- Page 1 Stereo High-Power Amplifier A 2000 Installation Operation 058-E0021 Version 01-20-2004 Tel.: + 49 - (0)711 - 45893 - 0 KLEIN + HUMMEL GmbH Fax: + 49 - (0)711 - 45893 - 35 e-Mail:info@klein-hummel.de Zeppelinstr. 12 73760 Ostfildern/Germany Internet:www.klein-hummel.de...
-
Page 2: Safety Instructions
Safety Instructions It is absolutely essential that you read these safety instructions carefully before connecting and using this K+H product. Your safety depends on it. Furthermore, failure to follow these instructions voids the warranty. To ensure safe operation for years to come, keep these instructions in a safe place for future reference. K+H has manufactured this product in accordance with IEC 1992 (SEC) 39 standards, then tested and delivered it in safe operating condition. -
Page 3: Table Of Contents
High Power Amplifier P A 2000 Precision Audio Line Fig. 1 Front view Fig. 2 Rear view Table of Contents: Safety Instructions ..........2 3. Operation ............6 Illustrations, table of contents ......3 3.1 Front panel ..........6 1. Basic Information ..........4 3.2 Indicators and level control ...... -
Page 4: Basic Information
1. Basic Information Please take care of sufficient ventilation at both sides of the amplifier see figure 3: The K+H P A 2000 is a highest performance class AB high power amplifier. Most sophisticated protection functions and high power reserves make this amplifier the first choice for all applications. -
Page 5: Mains Fuse
and off with the mains switch of the first one. To avoid excessive on currents the units are powered on one after the other with a 3 second delay each. Caution: Do not push the rocket switch for a too long time if there are remote control modules present in the system. -
Page 6: Expansion Module Slots
2.11 Expansion module slots 3.2 Indicators and level control Module 1 Audio and HAVARIE Module 2 Audio and Remote Module 3 Audio Fig. 7 Module slots Module 1 slot for the first audio module in a chain of 3, also for the optional HAVARIE card Module 2 slot for the second audio module in a chain of 3, also for the optional remote... -
Page 7: Determining Modes And Signal Inputs
Protect A/B a protection function is active, A/B- 3.4 Determining modes and signal inputs speaker outputs are switched off, the input of the power-stage is muted (Mute) HF-DC A/B At the amplifiers output a non audible signal such as HF or DC is present, speaker outputs are switched off and the power stage is muted (Protect and Mute) Temp A/B... -
Page 8: Digital Audio Input (Optional)
VU A, VU B select total gain: Open input is not terminated. The input may 26, 32 or 36 dB. not be terminated, if several amplifiers A (AES3) input channel A when in stereo mode or are connected in a chain to one digital input when in mono and bridge mode or audio source by means of BNC T- input for AES/EBU digital audio when... -
Page 9: Temperature Protect
case of trouble the amplifiers power stages are 3.6.8 Temperature protect muted and the speaker outputs are switched off If the power electronics heat up in spite of the by relay contacts. active temperature rise limiter, power stages are muted and the speaker outputs switched off by relay contacts too. -
Page 10: Technical Specification
5. Technical specifications A 2000 Power output 20 Hz...20 kHz, 0.1 % THD+N Operation Peak 8 Ohms mono or stereo 2 x 395 watts 2x 420 watts 4 Ohms mono or stereo 2 x 650 watts 2 x 850 watts 2 Ohms mono or stereo 2 x 1,000 watts 2 x 1,200 watts...
