CLS Façade 12 RGB
Version 2.0 May 2009
- 1 -
www.cls-led.com
CLS Manuals
CLS Façade 12 RGB
INTRODUCTION
Thank you for selecting the CLS Façade 12 RGB. The CLS Façade 12 RGB is an universal luminary that uses 12
Luxeon III LEDs to create an even RGB light-output. The CLS Façade 12 RGB can be used indoor and outdoor
through its waterproof (IP65) housing. With these qualities the CLS Façade 12 RGB is almost everywhere
mountable.
Included items
The CLS Façade 12 RGB is shipped in one package containing the following items:
• 1 CLS Façade 12 RGB
• 1 Allen key size nr. 4
• 1 User manual
Optional accessories
• CLS RGB Façade with elliptical lenses
• CLS RGB Façade with medium frosted lenses
• CLS DMX-1000 Multi current DMX LED dimmer 350-1000 mA
• CLS connection cable between DMX-1000 and Luxeon RGB products
• CLS ACX-60 DMX-controller
• CLS Façade RGB extension cable 150 cm
• CLS Façade RGB extension cable 500 cm
• CLS mold set, straight 8-26 mm
Note: It is important to read this manual before you install or use this product.
SAFETY INFORMATION
Warning! This product is for professional use only, not for domestic use.
Read this manual before powering up or installing the CLS Façade 12 RGB. Follow the instructions
listed below and observe all warnings in this manual.
Protection from electric shock
• Disconnect the driver from AC power before installing, dismounting or maintaining the unit.
• Make sure all connectors are connected properly.
• Use only a source of AC power that complies with local building and electrical codes and has both
overload and ground-fault protection.
• Refer all service to a qualified technician.
(item nr. 871330)
(item nr. 871331)
(item nr. 8714660)
(item nr. 8714662)
(item nr. 707030)
(item nr. 8713320)
(item nr. 8713325)
(item nr. 871992)
