Summary of Contents for Sonic RC-P
-
Page 1: User Guide
RC-P Remote Control User Guide www.sonici.com... -
Page 3: Table Of Contents
Table of Contents Warnings and Safety Guidelines Introduction Features Battery Insertion and Replacement Operating your Hearing Instruments with the Remote Control... - Page 5 Operating Distance Lock Switch Volume Control Program Cycle Button Mute Button Status Light Lanyard Ring...
- Page 7 Protection Sleeve Care of Your Remote Control Environmental Protection International Warranty Declarations of Conformity...
-
Page 8: Warnings And Safety Guidelines
Warnings and Safety Guidelines • You should familiarize yourself completely with this booklet before using your remote control. • The remote control should not be used in an aircraft. • A discharged battery should be removed as soon as possible. •... - Page 9 • Never dispose of batteries with household waste. They can cause environmental pollution. • Never try to recharge non-rechargeable batteries. • Keep new and used batteries away from young children or persons of mental incapacity. If swallowed, seek immediate medical advice. •...
- Page 10 • The remote control uses digital inductive signals to transmit commands to the hearing instruments. Although extremely unlikely, concerns have been raised that this signal could possibly interfere with medical devices such as pacemakers. • As an additional precaution, we advise pacemaker recipients not to carry and use the remote control in a breast pocket or around the neck.
- Page 11 • Attention The remote control is not a toy and should under no circumstances be passed on to infants or small children (under 36 months). • For security reasons the lanyard ends should never be tied together. Use the fastener provided.
-
Page 12: Introduction
Introduction Remote Control (RC-P) This booklet describes how to get the most from your new Sonic remote control. Please follow these instructions for care and use. -
Page 13: Features
Features 1 Program cycle button 6 Battery cover 2 Volume control 7 Lock switch 3 Mute button 4 Status light 5 Lanyard ring... -
Page 14: Battery Insertion And Replacement
Battery Insertion and Replacement The remote control uses a CR2 type battery. To insert a new battery: • Gently slide the battery cover off. (A) - Page 15 • Make sure that the “+” sign on the battery matches with the “+” sign in the battery compartment. • Place the battery in the compartment making sure that the battery is properly positioned at both ends. (B) • Replace the battery cover, then slide it closed. Please note: •...
-
Page 16: Operating Your Hearing Instruments With The Remote Control
Operating your Hearing Instruments with the Remote Control Your hearing instruments can be operated by using the buttons on your remote control. If you have hearing instruments fitted to both ears, the remote control will adjust both at the same time. -
Page 17: Operating Distance
Operating Distance With the remote control, you can operate your hearing instruments from a distance of up to 3 feet / 1 meter. A direct line of sight between the remote control and your hearing instruments is not required. -
Page 18: Lock Switch
Lock Switch Your remote control is equipped with a lock switch to prevent accidental operation. Unlocked = Green dot visible Locked = Green dot hidden... - Page 19 • Your remote control is "unlocked" and ready for use when the green dot is visible. (A) • Your remote control is "locked" when the green dot is hidden. Your remote control buttons are deactivated.
-
Page 20: Volume Control
Volume Control The volume of your hearing instruments may be adjusted by using the volume control. Press “+” to increase volume (louder) Press “–” to decrease volume (softer) Increase volume Decrease volume... -
Page 21: Program Cycle Button
Program Cycle Button To cycle through the hearing instrument programs with the remote control, press the ∙ button. Each push will advance the hearing instrument to the next program in the cycle. Program cycle button... -
Page 22: Mute Button
Mute Button The remote control is equipped with a mute button. By pressing this button, the remote control directs the hearing instruments to a mute mode. Mute Button Press the * button to access the mute function. To unmute the hearing instruments with the remote control press any button. -
Page 23: Status Light
Status Light The status light indicates the remote control operation. It will blink after each button press. Two possibilities will be seen. blinking indicates that the remote control is locked. To unlock, position the lock switch so that the green dot is visible. Green Green indicates that the remote control is unlocked and... - Page 24 Status Light Status light If the light does not blink after a button is pressed, the battery needs to be replaced.
-
Page 25: Lanyard Ring
Lanyard Ring For your convenience, it is possible to attach the remote control to a lanyard. In order to mount the lanyard, pull out the ring which is found near the battery compart- ment. Thread the cord through the ring to attach it to your remote control. -
Page 26: Protection Sleeve
Protection Sleeve Purpose: You can safeguard the appearance of your remote control from scratches by using the supplied protection sleeve. Use: Insertion – Gently push the remote control into the protection sleeve opening. Removal – Press with your thumb on the material directly opposite to the protection sleeve opening to expose the end of your remote control, then gently pull it out. -
Page 27: Care Of Your Remote Control
Care of Your Remote Control • When changing the battery or cleaning the remote control, hold it over a soft surface to avoid damage if it is accidentally dropped. • Clean the remote control regularly with a dry cloth or tissue. - Page 28 • Never attempt to dry the remote control with a hair dryer, in a microwave oven or with any other heating device. • The remote control should never be exposed to extreme heat, such as on the dashboard or in the glove box of your car.
-
Page 29: Environmental Protection
Environmental Protection Help to protect the environment by not disposing of your remote control or batteries with your unsorted household waste. Please recycle your remote control and batteries or return them to your hearing healthcare provider for disposal. Contact your hearing healthcare provider for more information. -
Page 30: International Warranty
International Warranty The Sonic remote control is covered by a limited warranty, covering defects in materials and workman- ship, for a period of 12 months from the date of delivery. This warranty covers the remote control itself, but not accessories such as batteries. -
Page 31: Declarations Of Conformity
Declarations of Conformity Hereby, Sonic AG, declares that the RC-P remote control is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC and Directive 93/42/EEC. A copy of the declaration of conformity can be obtained at the following addresses: Sonic Innovations, Inc. - Page 32 This device and its radio communication parts are approved for use in the following countries: All member states of the EU and EFTA and AU, CA, JP, NZ and US. FCC ID: ZTORCP1 IC: 9799A-RCP1 N14279...
- Page 33 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera- tion.
- Page 34 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference in a residential instal- lation.
- Page 35 radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. •...
- Page 36 This Class B digital apparatus complies with Canadian ICES-003. This device emits according to following standard: ETSI EN 300 330 – 1 V1.5.1...
- Page 37 Notes...
- Page 38 Notes...
- Page 39 3018 Bern Somerset, NJ USA +41 31 560 21 21 08873 +1 888 423 7834 Australia Canada Sonic Innovations Pty Ltd Sonic Innovations Canada Ltd. 3 Unley Road 920 Industriel Blvd Parkside, SA 5063 Terrebonne, Quebec Australia J6Y 1X1 Canada...
- Page 40 Sonic Innovations Inc. Sonic AG 2501 Cottontail Lane Morgenstrasse 131B Somerset NJ, 08873, US 3018 Bern, Switzerland 1-888-678-4327 +41 31 560 21 21 11.11/4001550 www.sonici.com...
