INDEX INDEX ............................. 3 Precautions ........................... 5 1. Important Safety Instructions...................... 5 2. Notice ............................5 3. Copyright ............................ 6 4. Disclaimer........................... 6 5. Trademarks ..........................6 Before You Begin ........................7 1. Main Features ..........................7 2. Accessories ..........................8 Hardware Description......................
Page 4
PVR (Personal Video Recorder) Function ................ 23 1. Recording ..........................23 1.1 Recording methods ......................23 1.2 Recording Edit........................25 1.3 Long Time recording ......................25 1.4 Pause during recording .......................25 2. Time Shifting..........................27 3. Playback (Play List)........................28 3.1 Recorded Files ........................28 3.2 Imported Files ........................29 3.3 Music ...........................29 3.4 Photo ...........................29 4.
Precautions 1. Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Do not alter the mains plug in any way. If the provided plug does not fit consult an electrician for replacement of the obsolete outlet. ...
To reduce the risk of electric shock, do not remove the cover (or back). No user serviceable parts are inside. Refer servicing to qualified service personnel. The Lightning Flash with arrowhead symbol The exclamation point within an within an equilateral triangle, is intended to equilateral triangle is intended to alert alert the user to the presence of un‐insulated the user to the presence of important "dangerous voltage" within the product operating and maintenance enclosure that may be of sufficient magnitude (servicing) instructions in the to constitute a risk of shock to persons literature accompanying the product 3. Copyright This manual is protected by copyright laws. Copy, use and reproduction of this manual in part or whole without Manufacturer’s prior written approval are prohibited. 4. Disclaimer The manufacturers, distributors and agents are not liable to any kind of damage caused by the use of the information contained in this manual. ...
Before You Begin 1. Main Features Supports MPEG4 /MPEG2 ‐ HD/SD and Fully DVB‐S2 /DVB‐S Compliant Intelligent Blind Scan for both SD and HD TV & Multi‐Satellite Search Multi‐LNB Controlled by DiSEqC Control Version 1.0, 1.1, 1.2 and USALS HDTV PVR Receiver ( H.264/ MPEG4 HD ) Embedded Linux OS Time Shifting, Recording & Playback with External HDD (USB 2.0) Simultaneously Records upto 3 Channels and allows Viewing of 2 others (PIP) on the same Transponder Powerful Extended EPG supports Event Recording USB 2.0 Host port (MP3 Player & JPEG Viewer) ...
Hardware Description 1. Front Panel Configuration POWER BUTTON : Press to switch between STANDBY and POWER ON modes. CH Up/Down BUTTON : Press to change services in normal mode, or to move highlighted‐bar in menu mode. STANDBY / REMOTE Indication LED (RED/GREEN) : The LED is Red when the receiver is in Standbay Mode. The LED is GREEN when the Remote is in use. Remote Sensor : Receives commands from remote controller. ...
2. Rear Panel Configuration 1. IR extension: The 2.5mm plug of the IR Extension can be connected to the “IR Jack”, when connected the front panel IR function is replaced by the IR Extension. 2. Common Interface Slot: A CA Module can be inserted (e.g. Irdeto, Viaaccess, Nagravision etc) and when used with a viewing card from a Pay TV service provider, pay TV channels can be viewed. 3. Smart Card Reader : When used with a CONAX viewing card from a Pay TV service provider pay TV channels can be viewed. 4. LNB IN: Connects to a satellite antenna cable. 5. LNB OUT: Connects to another STB for loop‐through. 6. RS‐232C : Serial port for firmware update and data transfer. 7.
3. Remote Control Unit 1. POWER : Turns the STB On/Off. 2. MUTE/Resolution : Turns the sound On/Off, and allows selection of the video format by pressing and holding the button in, pressing exit will return to the key to the mute function. 3. Numeric : Allows numerical data entry and changing of services directly. 4. Subtitle : To show subtitles. 5. Teletext : To show the digital teletext. 6. OK or Service List : Show the service list in non‐menu mode and select an item or confirm in menu mode. 7. ARROW Buttons a. Up & Down Buttons : To change the value of a selected item with preprogrammed values in menu. b. Left & Right Buttons : To move the cursor left and right in menu. 8. Menu : To enter the main menu or to move to the previous menu. 9. EXIT : Exit from the menu or pop‐up window. 10.
Page 12
11. Favorite : To display the satellite group and the favorite groups. 12. EPG(Electronic Program Guide) : Shows the TV/Radio program guide. 13. Recall : Moves to previous state. 14. Volume Up & Down : To change the Volume 15. Play / Time shift : Display the progress bar during playback when no progress bar is displayed. It starts playback at normal speed. It also returns to normal speed from trick mode.. 16. Channel Up & Down: To change service channel. 17. Pause : This key is used to pause the video. Press once more to resume the video. 18. Rewind : Rewinds at high speed. Each time you press this button the rewind speed is increased. 19. STOP : To stop time shifting, play back or recording. 20. Fast Forward : Fasts forwards at high speed. Each time you press this button the speed is increased. 21. Previous File : Used to play the previous MP3 file in MP3 play mode. This button is also used to jump back to beginning of recording during playback. 22. Recording : To start Recording 23. Next File : To play the next file. This button is also used to jump to end of recording during a playback ...
Page 13
24. Color Buttons a. RED : Used for special functions in the menu. The RED key is used to sort lists in the service list or go to previous day search in the EPG or make/delete the current position as a bookmark. b. GREEN : Used for special function in menu. The Green key is used to set the favorites setting in the service list or go to the next bookmark position. c. YELLOW : Used for special functions in the menu. Yellow key is used to find services in the service list or change the audio track. d. BLUE : Used for special function in the menu. The Blue key is used to set service list options in the service list or display Multi‐Picture. 25. Page Up& Down : Move to the next or previous page if more than one page are available. This button also is change the location of sub picture in PIP. 26. TV/RADIO : Switches between TV and Radio. 27. Information : Shows the channel infobox, if you press it again you will see more detailed information. 28. PIP Buttons a. PIP(Picture in Picture) : To activate the PIP window. b. PIP Swap : Switching between the main‐picture and sub‐picture c. PIP(Picture in Picture) Service List : To show the sub‐picture service list. ...
Connection diagram 1. Receiver to A/C power Connect the A/C power cord between A/C power cord socket of receiver and A/C outlet. 2. Receiver to TV with Digital A/V Output Connect the HDMI Cable to the HDMI Connector of the TV. Connect the SPDIF Cable to the Digital audio input of the Digital Audio Equipment. NOTE : Depending on the A/V equipment you own, there are various ways you can connect the STB.
3. Receiver to TV with Analog A/V Output Connect the VIDEO and AUDIO L, R to VIDEO IN and AUDIO L, R IN of TV. NOTE : The composite connection(RCA cable) is recommended for analogue TVs You cannot view high definition video with composite video connector. 4. Connecting to Antenna Cable Using Single DISH : Connect the Satellite Antenna cable to LNB IN. ...
Page 16
Using a DiSEqC switch : Connect the cable from the DiSEqC switch to LNB IN. Using DiSEqC motor : Connect the cable from the DiSEqC motor to LNB IN. ...
Guide of Functions 1. Selecting a Service To select the desired service (channel), please refer to the instructions below. 1.1 Using CH UP/DOWN buttons You can navigate between services by pressing the CH UP/DOWN buttons. Whenever you press the CH UP(DOWN) button, current service will be changed to next/previous service.
1.4 Using Recent Service List To display the recent service list, press the RECALL button for a short time. To return to the previous service that you were watching, press RECALL button twice or for a longer time. ...
Press the EPG button, then the EPG menu will be displayed. Use the ARROW buttons to move to other services or to see previous/next guide. Press the EPG button once to view the full EPG with multi service list, and press it twice to view the additional EPG information of a specific channel service.
8. Subtitle You can select the language for Subtitles, if the program provides subtitle information. Press the SUBTITLE button on your remote control unit. Select the desired subtitle language then press the OK button. The subtitles will be displayed in the selected language at the bottom of the screen.
10. Teletext When the TELETEXT icon on the INFO Banner is displayed, press the TELETEXT button to view the teletext. 11. PIP (Picture in Picture) When you press the PIP button, a sub picture screen will appear on the main screen view. If you press the PIP button one more time, the primary picture and the sub picture will appear together side-by-side with the same size.
Page 22
If you press the PAGE UP/DOWN button, the location of the sub picture is changed. If you press the PIP SERVICE LIST button, you will see the list of services available for the sub picture. You can change the service of the sub picture from the service list shown.
PVR (Personal Video Recorder) Function 1. Recording You can select a recording storage device with the following sequence : Menu > Configuration > Recording Option > Record Device. The Default is ‘USB’. 1.1 Recording methods There are 3 type recording methods. (Instant Recording / Time Scheduled Recording / Event Scheduled Recording).
Page 24
Event Scheduled Recording via EPG : - In the EPG menu screen, you can choose the event you wish to schedule or record. - While watching the LIVE TV screen, press the EPG button to access the EPG menu screen. - Go to the event which you wish to view at the time indicated on the EPG schedule, then press OK.
1.2 Recording Edit Press the REC button while recording to see the recording message window. Pause : Select Pause Recording then press OK to pause the current recording process. Duration : Set recording duration. Press LEFT/RIGHT ARROW button to change recording duration. ...
Page 26
Press PAUSE button once again and event will resume from the pause time. During recording, press the PLAY/TIMESHIFT button to show the Play bar screen. While the Play bar is shown on your screen, you may use the LEFT/RIGHT Arrow button to move (forward &...
2. Time Shifting You can select a storage device to host the temporary file for the Time shift with the following sequence: Menu > Configuration > Recording Option > TimeShift Device. Default storage device is set to ‘USB’ If you press the PAUSE button during Time shift, the live video is paused but the time shift buffer will continue to record.
3. Playback (Play List) You can playback many files with the Playlist which you access by the PLAYLIST button. In the Playlist, you can check and playback recorded files, multimedia movie files, MP3 music files, and image files. With the LEFT/RIGHT ARROW button, go to the Recorded Files, Imported Files, Music and Photo category and check &...
File Option : If you press the BLUE button, you can select Delete, New Folder, Move to Folder, Copy to Device, Rename, Lock/Unlock. You can select multiple files together and delete or move all of them at once. - Delete : To delete file(s) - New Folder : To make a new folder.
4. Bookmark When the Play bar is displayed, you may move to desired time and book mark it by pressing the RED button. Bookmark(s) are indicated with a Green line on the play bar. Also, you may press the RED button to activate the play bar to mark your bookmark(s).
Menu Map Main Menu 1. Storage Manager 2. Timer Settings 3. Service List Manager 4. Data Transfer System Tools 1. Recording Option 2. Parental Control 3. Display Setting 4. Time Setting 5. Language Setting 6. A/V Output Setting Configuration 1. Dish Setting 2.
Main Menu of Guide To display the menu, press the MENU button at any time. You can select the sub menus by using the ARROW buttons. The selected sub menu becomes highlighted. After selecting (highlighting) the sub menu you want to access, press the OK button.
1.2 Timer Settings Insert a new timer entry or modify an existing timer entry. To add new timer entry : Press the GREEN button. The Timer Edit window will popup. You can set the specific start date, time, duration and service for its reservation.
Page 34
Delete Services : All service lists will be shown on left side of the window. By using the ARROW and OK buttons you may select services to be deleted by placing them in the middle window. The press the GREEN button to delete the selected services.
1.4 Data Transfer When the data transfer task is in process, the Front USB slot is set to a default device slot. But, if no USB device is connected to a front USB slot, then the Rear USB slot is set as a device to be used for the data transfer process.
2. Configuration 2.1 Recording Option Alarm Confirm Message : Turn ‘ON’ this Alarm message to indicate and show the alert pop-up message when a reserved recording event is about to start. The alert message will show 3 minutes before the start time of the reserved recording event.
2.2 Parental Control User’s access rights to a service and programs are controlled by a 4-digit secret code that is defined by the user. Whenever you attempt to access the parental control menu, a pop-up window will ask you to input a PIN code. (If necessary, you can change it.) NOTE : The default PIN code is ‘0000’...
2.4 Time Setting Time Setting : To set the current time, you can use two modes; Auto or Manual. Local Offset : Enter the offset value by using the standardized information of current service area. Daylight Saving : If you want to apply daylight saving, select the counter by using the ARROW buttons.
2.6 A/V Output Setting TV Type : Select the TV types.(PAL/NTSC/Auto) In Auto mode, the STB is automatically selects NTSC or PAL according to the format the of the broadcast. TV Aspect Ratio : Select the aspect ratio of the TV which is connected to the STB (4:3/16:9).
3. Installation 3.1 Dish Setting Select the satellite/antenna and LNB settings for se rvice search. The values that are set in this menu will be available for selection in other service searc hing menus. Satellite : Select the satellite which you want to do a search for.
- Using USALS : Dish Longitude : Enter the longitude position of the antenna using the NUMERIC buttons. Dish Latitude : Enter the latitude using the NUMERIC buttons. Go To : Press the OK button to rotate the dish to the selected antenna position.
Blind Search Mode : - Satellite : Press the OK button to select multiple satellites. - Frequency : Set Auto to search whole frequency, Set Manual to search only desired frequency. - Polarity Select polarity. Polarity/Vertical/Horizontal - Search Type : Select the search type. - Dish Setting : Press the OK button to move to the Dish Setting menu directly.
MAC Address : This will display the MAC address of the STB Ethernet interface and is a fixed assignment unique to each STB. Control of the files via the network and your PC : - Check the IP Address of the STB on the Network Setting menu. - Press Enter button on your PC, after writing IP Address on the web browser address line.
Store system data : If you want to use system parameters and service data in the future, this menu allows you to store current state. Press the OK button to store current state. Delete store position : Delete stored system data. 3.6 System Information This menu displays general information about the hardware and software version of your receiver.
4. Utility 4.1 Calculator To use the calculator, highlight the calculator an d press the OK button. 4.2 Calendar To display the calendar, highlight the calendar and press the OK button. Utilize the ARROW buttons to choose the date. If you press PAGE UP/DOWN button, you can see the past/next month of the calendar.
4.4 Plugin If you have an appropriate Plugin, you can download the file(s) to Plugin then enjoy the program. Download Plugin File - In the USB storage, please create a new folder name ‘plugin’ and in this ‘plugin’ folder, create a folder name ‘bin’.
4.5 YouTube Required settings : Before you can enjoy the YouTube feature with your STB, please make sure of the following conditions. - Set-top-box should be connected with Ethernet cable, with proper network settings. (Please refer to the “Network setting” section of the manual). - Sufficient capacity for buffering is required via a USB memory stick or HDD.
Troubleshooting Problem Solution Check the main power cable and check that it is plugged into a Does not display any message suitable power outlet. on the front panel. Check the STB main power switch ‘ON’ at the rear of the STB. ...
Specifications Tuner & Channel Decoder Input Connector F‐type, IEC 169‐24, Female Loop through out F‐type, IEC 169‐24, Female Frequency Range 950MHz ~ 2150MHz Input Impedance 75Ω, unbalanced Signal Level ‐65 to ‐25dBm LNB Power 13/18VDC, max.400mA 22KHz Tone (22±2)KHz, (0.6±0.2)V DiSEqC Control V1.0/1.2/USALS Compatible Demodulation QPSK / 8PSK Input Symbol Rate 2 ~ 45 Ms/s(QPSK of DVB‐S) 2 ~ 45 Ms/s(QPSK of DVB‐S2) 2 ~ 35 Ms/s(8PSK of DVB‐S2) FEC Decoder 1/2, 2/3, 3/4, 5/6 and 7/8 with Constraint Length K=7(DVB‐S) 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9 and 9/10 (DVB‐S2/QPSK) 3/5, 2/3, 3/4, 5/6, 8/9, 9/10(DVB‐S2/8PSK) ...
Page 50
Audio / Video & Data IN/OUT RCA Video & Audio Output OPTIC Dolby Digital (SPDIF) RS‐232C 9 pin D‐SUB (Male) type, Transfer rate 115Kbps USB USB 2.0 Rear Support. (5V DC 500 mA Max.) Ethernet RJ45 connector, 100 Mbps Front Panel Buttons 3 Buttons (Standby, CH UP/DOWN) Power Supply Input Voltage AC 100 ~ 250V, 50/60Hz Type Adaptor Power Consumption Max. 24W Physical Specification Size (W x H x D) 220mm X 35mm X 145mm Weight (Net) 0.6 Kg Operating Temp. ...
