ZO
Know your
Output Jack
Charge Status
Indicator
USB Charging Port
Neutralize the Source
When initially connecting your ZO to any audio source, you must start
with neutral source equalizer settings as indicated below...
For portable media devices, turn off all built-in equalizer settings which are
typically found in the device's main menu.
For computers, turn off all software-related equalizers, which are normally
accessed through the audio player's main menu. If it is accessible, turn off
any equalizer functions which may be associated with the computer's sound
card.
When connecting to a car stereo, set the bass the treble to its neutral setting
(between min and max).
If you are connecting ZO through an aftermarket car stereo, turn off all sound
effect functions and set the equalizer to the "flat" preset.
Be sure to turn the volume of your source down to about 25% before using the
ZO! If using Line-out, be sure to turn the volume of the ZO all the way down,
and do not use standby mode.
ZO
2
ZO
2
Input Jack
SmartVektor
Controller (SVC)
™
Turns ZO on/off, triggers standby
mode, controls sound contouring
and volume level adjustments
LightScale Display
Colored LED displays the
selected contour & volume
levels, and secondary LED
blinks when battery is low
Pg 1
digiZoid.com
Advertisement
Table of Contents
Related Manuals for Digizoid zo
Summary of Contents for Digizoid zo
- Page 1 “flat” preset. Be sure to turn the volume of your source down to about 25% before using the ZO! If using Line-out, be sure to turn the volume of the ZO all the way down, and do not use standby mode.
- Page 2 Connect the mini-end of the supplied USB charging cable to ZO’s charging port, and the other end to your computer’s USB port. When in charging mode, the charge status indictor light will glow red. Once ZO is fully charged (about 1 hour), the light will automatically deactivate. Accessories 3.5mm Stereo Cable This cable connects your ZO to an audio source.
- Page 3 To turn your ZO off, push in & hold the SVC until the light goes off. Changing Contour Level with the SVC When your ZO is turned on for the first time, the SVC will be set at the median contour level, and the LightScale indicator will illuminate an amber color.
- Page 4 Do not connect ZO to a mono channeled system. Do not use ZO in a double-amplification configuration (i.e., do not use ZO with another headphone amplifier). Troubleshooting If your ZO does not turn on, ensure...
