- Page 1 The Future of Home Entertainment USER MANUAL DG-HD19LCDVD/DG-HD22LCDVD Hills. Hills. A clever A clever product product...
-
Page 2: Table Of Contents
Contents NEED HELP?............. TV................Safety precaution..................Accessories....................Remote control manual................. Remote control functions................LCD TV panel overview................Connecting to external devices..............The OSD menus..................DVD................ Basic operation..................Supporting DVD format................DVD Functions operating instructions............MP3/JPEG Playback................Function Settings..................Trouble shooting..................Maintenance.................... -
Page 3: Need Help
NEED HELP? If you are experiencing difficulty operating this product or require set up assistance please contact the DGTEC Service Centre. The call is free from anywhere in Australia. Our operators will assist you in plain English without the technical jargon:... -
Page 4: Safety Precaution
1.Safety precaution Notes: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insinuated WARNING dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:... -
Page 5: Accessories
SAFETY WARNINGS Before using this product, read and follow all warnings and instructions. This product is not intended for use by young children. Young children should be properly supervised. This product is intended for household use only and not for commercial or industrial use. -
Page 6: Remote Control Manual
3.Remote control manual Power button Mute button Sleep button Numeric button SUBTITLE/Return channel button ASPECT/DVD 10+ button ASPECT Picture mode button Sound mode button TV setup menu Signal source selection button ENTER LEFT RIGHT DOWN Volume adjusting button Channel selection button Information button DVD SETUP/Favourite button Open/Close/Exit the OSD... -
Page 7: Remote Control Functions
4.Remote control functions POWER: Power on/off button , press once to turn the TV on and press again to turn the TV off. SLEEP: Sleep button , sets TV power off time. MUTE: Mute button , press once to disable the audio and press again to enable the audio. 0,1-9: TV channel selection button. -
Page 8: Lcd Tv Panel Overview
TV Control Panel VOL- VOL+ MENU SOURCE POWER 1.Volume adjusting. 2.Channel selecting. 3.Main menu display and confirm. 4.Selecting exterior signal input. 5.On/off button. DG-HD19LCDVD 1.OPEN/CLOSE button 2. NEXT button 3.PLAY/PAUSE 4.PREV button 5.STOP button DG-HD22LCDVD 1.STOP button 2.PREV button 3.PLAY/PAUSE 4.NEXT button... - Page 9 TV Terminal connections DG-HD19LCDVD VIDEO AUDIO RF(75 S-VIDEO DC-12V HDMI S-VIDEO input. DC 12V power input. HDMI input. VGA input. Component input terminal. AV input . PC audio input. Headphone output. Antenna input (75 Ohm VHF/UHF). DG-HD22LCDVD POWER RF(75 S-VIDEO...
-
Page 10: Connecting To External Devices
6.Connecting to external devices Connecting external devices to your LCD TV HDMI The rear of TV YPBPR S Video DG-HD19LCDVD VIDEO AUDIO RF(75 S-VIDEO DC-12V HDMI Notes: VGA use a common PC AUDIO in. -
Page 11: The Osd Menus
7.The OSD menus Menu Setup TV (First time installation wizard) Initial Setup Welcome Welcome to use the Wizard for Initial Setup !! Please press [OK] to start the 1. Turn on TV, Then press"OK" to wizard. start the wizard Language Initial Setup Please select your Language: English... -
Page 12: Video Menu
Menu Operation Under TV Input 1 VIDEO MENU Picture Mode Standard Brightness a. The image on the left depicts the OSD menu. Contrast Saturation b. The definition of each option: Sharpness Color Temperature b-1. Picture Mode: Changes the picture mode Strong in sequence : Stand ard Mil d Vivid Hi-Bright User... -
Page 13: Audio Menu
2 AUDIO MENU Sound Mode Standard a. The image on the left depicts the audio Balance Bass menu. Treble b. The definition of each option: b-1. Sound Mode: Changes the Sound Mode in sequence as: Standard Pop Adjust Audio Select EXIT Exit Rock News. -
Page 14: Digital Channel Range Scan
Digital Channel Range Scan Digital Manual Scan Manual Scan:Press"OK"to enter Manual Scan, Analog Manual Scan Select one of the following options: Digital Channel Range Scan,Digital Manual Scan,Analog Manual Scan. Enter Select EXIT Exit Manual Scan Scan with a range of channels Digital Channel Range Scan:Press"OK"to enter Digital Channel Range Scan. -
Page 15: Setup Menu
4 SETUP MENU OSD Language English Display Mode 16:9 a. The image on the left depicts the setup Time Setup Subtitle menu. Teletext Blue Screen b. The definition of each option: Reset Default b-1. OSD Language: Changes the OSD Language in sequence as: English, Enter Select EXIT Exit... -
Page 16: Parental Menu
OSD Language English Display Mode 16:9 b-6. Blue Screen: press key to enter Time Setup Subtitle Blue Screen(On/Off). Teletext Blue Screen Reset Default Enter Select EXIT Exit Setup Password b-7. Reset Default: Press key to this position, then press key to enter Default Password is "0000". -
Page 17: Dvd
b-3.Input block: you can block any input source. S-VIDEO YPBPR HDMI Select Input Block EXIT Exit New Password Confirm Password b-4.Change password: changing of the parental password. Change Password EXIT Exit b-5.Clear All Blocks: restore your Are you sure? Cancel settings. - Page 18 DVD Operation DVD Operation...
-
Page 19: Basic Operation
Basic operation Basic operation 1.Turn on the LCD TV and then press SOURCE repeatedly to select DVD mode. 2. Insert Disc to DVD player - Insert the Disc in the Disc slot (Data side of the disc has to face towards front of the unit), the player will load the disc automatically. -
Page 20: Supporting Dvd Format
Supporting DVD format Supporting DVD format This product can play the following DVD formats disc. Disc Type Disc Size (Diameter) Recorded Time Recorded Content Remarks DVD format: Single side:120mins. Approx Compressed digital 12cm Double side:240mins. Approx audio and video MPEG2 Super VCD 45mins. -
Page 21: Dvd Functions Operating Instructions
1. Play (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs) - For DVD disc, press button from root or title menu; when playing the DVD, you may play your favourite title directly with title selection by pressing the TITLE button. - For Super VCD &... - Page 22 For DVD discs, Press INFO button once to display first page as shown below: Disc Type Chapter -/-(Current/Full) Elapsed disc time Tiltle -/- (Current/ Full) INFO Press the button again to display the second page shown below: Audio Language Audio Type Angle ON/OFF -/- (Current/ Full) or OFF Subtitle -/-(Current/Full)or OFF...
-
Page 23: Mp3/Jpeg Playback
10. Mute (for DVD/ Super VCD/ VCD/ CD/ CD-G/HD-CD and Mp3/ JPEG discs) - Press MUTE button to mute the audio output. There will be an on screen symbol indicating “MUTE”. Press again to cancel, or Press VOL+/VOL - to cancel and adjust the volume. - In case there is no audio output, press MUTE button to cancel mute. -
Page 24: Function Settings
NOTE: - Press buttons to move the highlight to folders, documents or mode selections. - Press numeric buttons to select the content directly. For number over 10, press -/-- button first. (e.g. File number 15, press -/-- then 5.) - With MP3 playback, there is no picture display, only audio output. - When playing or pausing a picture , you may use navigation buttons to flip / rotate the picture. - Page 25 PARENTAL TV Type DVDs are produced in a variety of screen aspect ratios. This menu enables you to select one of the three aspect ratios: 4:3 PS (Normal) 4:3 LB (Normal) 16:9 (Wide) PARENTAL - Select the most appropriate aspect ratio for the DVD being viewed.
- Page 26 NOTE: Only editable when password is unlocked, and functional when password is locked. PARENTAL Default Setting PARENTAL - Press ok button to restore factory default. Language Setup Language Setup Press SETUP button to enter the DVD OSD menu. OSD Language Use navigation buttons to select the OSD LANGUAGE setup icon, press OK button to confirm.
- Page 27 NOTE: If the selected language is not included in you DVD disc content, it will select the default language of the disc automatically. The default language setting is English. MENU Language FRENCH SPANISH GERMAN ITALIAN - Use navigation buttons to select the MENU LANG setup icon, press OK button to confirm.
- Page 28 Dolby Digital Setup Dolby Digital Setup Dynamic Range - When switching the compressed mode to “Audio output”, adjust switching from the compress ratio for different effect. When selecting FULL, the peak signal value is smallest. When selecting OFF, the peak signal value is biggest.
-
Page 29: Trouble Shooting
Trouble shooting Trouble shooting Before contacting the service technician, perform the following simple checks. If any problem still persist, please contact DGTEC technical support on 1800 189 941. PROBLEM PROBLEM POSSIBLE SOLUTION POSSIBLE SOLUTION - Check that the main plug has been connected to the mains. -
Page 30: Maintenance
NOTE: The troubleshooting suggestions below apply only when LCD is set to VGA mode. NOTE: The troubleshooting suggestions below apply only when LCD is set to VGA mode. PROBLEM PROBLEM POSSIBLE SOLUTION POSSIBLE SOLUTION - Adjust resolution, horizontal frequency, or vertical frequency. The signal is out of range. -
Page 31: Specifications
Specifications Panel Features Screen Size 19 inch 408mm(H) X 255mm(V) Active Area Aspect Ratio 16:10 Panel Resolution 1440 X 900 Brightness 300 cd/m² 700:1 Contrast Ratio Viewing Angle 170º(H) X 160º (V) 0.283mm(H) X 0.283mm(V) Dot Pitch Maximum Colour 16.7M Response Time Black-White (R&D) OSD Languages English, French Spanish German Italian... - Page 32 Panel Features Screen Size 22 inch 473.76mm(H) X 296.1mm(V) Active Area Aspect Ratio 16:10 Panel Resolution 1680 X 1050 Brightness 300 cd/m² 700:1 Contrast Ratio Viewing Angle 170º(H) X 160º (V) 0.282mm(H) X 0.282mm(V) Dot Pitch Maximum Colour 16.7M Response Time Black-White (R&D) OSD Languages English, French Spanish German Italian TV Function...
