- Page 1 MC1000-SFP 100/1000 Base-T UTP to 1000 Base-X Fiber SFP Media Converter User’s Guide Version 1.0 11/2004...
-
Page 2: Copyright
ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others. -
Page 3: Zyxel Limited Warranty
MC1000-SFP User’s Guide (2) This device must accept any interference received, including interference that may cause undesired operations. FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial environment. -
Page 4: Safety Warnings
MC1000-SFP User’s Guide upon proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials, ZyXEL will, at its discretion, repair or replace the defective products or components without charge for either parts or labor, and to whatever extent it shall deem necessary to restore the product or components to proper operating condition. -
Page 5: Table Of Contents
For brevity’s sake, we will use “e.g.” as shorthand for “for instance”, and “i.e.” as shorthand for “that is” or “in other words” throughout this manual. The MC1000-SFP may be referred to as the MC1000, media converter or device in this manual. ZyXEL Web Site The ZyXEL download library at www.zyxel.com contains additional... -
Page 6: Customer Support
MC1000-SFP User’s Guide Customer Support Please have the following information ready when you contact customer support. WORLDWIDE NORTH AMERICA GERMANY Tel: +886-3-578-3942 Tel: +1-800-255-4101 Tel: +49 2405 6909 0 Fax: +886-3-578-2439 Tel: +1-714-632-0882 Fax: +49 2405 6909 99 Email: sales@zyxel.com.tw Fax: +1-714-632-0858 Email: sales@zyxel.de... -
Page 7: Introduction
MC1000-SFP User’s Guide Introduction The 100/1000 Base-T UTP to 1000 Base-X Fiber SFP Media Converter allows seamless integration between a Fast/Gigabit Ethernet network using unshielded twisted pair (UTP) copper cabling and a Gigabit fiber network. Use the LEDs to quickly check status and the DIP switches to set transmission settings and “link loss forwarding”. -
Page 8: Example Applications
MC1000-SFP User’s Guide Can insert an SFP (Small Form-factor Pluggable) transceiver module with LC-type connector DIP switches to configure fiber link negotiating defaults and Link Loss Forwarding Link Loss Forwarding to notify the peer link if a link goes down... -
Page 9: Hardware
MC1000-SFP User’s Guide Hardware The media converter can be placed on a desktop. Make sure that there is proper heat dissipation from and adequate ventilation around the device. Do not place heavy objects on the media converter. Front Panel The front panel consists of an RJ-45 port for 100/1000 Mbps UTP connections, LED indicators, DIP switches and an SFP slot for an SFP transceiver module with an LC-type connector. -
Page 10: Led Indicators
MC1000-SFP User’s Guide An auto-negotiating port can detect and adjust to the optimum Ethernet speed (100/1000Mbps) and duplex mode (full duplex or half duplex) of the connected device. An auto-crossover (auto-MDI/MDI-X) port automatically works with a straight-through or crossover Ethernet cable. -
Page 11: Dip Switches
MC1000-SFP User’s Guide LNK/ACT Green The media converter fiber link is up. (Fiber) Blinking The media converter is transmitting or receiving on the fiber link. The media converter fiber link is down. FDX/COL Orange The fiber port is operating in full-duplex mode. - Page 12 MC1000-SFP User’s Guide The fiber link is auto-negotiating when the switch is off. Turn it Switch 1 on to force the fiber link to be up at only 1000Mbps in full duplex mode. Turn this switch on to have the Ethernet port send a Link Loss...
- Page 13 MC1000-SFP User’s Guide Disconnect all fiber-optic cables from an SFP transceiver module before installing or removing it. Do NOT remove and install an SFP transceiver module more often than is absolutely necessary. Doing so may shorten the useful life of the SFP transceiver module.
- Page 14 MC1000-SFP User’s Guide Do NOT force or twist the SFP transceiver module into a slot. Connecting a Fiber-optic Cable Follow the steps described to connect a fiber-optic cable to the SFP transceiver module. Remove the dust plugs from the SFP transceiver module and the cables.
-
Page 15: Rear Panel
MC1000-SFP User’s Guide Using your thumb and index finger, grasp the tabs on both sides of the module and carefully slide it out of the slot. Do NOT force or twist the module out of a slot. Rear Panel The rear panel contains a power port. Connect the included power adapter (9V DC voltage with minimum 0.7A current) to the port labeled... -
Page 16: Specifications
MC1000-SFP User’s Guide Specifications ITEM SPECIFICATION Ethernet IEEE802.3 10BASE-T Standards IEEE802.3u 100BASE-TX IEEE 802.3ab 1000Base-T IEEE802.3x Flow Control and Back pressure Ethernet Port CAT-5 (100/1000Mbps) unshielded twisted pair cable. Auto-crossover (MDI/MDI-X) and auto-negotiation support. Fiber Port SFP 3.3V with LC connector. - Page 17 MC1000-SFP User’s Guide ITEM SPECIFICATION Temperature Operating: 0 ~ 45 C (32 ~ 113 Storage: -10 ~ 70 C (14 ~ 158 Humidity Operating: 10 ~ 90% (non-condensing) Storage: 10 ~ 90% (non-condensing) FCC Part15 (Class A) CE EMC (Class A)
-
Page 18: Troubleshooting
MC1000-SFP User’s Guide Troubleshooting Use the LEDs to identify possible problems and then take corrective action. PROBLEM POSSIBLE CAUSES AND REMEDIES The PWR LED Make sure you are using the supplied power adaptor is off and that it is plugged in to an appropriate power source. - Page 19 MC1000-SFP User’s Guide PROBLEM POSSIBLE CAUSES AND REMEDIES The LNK/ACT Check the Ethernet cable connection between the (Ethernet) LED media converter and the Ethernet device. The distance is off between them should not be more than 100 meters Check for faulty Ethernet cables.
