Qualcast
1900W High Pressure Washer
Original instruction manual
Important
–
Please read these instructions fully before operating or maintaining your pressure washer.
These instructions contain important information that will help you get the best from your
pressure washer, ensuring it is assembled correctly and safely.
Q1W-SP16-1900
Technical Support & Parts
01904 727500
www.gardenservicecentre.co.uk
Scan to watch
our new
instruction
videos!
June 2015 Rev A

Advertisement

Table of Contents
loading

Related Manuals for Qualcast Q1W-SP16-1900

Summary of Contents for Qualcast Q1W-SP16-1900

  • Page 1 Qualcast 1900W High Pressure Washer Original instruction manual Q1W-SP16-1900 Technical Support & Parts 01904 727500 www.gardenservicecentre.co.uk Scan to watch our new instruction videos! Important – Please read these instructions fully before operating or maintaining your pressure washer. These instructions contain important information that will help you get the best from your pressure washer, ensuring it is assembled correctly and safely.

  • Page 2: Table Of Contents

    Safety Information Contents Important - Please read these instructions fully before operating or maintaining Safety Information............................3 Warning Symbols ..........................3 General Safety............................4 Personal Safety.............................4 Operating Safety............................6 Maintenance and Storage Safety......................7 Intended Use............................7 Service..............................7 In the Box ..............................8 Assemble the Pressure Washer........................9 Preparing to Operate the Pressure washer....................10 Operating the Pressure Washer........................13 Maintenance and Repair...........................17...

  • Page 3: Safety Information

    Safety Information Important - Please read these instructions fully before operating or maintaining Warning Symbols The following warning symbols appear through this manual and indicate the appropriate safety measures you should take when operating and maintaining the pressure washer. Warning Read the instruction manual Conforms to all relevant safety standards.

  • Page 4: General Safety

    Safety Information Important - Please read these instructions fully before operating or maintaining General Safety IMPORTANT! - Keep this instruction manual in a safe place for future reference. - Read the instructions carefully. Be familiar with the controls and the proper use of the equipment.
  • Page 5 Safety Information Important - Please read these instructions fully before operating or maintaining Personal Safety (continued) - High-pressure jets can be dangerous if misused. The jet must not be directed at persons, animals, electrical equipment or the appliance itself. - Know how to stop the product and bleed pressure quickly, be thoroughly familiar with the controls.

  • Page 6: Operating Safety

    Safety Information Important - Please read these instructions fully before operating or maintaining Operating Safety (continued) - Water that has lown through backlow preventers is considered to be non-potable. - The PVC or polychloroprene sheathed power cord, or extension cables (H05VV-F) are acceptable for use at temperatures at or above 0 - Always ensure that a machine which has been switched off and cannot be restarted unintentionally.

  • Page 7: Maintenance And Storage Safety

    - to clean machines, vehicles, buildings, tools, facades, terraces, garden equipment etc. using a high-pressure water jet (and detergents if required). - to use with accessories, replacement parts and detergents approved by Qualcast. Observe the instructions provided with these detergents.

  • Page 8: In The Box

    In the Box Parts high pressure washer spray lance high pressure hose gun storage trigger gun handle screws 4pcs patio cleaner water inlet male connector extend lance for patio cleaner nozzle pin spiral spray lance manual If there are any parts missing, please call the customer helpline on 01904 727500 Customer Helpline 01904 727500 www.gardenservicecentre.co.uk...

  • Page 9: Assemble The Pressure Washer

    Assemble the Pressure Washer Preparing to assemble the pressure washer IMPORTANT! - Remove all parts of the pressure washer from the box and carefully remove all packaging. Take care not to lose any instructions which may be afixed to the parts. These provide important information which will be required while attached the pressure washer.

  • Page 10: Preparing To Operate The Pressure Washer

    Preparing to Operate the Pressure Washer Step 1 - Fit the high pressure hose to the washer WARNING! Always wear safety gloves when doing any work on the pressure washer. Remove the plastic cover and then connect the high pressure hose to the pressure washer. Attach high pressure hose to the machine’s water outlet (hand tighten only).
  • Page 11 Preparing to Operate the Pressure Washer Step 4 - Assemble inlet adapter. Attach the inlet adapter to the machine’s water inlet. Hand tighten only. Step 5 - Connect garden hose and inlet adapter. Before you attach your water hose (not included), run the water through to eliminate any air in the hose to avoid air locking.
  • Page 12 Preparing to Operate the Pressure Washer Step 7 - Connect socket Make sure the ON/OFF switch is in the OFF position and your hands and plug are dry. Connect the plug to the mains socket. Note! We Recommend the use of a RCD Safety protection plug. Operate the Pressure Washer Step 1 - Starting WARNING!

  • Page 13: Operating The Pressure Washer

    Operate the Pressure Washer Step 2 - Stopping 1. Release the trigger, and replace the safety lock. 2. To switch the machine off, set the On/Off switch to OFF. Step 3 – Use the high pressure lance WARNING! - Always turn off the machine when changing the high pressure lance.-The trigger gun is subjected to a recoil force when the water jet is discharged.
  • Page 14 Operate the Pressure Washer Step 3 – Use the high pressure lance (continued) CAUTION! - Jet spray adjustment is very aggressive. Do not adjust while spraying. Switch the machine off when interrupting your work for extended periods of time. - The high-pressure pump starts running as soon as you operate the hand-held spray gun. The high-pressure pump stops running as soon as you release the trigger on the hand-held spray gun.
  • Page 15 Operate the Pressure Washer Step 4 – Use the detergent bottle WARNING! In case of contact with detergents: rinse with an abundance of clean water Always turn off the machine when changing the detergent bottle. 1. Unscrew the bottle cap of the detergent bottle. Fill the detergent tank with the relevant suppliers diluted recommended mixture level.

  • Page 16: Maintenance And Repair

    Operate the Pressure Washer Step 5 - Use the patio cleaner WARNING! Always turn off machine when changing the patio cleaner 1. Fit the patio cleaner (D) with the extended lance (E) to the trigger gun. 2. Turn on the pressure washer. Pull trigger to operate unit. 3.

  • Page 17: Maintenance And Repair

    Maintenance and Repair Maintenance and Repair(continued) - After every use wipe the machine with a slight damp cloth. Do not clean the machine using a high-pressure water jet. - Clean the high-pressure jet nozzle. The pressure washer is equipped with a water ilter to protect the pump. If the ilter is not kept clean, the water low to the machine will be restricted and the pump may be damaged.

  • Page 18: Troubleshooting

    Troubleshooting General Troubleshooting WARNING! - Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualiied specialist if you cannot solve the problem yourself! - Always turn off the machine and remove the plug before making any adjustment.

  • Page 19: Technical Data

    Technical Data Technical Data Table Voltage 230-240V~/ 50Hz Input power 1900W Max pressure 150bar Rated pressure 100bar Rated low 5.5l/min Max low 7l/min Inlet T Net weight 9.5 kg Measured sound pressure level 83dB (A), k=3 dB (A) Measured sound power level 92dB (A), k=3 dB (A) Guaranteed sound power level 94dB (A)

  • Page 20: Plug Replacement

    Recycling and Disposal Recycling and disposal (continued) This symbol is known as the Crossed out Wheelie Bin Symbol. When this symbol is marked on a product or battery, it means that it should not be disposed of with your general household waste.

  • Page 21: Getting Help

    Plug Replacement Plug Replacement (continued) CABLES IMPORTANT • Use only 1.00mm size cable up to 40 metres length maximum. Maximum rating: 1.00mm size cable, 10 amps 250 volts AC. • YOUR HIGH PRESSURE WAHSER IS SUPPLIED WITH CABLE WIRED DIRECTLY INTO THE PRODUCT.

  • Page 22: Guarantee

    Guarantee Dear Customer, In the unlikely event that your device develops a fault, please contact our Customer service department on the telephone number shown below. 1. These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. Claims must be accompanied by Proof of Purchase. This must be in the form of a Sales receipt or Bank statement and must show that the product has been purchased within 2 years prior to the claim, from the retailer that it was originally sold to.

  • Page 23: Declaration Of Conformity
