet Explorer. Figure 10 — Router Configuration Page with Default Values Each parameter of the configuration is explained on the following pages.
-
Page 13: Device Parameter
65535 are reserved). If the BACnet Ethernet network value is left at its default value of 0, the BACnet Ethernet function within the BASRTP-B will be disabled. To prevent message loops, a subnet must have only one router enabled for BACnet Ethernet. -
Page 14: Bacnet/Ip Parameters
The BACnet/IP network number is a 16-bit value (1–65534). Each network within the BACnet internetwork must have a unique number. This includes the BACnet/IP and MS/TP sides of the BASRTP-B. Do not use addresses 0 or 65535 since these addresses are reserved. IP Address (Default Value = 192.168.92.68) -
Page 15: Ms/Tp Parameters
1. equals the highest MAC address of any master, and 2. all masters use sequential MAC addresses Since many BACnet devices do not allow this parameter to be changed, leave the BASRTP-B at the default value. Max Info Frames (Default Value = 40) This is the maximum number of messages that can be routed onto the MS/TP network by the router per token pass. -
Page 16: Status Screen
Strict setting. Status Screen The Status Screen depicted in Figure 11 reports the traffic of the various protocols handled by the BASRTP-B. It shows the number of messages received and transmitted for each of the supported networks. - Page 17 By refreshing this page, you can watch the router MS/TP state change and gain insight into the state of the MS/TP network (as seen by the router). For example, if ―MNSM‖ always reports SoleMaster or PollForMaster, after repeated refreshes, then the router cannot communicate with any MS/TP devices.
-
Page 18: Warranty
Warranty Contemporary Controls (CC) warrants this product to the original purchaser for two years from the product shipping date. Product returned to CC for repair is warranted for one year from the date the repaired product is shipped back to the purchaser or for the remainder of the original warranty period, whichever is longer. -
Page 19: Declaration Of Conformity
EN 55024:1998 + A1:2001 + A2:2003, Information Technology Equipment — Immunity Characteristics — Limits and Methods of Measurement Manufacturer: Authorized Representative: Contemporary Control Systems, Inc. Contemporary Controls Ltd 2431 Curtiss Street Sovereign Court Two, UWSP Downers Grove, IL 60515 USA... - Page 20 This page is intentionally left blank. TD070210-0ID...
