Makita DUR142L Technical Information

Makita DUR142L Technical Information

Cordless grass trimmer
Hide thumbs Also See for DUR142L:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
T
ECHNICAL INFORMATION
Model No.
Description
C
ONCEPT AND MAIN APPLICATIONS
Models DUR142L/DUR182L and DUR183L are lightweight yet powerful
cordless grass trimmers, powered by 14.4/18V Li-ion batteries.
High power yet lightweight Brushless DC motor placed on the bottom side
of the shaft will provide easy handling and high trimming performance.
DUR142L and DUR182L are one-piece shaft models while DUR183L is
a split shaft model.
Their other main features are:
• Enhanced dust and drip-proof performance for use in bad weather
• Compatible with Metal blades, Nylon cutting heads and Plastic blade
• Reverse switch for removing grass clippings from the cutting tool
Note: • These products are not compatible with BL1415/ BL1815.
• Use of metal blades in some countries is prohibited due to
their safety regulations.
S
pecification
Specification
Cell
Voltage: V
Battery
Capacity: Ah
Energy capacity: Wh
Charging time: min.
Max. output: W
Shaft type
No load speed: min
¹=rpm
ˉ
Nylon cutting head
Cutting width:
mm (")
Metal blade
Spindle thread size
Over load protection
Electric brake
Variable speed control
Reverse switch
Weight according to
EPTA-Procedure01/2003*
*
With Battery, Nylon cutting head, Harness, Protector, Handle
1
*
With BL1430, BL1440 or BL1450
2
S
tandard equipment
Single harness
Nylon cutting head
Hex wrench 4
Hex wrench 5
Note: The standard equipment may vary by country or model variation.
O
ptional accessories
Universal guard
Nylon cord ø2mm -15m
Metal blades*
(Triple blade, Star blade, Eddy blade)
Plastic blade (cutting width: 260mm)
*Only for countries without regulations
DUR142L/DUR182L
DUR183L
Cordless Grass Trimmer
Model
DUR142L
1.5, 3.0, 4.0, 5.0
22, 44, 58, 72
15, 22, 36, 45
with DC18RC
3.8 (8.3)*
: kg (lbs)
1
*
With BL1830, BL1840 or BL1850
3
Safety goggles
Accessory bag
Cap 24 (for BUR183L only)
Fast charger DC18RC
Charger DC18SD
Charger DC24SC
Four port multi charger DC18SF
Automotive charger DC18SE
DUR182L
Li-ion
14.4
200
250
One-piece shaft
3,500 - 6,000
300 (11-3/4)
230 (9)
M8x1.25, Left-handed
Yes
Yes
Yes
Yes
3.9 (8.6)*
2
For DUR142L
Battery BL1415N
Battery BL1415NA
Battery BL1430
Battery BL1430A
Battery BL1440
Battery BL1450
OFFICIAL USE
for ASC & Sales Shop
PRODUCT
W
DUR182L
DUR183L
Dimensions: mm (")
Length (L)
1,843 (72-1/2)
Width (W)
287 (11-1/4)
Height (H)
253 (10)
DUR183L
18
1.5, 2.0, 3.0, 4.0, 5.0
27, 36, 54, 72, 90
15, 24, 22, 36, 45
with DC18RC
250
Split shaft
4.1 (9.1)*
3
For DUR142L
Battery BL1815N
Battery BL1820
Battery BL1830
Battery BL1840
Battery BL1850
P 1/ 13
H
L
3

Advertisement

loading

Related Manuals for Makita DUR142L

Summary of Contents for Makita DUR142L

  • Page 1 High power yet lightweight Brushless DC motor placed on the bottom side of the shaft will provide easy handling and high trimming performance. DUR142L and DUR182L are one-piece shaft models while DUR183L is a split shaft model. Their other main features are: DUR182L •...
  • Page 2 1R279 Round bar for arbor 5-50 removing Helical gear 31 [2] LUBRICATION Apply Makita grease N. No.2 to the following portions designated with the black triangle to protect parts and product from unusual abrasion. Item No. Description Portion to lubricate...
  • Page 3 P 3/ 13 epair [3] DISASSEMBLY/ASSEMBLY [3]-1. Motor section (cont.) DISASSEMBLING (2) Disassemble Motor section as drawn in Fig. 3. Fig. 3 1. Remove Motor housing (R) by unscrewing eight 4x18 5. Pull out Cutter shaft from Bearing box by hand. Tapping screws.
  • Page 4 P 4/ 13 epair [3] DISASSEMBLY/ASSEMBLY [3]-1. Motor section (cont.) DISASSEMBLING (3) As for Split shaft model DUR183L, refer to Fig. 4. Fig. 4 While pressing and unlocking the side stoppers of Power supply cord unit from the side holes of Pipe A complete with thin slotted screwdrivers, push the Power supply cord unit out of Pipe A complete.
  • Page 5 P 5/ 13 epair [3] DISASSEMBLY/ASSEMBLY [3] -2. Pipe complete / Pipe B [Housing set side] DISASSEMBLING (1) Separate Pipe complete/ Pipe B from Housing set L as drawn in Fig. 6. Fig. 6 1. After removing Housing set R from Housing set L, 2.
  • Page 6 P 6/ 13 epair [3] DISASSEMBLY/ASSEMBLY [3] -2. Pipe complete / Pipe B [Housing set side] (cont.) ASSEMBLING Assemble by reversing the disassembly procedure. (Fig. 6 of the previous page) Note: Lever 94 for DUR183L must be assembled to Joint 24 as drawn in Fig. 7. Housing set and Pipe B for DUR183L must be assembled as drawn in Fig.
  • Page 7 P 7/ 13 epair [3] DISASSEMBLY/ASSEMBLY [3] -3. Grip set (cont.) ASSEMBLING (3) To assemble Lock off lever to Lever base; while enlarging Lever base by fingers carefully (Fig. 12) and holding two Compression springs 4 by the another finger (Fig.
  • Page 8 P 8/ 13 epair [3] DISASSEMBLY/ASSEMBLY [3] -3. Grip set (cont.) Fig. 19 Controller section Grip section Pipe complete...
  • Page 9 Speed control dial Controller A Terminal Stator Power supply cord unit for DUR142L and DUR182L Power supply cord unit for DUR183L is split style Power supply cord unit as drawn right. The others are the same as that of DUR142L and DUR182L...
  • Page 10 P 10/ 13 iring diaphragm Fig. D-2 Wiring in Motor housing set Put Three Insulated connectors for orange, white, blue lead wires to the place between Ribs A and B. Power supply cord unit Rib C Rib A Rib B Stator 3.0 mm While routing Power supply cord unit between...
  • Page 11 P 11/ 13 iring diaphragm Fig. D-3 Wiring in Housing set While facing the wire connecting portions to the mark of Flag connector + - poles, connect Lead wires (black, yellow) to Terminal. And then, connect Lead wire (red) to Terminal. Wire connecting portion Mark of Poles Terminal...
  • Page 12 P 12/ 13 iring diaphragm Fig. D-4 Wiring in Grip set Put Reverse switch to Handle set while facing Wire connected side of Wire connected side Receptacles to ON-OFF switch side. of Receptacle Place the slacks of Lead wires around Closed end splices in the space here.
  • Page 13 P 13/ 13 rouble shooting Whenever you find any trouble in your machine, first, refer to this list to check the machine for solution. Note in Repairing • After removing the blade, Check the cutter shaft to turn smoothly by hand. •...
