SPLIT-TYPE, AIR CONDITIONERS
INDOOR UNIT
SERVICE MANUAL
Wireless type
Models
MS-GA50VB -
MS-GA60VB -
MS-GA80VB -
NOTE:
This service manual describes technical data of the indoor units.
RoHS compliant products have <G> mark on the spec name plate.
For servicing of RoHS compliant products, refer to the RoHS PARTS LIST (RoHS compliant).
Revision B :
• Indoor heat exchanger of MS-GA80VB -
• PARTS LIST and RoHS PARTS LIST have been changed.
Please void OB369 REVISED EDITION-A.
E1
E1
E1
CONTENTS
1. TECHNICAL CHANGES ····································2
2. PART NAMES AND FUNCTIONS······················2
3. SPECIFICATION·················································4
4. NOISE CRITERIA CURVES ·······························5
5. OUTLINES AND DIMENSIONS ·························6
6. WIRING DIAGRAM ············································7
7. REFRIGERANT SYSTEM DIAGRAM ················8
8. SERVICE FUNCTIONS ······································9
9. TROUBLESHOOTING······································11
10. DISASSEMBLY INSTRUCTIONS·····················19
11. PARTS LIST······················································21
12. RoHS PARTS LIST···········································23
13. OPTIONAL PARTS···········································25
has been changed.
E1
No. OB369
REVISED EDITION-B
Outdoor unit service manual
MU-GA•VB Series (OB370)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-GA50VB and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric MS-GA50VB

Summary of Contents for Mitsubishi Electric MS-GA50VB

  • Page 1: Table Of Contents

    SPLIT-TYPE, AIR CONDITIONERS Please void OB369 REVISED EDITION-A. INDOOR UNIT No. OB369 SERVICE MANUAL REVISED EDITION-B Wireless type Models MS-GA50VB - MS-GA60VB - MS-GA80VB - Outdoor unit service manual MU-GA•VB Series (OB370) CONTENTS 1. TECHNICAL CHANGES ····································2 2. PART NAMES AND FUNCTIONS······················2 3.
