Summary of Contents for The box PA110
-
Page 1: User Manual
P R O S P E A K E R PA110 TWO-WAY PASSIVE SPEAKER User Manual... -
Page 2: Safety Precautions
Do not expose the speaker cabinet to direct precipitation or stand in water. Liquid getting into the box will risk a short circuit and will be hazardous. Do not stack the speaker cabinet in a manner that could cause injury should a cabinet become dislodged. - Page 3 PA110 PA110 Frequency response, SPL/2.83v Impedance curve PA110 PA110 Harmonic distortion 106dB/2.5m, nominal impedance Waterfall spectrum analysis FEATURES: Two-way passive speaker with one 10" woofer and one 1.5" driver. Cabinet is made from polypropylene and special high-tech material in large injection mold.
-
Page 4: Specifications
Specifications System: Built-in Crossover Two Way Full Range Speaker Cabinet: Polypropylene, Trapezoid Driver Quantity: 10 x1(Bass) 34mm Driver Frequency Response(-3dB): 55Hz-18KHz Frequency Response(-10dB): 50Hz-20KHz Sensitivity(dB/1M/1W): 95 dB Impedance: 8 Ohm Recommendatory Power(RMS/W): 250 W Max Sound Level(dB/1M): 119dB Tweeter Dispersion(HxV): 90 x 60 Harmonic Distortion: Connectors:...
