- Page 1 ™ The Aire Deluxe Ceiling Fans FP6244** Net Weight: 14.68 lbs (6.66 kgs) FP6245** Net Weight: 16.67 lbs (7.56 kgs) Model Nos. FP6244** | FP6245** OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS...
- Page 2 Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must accompany authorized returns and must be sent freight prepaid to Fanimation. The fan to be returned must be properly packed to avoid damage in transit;...
-
Page 3: Tools Needed For Assembly
Fanimation. Substitution of parts or accessories not – Fiber Washer • Switch Cup Assembly (FP6244**) designated for use with this product by Fanimation could – our ire Connectors result in personal injury or property damage. Contact • Light Kit Assembly (FP6245**) –... -
Page 4: Energy Efficient Use Of Ceiling Fans
8 - 9 feet above the floor for optimal airflow. Consult your down into the occupied space.Remember to adjust your Fanimation Retailer for optional mounting accessories. thermostat when using your ceiling fan - additional energy and dollar savings could be realized with this simple step! Turn Off When Not in the Room Ceiling fans cool people, not rooms. - Page 5 Electrical and Structural Requirements (Continued) Brace use (Figure 3) Paired with a deep box, this hanger is meant to span CEILING JOIST between two joists and takes the place of wooden blocking. WARNING To reduce the risk of fire, electrical shock, or personal injury, mount fan to outlet box marked acceptable for fan support of 15.88 kg (35 lbs) or less.
-
Page 6: How To Assemble Your Ceiling Fan
How to Assemble Your Ceiling Fan 1. Remove the hanger ball portion from the downrod/ hanger ball assembly by loosening the set screw in the hanger ball until the ball falls freely down the downrod. Downrod Remove the pin from the downrod, then remove the hanger ball. - Page 7 How to Assemble Your Ceiling Fan (continued) 6. Reinstall the hanger ball on the downrod as follows. Route the black, white and blue wires through the hanger ball. Position the pin through the two holes in the downrod and align the hanger ball so the pin is captured in the groove in the top of the hanger ball.
-
Page 8: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan WARNING To avoid possible re or shock, be sure electricity is turned off at the main fuse box before hanging. MAIN FUSE BOX (Figure 1) NOTE: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as it must be Figure 1 grounded for safe operation. -
Page 9: How To Wire Your Ceiling Fan
How to Wire Your Ceiling Fan WARNING To avoid possible fire or shock, be sure electricity is turned off at the main fuse box before hanging. MAIN FUSE BOX (Figure 1) Figure 1 1. Connect the green grounding lead from the hanger BLACK FAN WIRE ball and the green grounding lead from the hanger... -
Page 10: How To Install Your Canopy Housing
How to Install Your Canopy Housing NOTE: This step is applicable after the neccessary wiring is completed. 1. Remove one of the two shoulder screws in the hanger bracket. Loosen the second shoulder screw without fully removing it. Assemble canopy by rotating key slot in canopy over shoulder screw in hanger bracket. - Page 11 How to Assemble Your Ceiling Fan Blades (Continued) 3. Secure the blade holders to the bottom of the motor assembly using the 1/4˝-20 screws. (Figure 3) NOTE: Periodically check blade holder hardware and resecure if necessary. WARNING Blade Holder To reduce the risk of personal injury, do not bend the Screws blade holders when installing, balancing the blades (2 per assembly)
- Page 12 How to Assemble Your Switch Cup Assembly/Light Kit Assembly (Continued) 4A—FP6244**. Assemble the switch cup assembly to FP6244** FP6245** the switch housing adapter using the previously removed screws and securely tighten all screws. (Figure 4A) 4B—FP6245**. Assemble the light kit assembly to the switch housing adapter using the previously removed screws and securely tighten all screws.
-
Page 13: How To Operate Your Ceiling Fan
How to Operate Your Ceiling Fan 1. Restore electrical power to the outlet box by turning the electricity on at the main fuse box. (Figure 1) MAIN FUSE BOX Figure 1 2A. Install the fan pull chain coupler. (Figure 2A) FP6244** FP6245** 2B. -
Page 14: Trouble Shooting
6. Fan blades out of balance. 6. Balance blades using balance kit provided in hardware bag. 1. If possible, consider using a longer 4.NOT ENOUGH AIR downrod (not included, you can buy MOVEMENT the longer downrod from fanimation.com). -
Page 15: How To Clean Your Ceiling Fan Blades
Maintenance 1. Periodic cleaning of your new ceiling fan is the only CAUTION maintenance that is needed. When cleaning, use only a soft brush or lint free cloth to avoid Do not use water when cleaning your ceiling fan. scratching the finish. Abrasive cleaning agents are It could damage the motor or the finish and create not required and should be avoided to prevent the possibility of electrical shock. - Page 16 Parts List Model No. FP6244** Reference # Description Part # APGAC110BL Hanger Bracket Assembly ADRAC1-45** Hanger Ball/Downrod Assembly Canopy PPAC1012** Canopy Screw Cover Assembly APPAC1101** Motor Coupling Cover APPAC1411** Fan Motor Assembly AMA6244** Blade Holder Set AP624412** Blade Set AP624405** Switch Cup Assembly AP624404** Loose Hardware Bag:...
- Page 17 Aire Deluxe ™ Model FP6244** Exploded-View Illustration Figure 1 NOTE: The illustration shown is not to scale or its actual con guration may vary. Product/parts are subject to change without notice.
- Page 18 Parts List Model No. FP6245** Reference # Description Part # APGAC110BL Hanger Bracket Assembly ADRAC1-45** Hanger Ball/Downrod Assembly Canopy PPAC1012** Canopy Screw Cover Assembly APPAC1101** n i l APPAC1411** Fan Motor Assembly AMA6245** Blade Holder Set AP624412** Blade Set AP624405** Light Kit Assembly AP624501** Glass...
- Page 19 ™ Model FP6245** Exploded-View Illustration Figure 1 NOTE: The illustration shown is not to scale or its actual con guration may vary. Product/parts are subject to change without notice.
- Page 20 10983 Bennett Parkway Zionsville, IN 46077 Toll Free (888) 567-2055 FAX (866) 482-5215 Outside U.S. call (317) 733-4113 Visit Our Website @ www.fanimation.com Copyright 2015 Fanimation 2015/11 V.01...
