Gas cooktop with integrated
control panel
Width 11 15 / " (29 cm)
16
Series 200
VG 232–232 CA 755–
Natural gas
120V / 60Hz
Optional accessories : 125–
50–
Planning notes:
56
VG 232–232CA
Equipped for natural gas. Jets
supplied for conversion to LP gas.
– Special appliances from the
professional kitchen. Individually
put together with continuous
aluminum control panel.
– Electric ignition of all burners.
Simply press the knob, turn it and
hold it there until a stable flame
burns.
Brushed stainless steel cooktop.
Two gas burners suitable for pots
up to max. ∅ 8
11 / " cm : One
16
high-output burner (9,500 BTU).
One standard burner (6,500 BTU).
Electric ignition.
One-hand operation.
Cast-iron holder, also suitable for
small pots.
Enameled burner cap.
All-gas valve with fine control and
thermoelectric safety pilot.
VD 201–010 Shot-blasted
aluminum appliance cover. Cast
iron grates must be removed
before cover can be closed.
VV 200–000 Connecting strip for
combination with other appliances
with integrated control panel.
Order cover separately.
The gas cooktop is equipped
with a connecting cable and a
shock-proof plug (55").
When used with downdraft VL 051
swivel range is not going over the
gas cooktop.
A minimum clearance of 4" from
adjacent heat-sensitive furniture
or contact surfaces must be
observed or thermal insulation
must be installed.
Appliance clicks into place
when inserted in the work top
from above.
Maximum drawer depth16 / ".
1
2
Total rating : 16,000 BTU
Total Amps: 1
Numbers indicated
inside parenthesis ( ) = mm
