  • Page 1 User Guide 1910100108 REV1.0.0...

  • Page 2: Table Of Contents

    Contents About this guide Chapter 1 Get started 1. 1 Overview ..............1 1.
  • Page 3 5. 3 Manage conversations ........... . 17 5.
  • Page 4 Chapter 12 File Explorer 12. 1 View files (PIC, MUSIC, VIDEO, DOC, APK, ZIP) ....... 32 12.
  • Page 5 18. 3 Display..............43 18.

  • Page 6: About This Guide

    Description Convention Smart phone/phone Stands for C5 without any explanation. Parameters provided in the screenshots are just references for configuring the smart phone, which may be Parameters different from the actual situation. You can set the parameters according to your demand.

  • Page 7: Chapter 1 Get Started

    Get started This chapter introduces the smart phone’s hardware information and guides you how to assemble your phone when you get started on using your new phone. • Overview • Assemble your device • Power on • Charge your device 1.

  • Page 8: Power On

    Insert Micro SIM cards and MicroSD card (optional) Carefully slide the cards into the card slots with the gold contacts facing down. Since your phone is a dual SIM phone, you can use one or two SIM cards by putting them in the corresponding card slots. Note: The device uses Micro SIM cards.
  • Page 9 When the battery is full, unplug the power adapter from the power outlet and remove the USB cable from your phone. Get started Chapter 1...

  • Page 10: Chapter 2 Basics

    Basics This chapter introduces the smart phone’s basic feature. • Touchscreen gestures • Unlock and lock the screen • Home screen • Status icons • Quick settings panel • Notification panel • Enter a text 2. 1 Touchscreen gestures Touch: Simply tap an item to select or launch it. Touch and hold: Touch and leave your finger on the screen for 2 seconds or more to activate onscreen items.
  • Page 11 Swipe: Place your finger on the screen, and drag your finger to the direction you want. For example, you can swipe to scroll through the Home screen or a menu. Drag: To drag, touch and hold an item and then move it to a new position. For example, you can rearrange a widget on the home screen.

  • Page 12: Unlock And Lock The Screen

    Zoom out: Pinch two fingers together on the screen. For example, pinch two fingers together to zoom out while viewing a picture or a web page. 2. 2 Unlock and lock the screen Use the screen lock features to secure your phone. •...

  • Page 13: Home Screen

    2. 3 Home screen Status bar Widget APP screen indicator APP shortcuts Status bar: Status and notification icons are displayed in the status bar. Widget: Self-contained applications that run on the Home screen (not shortcuts). APP screen indicator: Indicates which screen is being displayed. APP shortcuts: Shortcuts to your favorite applications.

  • Page 14: Quick Settings Panel

    Airplane mode enabled Bluetooth enabled Download status Uploading data Synchronizing data GPS enabled Alarms enabled Call in progress Missed calls New messages New emails Headset plugged in System update is available. 2. 5 Quick settings panel Swipe down from the top of any screen twice to open the quick settings panel. Note: On the lock screen, swipe only once to open the quick settings panel.

  • Page 15: Notification Panel

    11. Screen shot: Tap to select the screen shot type. 12. Cast screen: Tap to share the display on your phone with your TV or other devices. For more information, Cast screen. 2. 6 Notification panel Swipe down from the top of any screen to open the notification panel. Tap an item to view the details.
  • Page 16 Tap and hold or quickly tap twice to enable caps lock. Tap to switch to numbers and symbols. Tap to enter a comma. Tap and hold to open the input options menu. Tap to enter a space. Tap to enter a period. Tap and hold to enter a symbol.

  • Page 17: Chapter 3 Connection

    Connection This chapter contains the following sections. • Connect to WLAN • Connect to computer • Bluetooth • Tethering & portable hotspot 3. 1 Connect to WLAN Option One Swipe down from the top of any screen (except for the Lock screen) twice to open the quick settings panel.

  • Page 18: Tethering & Portable Hotspot

    Tap the switch to turn it on and find the device you want to connect, then follow the on-screen prompts to complete the connection. Option Two On the Home screen, tap Settings -> Bluetooth. Tap the switch to turn it on. Tap the device you want to connect.

  • Page 19: Chapter 4 Calls

    Calls This chapter contains the following sections. • Make a call • Answer & end a call • Options during a call • Call log • Call settings 4. 1 Make a call Dial directly by entering numbers On the Home screen, tap Phone ->...

  • Page 20: Answer & End A Call

    After connected, tap -> Add call to call the second participant. The first participant will be placed on hold. When the second participant is connected, tap -> Merge calls to start a conference call. Make a call using speed dial Using speed dial, you can call someone quickly by dialing a shortcut number instead of the original number.

  • Page 21: Call Log

    Place a new call while in a call You can make another call while a call is in progress. While making a call with others, tap Add call on the calling screen. -> Enter another phone number or choose another contact, then tap to dial.

  • Page 22: Call Settings

    Tap OK in the pop-up window on your phone screen. Add a call to the reject list If you have added a caller to your reject list, future calls from this caller will be sent directly to your voicemail. Go to Phone ->...

  • Page 23: Chapter 5 Messages

    Messages This chapter contains the following sections. • Type of messages • Send & receive messages • Manage conversations • Message settings 5. 1 Type of messages Text Messages (SMS) The Short Messages Service (SMS) lets you send and receive text messages to and from other mobile phones. Multimedia Messages (MMS) The Multimedia Messaging Service (MMS) lets you send and receive multimedia messages (such as pictures, videos, and audio messages) to and from other mobile phones.

  • Page 24: Message Settings

    Forward messages On the Home screen, tap Messages. In the list of message threads, tap a contact name or phone number to view the conversation thread. Tap and hold the message you want to forward and then tap Forward. Enter a phone number directly or to select a contact, then tap to send out the message.
  • Page 25 • Mute: Tap to select the time you need. • Sound: Tap to select the sound when you receive a new message. • Vibrate: Check the option to make the phone vibrate when notifications received. • Popup notification: Check the option to show popup for push notifications. General settings •...

  • Page 26: Chapter 6 Contacts

    Contacts This chapter contains the following sections. • Manage contacts • Import/Export contacts • Groups • Contacts settings 6. 1 Manage contacts Add a contact On the Home screen, tap Contacts. Enter the contact’s information. Add new contact to save. Edit a contact On the Home screen, tap Contacts.

  • Page 27: Import/Export Contacts

    6. 2 Import/Export contacts Import/export contacts from phone/storage On the Home screen, tap Contacts -> -> Import/Export. Select the place you want to copy the contacts from and the place you want to copy them to, then tap Next to keep following the pop-up prompts. Share contacts On the Home screen, tap Contacts.

  • Page 28: Chapter 7 Emails

    Emails This chapter contains the following sections. • Set up your email accounts • Send and check emails • Email settings 7. 1 Set up your email accounts Set up your email accounts to manage your email more conveniently. Add an email account On the Home screen, tap Mail.
  • Page 29 Remove your email account On the Home screen, tap Settings -> Accounts -> Personal ( IMAP). Tap the account you want to remove, then tap -> Remove account. Manage your folders • Inbox: All received emails are saved in this folder. •...

  • Page 30: Chapter 8 Camera And Video

    Camera and video This chapter contains the following sections. • Get to know camera • Take a photo • Record a video • Gallery • Video Player 8. 1 Get to know camera Launch the camera app • On the Home screen: Tap Camera.

  • Page 31: Take A Photo

    Tap to take a photo. 8. 2 Take a photo to choose camera mode, then tap the or press either volume button to take a photo. If you want to take a selfie, please tap to switch to selfie mode. Shooting mode to choose the shooting mode.

  • Page 32: Gallery

    8. 4 Gallery View photos On the Home screen, tap Gallery. Choose an option to view your photos. • Photos : View the photos in a timeline. • Albums: View the photos grouped by albums. • Collections: Create a new album and then you can view the photos grouped by your selection. Edit a photo Select the photo you want to edit.

  • Page 33: Chapter 9 Calendar

    Calendar This chapter contains the following sections. • Use the calendar • Calendar settings 9. 1 Use the calendar View the calendar On the Home screen, tap Calendar. at the top of the screen to select Day, Week, Month and Agenda to switch the calendar view. Create an event On the Home screen, tap Calendar.

  • Page 34: Chapter 10 Clock

    Clock This chapter contains the following sections: • Alarm • Clock • Timer • Stopwatch 10. 1 Alarm Create an alarm On the Home screen, tap Clock -> Alarm -> to create a new alarm. Scroll down to configure: • Time: Choose a time for the alarm. •...

  • Page 35: Stopwatch

    Tap START to start the countdown. You can tap STOP and CONTINUE to control the timing, or tap RESET to finish the countdown. 10. 4 Stopwatch Stopwatch contributes to recording precise time. On the Home screen, tap Clock -> Stopwatch. Tap START to start counting.

  • Page 36: Chapter 11 Browser

    Browser This chapter contains the following sections. • Go to a webpage • Browser tabs • Bookmarks • History 11. 1 Go to a webpage View a website On the Home screen, tap Browser, then tap the address bar on top of the page and enter the web address you want to visit.

  • Page 37: Browser Tabs

    • Find on page: Tap to enter a key word to find its place. • Request desktop site: Check the option to turn the page to a desktop site. • Bookmarks/History: Tap to see your bookmarks and visited histories. • Settings: Tap to configure the browser settings. 11.

  • Page 38: Chapter 12 File Explorer

    File Explorer This chapter contains the following sections. • View files (PIC, MUSIC, VIDEO, DOC, APK, ZIP) • Manage your files • Options for selected files or folders 12. 1 View files (PIC, MUSIC, VIDEO, DOC, APK, ZIP) On the Home screen, tap File Explorer.
  • Page 39 Tap and hold the folder and tap . Select the folder you want to copy to and tap . Cut a folder File Explorer -> Phone. Find the folder you want to remove. Tap and hold the folder and tap . Select the folder you want to store into and tap .

  • Page 40: Chapter 13 Weather

    Weather This chapter contains the following sections. • Add a city • Check the weather • Remove a city • Update the weather 13. 1 Add a city Add a city to check its real-time weather information. From the Home screen, tap Weather to log into the Weather interface.

  • Page 41: Chapter 14 Music

    Music This chapter contains the following section. • Get to know music 14. 1 Get to know music Launch the Music app On the Home screen, Tap Music. The music library will scan each song on your phone storage and SD card and then displays them in Songs, Albums, Artist and Playlists.
  • Page 42 Enter the playlist name and tap SAVE. Select the songs you want to add in this playlist. Tap Done to complete it. Music library settings On the Home screen, tap Music. to set the following options: • Shake: Tap to turn it on, then you can shake your phone to switch songs. •...

  • Page 43: Chapter 15 Notes

    Notes This chapter contains the following sections. • Compose a note • Note options 15. 1 Compose a note On the Home screen, tap Notes -> and begin composing your new note. When finishing composing, tap Done to save the note. 15.

  • Page 44: Chapter 16 Applications

    Applications This chapter contains the following sections. • Manage applications • Google applications 16. 1 Manage applications Download applications from • Play Store • Phone browser • Computer browser Install an application On the Home screen, tap File Explorer. Tap APK to view all the application files. Select the application you want to install and follow the pop-up prompts.
  • Page 45 Drive Use Drive to open, view, rename, and share your Google Docs and files. Play Music With Google Play Music, you can play music from local file or copied from your computer. Play Movies & TV Watch movies and TV shows purchased from Google Play. You can stream them instantly, or download them for viewing when you’re not connected to the Internet.

  • Page 46: Chapter 17 Tools

    Tools This chapter contains the following sections. • FM Radio • Flashlight • Sound Record • Mirror • Calculator • Downloads • System Update • Feedback • Compass • Photo Editor 17. 1 FM Radio Scan stations Connect a headset to the phone. On the Home screen, tap Tools ->...

  • Page 47: Mirror

    17. 4 Mirror On the Home screen, tap Tools -> Mirror to use your screen as a mirror. to choose the brightness you need. 17. 5 Calculator On the Home screen, tap Tools -> Calculator. Tap numbers and use the arithmetic feature to complete an operation. 17.

  • Page 48: Chapter 18 Settings

    Settings This chapter contains the following sections. • SIM cards • Airplane mode • Display • Cast screen • Sound and notification • Storage • Battery • Apps • Location • Security • Accounts • Language and input • Backup and reset •...

  • Page 49: Display

    18. 3 Display On the Home screen, tap Settings -> Display You can set the following options. • Brightness level: Tap to adjust screen brightness. • Adaptive brightness: Tap to enable optimizing brightness level for available light. • Wallpaper: Tap to set the wallpaper. •...

  • Page 50: Storage

    • When device is locked: Tap to choose show all notification content or don’t show notifications at all. • App notification: Set notification sounds for applications. • Interruptions: Tap to set the interruptions for calls and notifications. • Default notification ringtone: Set default notification ringtone. •...

  • Page 51: Language And Input

    On the Home screen, tap settings. Accounts. Tap Add account. Select an account type. Follow the pop-up prompts to set up the account. Synchronize accounts On the Home screen, tap settings. Accounts. -> Auto-sync data to turn it on. Delete an account On the Home screen, tap settings.

  • Page 52: Backup And Reset

    • Bluetooth headset: Tap to enable the phone to record audio through Bluetooth headset if available. 18. 13 Backup and reset You can back up your data to Google servers or reset your phone to its factory defaults. Back up your data On the Home screen, tap Settings.

  • Page 53: About Phone

    18. 17 About phone Use About phone to know more information about your phone including your phone’s status, model, android version, baseband version and so on. On the Home screen, tap Settings. Tap About phone. Settings Chapter 18...

  • Page 54: Appendix A: Specifications

    Appendix A: Specifications Specifications Height: 144mm Width: 72mm Size and Weight Depth: 8.8mm Weight: 141 g Color Pearl White/Dark Grey 5.0 inches IPS Display HD1280* 720 293.7PPI MTK MT6735 4x Cortex-A53 1.3GHz GPU: ARM Mali-T720 MP2 450Mhz ROM: 16 GB Memory RAM: 2 GB Memory Slot...
  • Page 55 GSM: band (2/3/5/8) WCDMA: band (1/2/4/5) FDD-LTE: band (2/4/7/28) TP701E: GSM: band (2/3/5/8) WCDMA: band (1/8) Navigation GPS/GLONASS Cloud Service Supported Operation System Android 5.1 TP-LINK Neffos C5 Charger USB Cable In the box Quick Start Guide Headset Warranty card Battery 2200mAh...

  • Page 56: Appendix B: Technical Support

    Appendix B: Technical Support Contact our technical support if you have any questions related to this product. Support Countries/Regions Tel: +86 755 26504400 (English Service) Fee: Depending on rate of different carriers, IDD. Global E-mail: support@neffos.com(English Service) Service Time: 24 hours a day, 7 days a week. Germany Pearl White/Dark Grey Tel: +390221116579...
  • Page 57 Support Countries/Regions Toll Free:1800 2094 168 India E-mail:support.in@neffos.com Service Time:10:00AM to 6:00PM, Monday to Saturday. Local No.: (+62) 021 63861936 E-mail: support.id@neffos.com Indonesia Service Time: 09:00AM to 12:00AM & 01:00PM to 06:00PM, Monday to Friday. Tel: + 60 (3) 2141 4358 (Mon-Sun, 10.30am-8.00pm) Malaysia E-mail: support.my@neffos.com Service Time: 24 hours a day, 7 days a week...
  • Page 58 No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2016 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 59: Fcc Compliance

    FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 60: Legal Notice

    Copyright © 2016 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved. Trademarks and permissions is trademarks or registered trademarks of Neffos Limited. TP-LINK is responsible for Neffos. Android is a trademark of Google Inc. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Neffos Limited is under license.

  • Page 61: Privacy Policy

    DISCLAIMER ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

  • Page 62: Traffic Security

    Areas with flammables and explosives • Turn off your device in potentially explosive environments instead of removing the battery. Always comply with regulations, instructions and signs in potentially explosive environments. • Do not use your device at refueling points (petrol stations), near fuels or chemicals, or in blasting areas. •...

  • Page 63: Charger Safety

    • Using generic batteries or chargers may shorten the life of your device or cause the device to malfunction. They may also cause a fire or cause the battery to explode. • TP-LINK cannot be responsible for the user’s safety when using accessories or supplies that are not approved by TP-LINK.

  • Page 64: Cleaning And Maintenance

    • If you notice strange smells or sounds coming from your device or the battery, or if you see smoke or liquids leaking from the device or battery, stop using the device immediately and take it to a TP-LINK Service Centre.

  • Page 65: Eu Regulatory Conformance

    To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling.

  • Page 66: Declaration Of Conformity

    TP-LINK TECHNOLOGIES CO , LTD DECLARATION OF CONFORMITY We, TP-LINK TECHNOLOGIES CO., LTD., Address: Building 24 (floors 1,3,4,5) and 28 (floors1-4) Central Science and Technology Park, Shennan Rd, Nanshan, Shenzhen, China Declare under our own responsibility that the product: Model: TP701/A/B/C/E...
