Operating Instructions
You can easily operate this air conditioner by pressing
relevant button on the control panel as well as the
remote controller.
ON/OFF Button
The air conditioner will be started when it is energized
or will be stopped when it is in operation, if you press
this button.
MODE Button
Each time MODE button is pressed, the operation
mode is changed in sequence:
COOLING FAN ONLY ENERGY SAVING COOLING
NOTE: After setting the mode, allow 3
minutes before switching to another mode.
FAN SPEED Button
Used to select fan speed in sequence auto, low,
medium and high.
TIMER Button
Used to set or cancel timer operation.
When the unit is in operation, you can set OFF TIMER.
When the unit is off, you can set ON TIMER.
Timer setting range is 0 to 24 hours.
If the OFF TIMER is set, the timer LED displays
the remaining time to turn off the unit for only
12 seconds, then LED shifts to display set temperature.
If the ON TIMER is set, the timer LED displays
the remaining time to turn on the unit.
If you want to cancel ON TIMER, press TIMER button again.
Button
Used to set room temperature in COOLING mode or used to set time in TIMER mode.
If the two keys are pressed at the same time,the temperature LED display will alternate between
and
.
NOTE: Temperature setting range is from 19
SWING Button
Used to select start or stop vertical air vanes swinging.
SWING
FAN
SPEED
TIMER
Indication symbols of LED on control panel:
Auto fan speed
Low fan speed
Medium fan speed
High fan speed
Above LED lights on when the relevant mode is in used.
(66
) to 31 (88
).
4
Control Panel
F
C C
HR
ON/
OFF
MODE
Cooling
Fan only
Display set temp
Display set timer
Timer
Energy-saving
C
HR
