SERVICE MANUAL
Ver 1.2 2004. 08
• HCD-RG11 is the tuner, deck, CD and
amplifier section in MHC-RG11.
TE
L 13942296513
www
.
Sony Corporation
9-874-039-03
2004H16-1
Audio Group
© 2004.08
Published by Sony Engineering Corporation
http://www.xiaoyu163.com
Amplifier section
DIN power output (rated) 40 + 40 watts
(6 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
50 + 50 watts (6 ohms at 1
kHz, 10% THD)
Music power output (reference)
95 + 95 watts (6 ohms
at 1 kHz, 10% THD)
Inputs
GAME (AUDIO) IN (phono jack):
voltage 450 mV,
impedance 47 kilohms
Outputs
PHONES (stereo mini jack):
accepts headphones of
8 ohms or more
Front speaker:
accepts impedance of 6 to
16 ohms
CD player section
System
Compact disc and digital
audio system
Laser
Semiconductor laser
(λ=780 nm)
Emission duration:
continuous
Frequency response
2 Hz – 20 kHz (±0.5 dB)
Wavelength
780 – 790 nm
Signal-to-noise ratio
More than 90 dB
Dynamic range
More than 90 dB
Tape deck section
Recording system
4-track 2-channel stereo
Frequency response
40 – 13,000 Hz (±3 dB),
using Sony TYPE I
cassette
x
ao
u163
y
i
http://www.xiaoyu163.com
HCD-RG11
2 9
8
Model Name Using Similar Mechanism
CD
CD Mechanism Type
Section
Optical Pick-up Name
Tape deck
Model Name Using Similar Mechanism
Section
Tape Transport Mechanism Type
Q Q
3
6 7
1 3
1 5
SPECIFICATIONS
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
Antenna
Antenna terminals
Intermediate frequency
AM tuner section
Tuning range
Antenna
Antenna terminals
Intermediate frequency
General
Power requirements
Power consumption
Dimensions (w/h/d)
Mass
Design and specifications are subject to change
without notice.
MINI HIFI COMPONENT SYSTEM
co
.
9 4
2 8
AEP Model
UK Model
HCD-RG20
CDM58F-K6
KSM-213D
HCD-RG20
CWL44FF29
0 5
8
2 9
9 4
2 8
87.5 – 108.0 MHz
FM lead antenna
75 ohm unbalanced
10.7 MHz
531 – 1,602 kHz (with the
interval set at 9 kHz)
AM loop antenna
External antenna terminal
450 kHz
230 V AC, 50/60 Hz
85 watts
1.0 watts (at the Power
Saving Mode)
Approx. 280 × 325 × 421 mm
Approx. 8.1 kg
m
9 9
9 9
