Using the optional Wall-Mount Bracket . . . 15 on the rear of the TV. For models with supplied AC adapter: SU-WL500 (KD-75X9400D only)..17 Labels for the AC adapter Model No. and Serial No. are located SU-WL450 (KD-65/55X9300D, on the bottom of the AC adapter.
Page 3
Sony accessories, including: Supplied Wall-Mount Bracket (KD-75X9400D, KD-65/55X9300D only) Wall-Mount Bracket SU-WL500 (KD-75X9400D only) Wall-Mount Bracket SU-WL450 (Except KD-75X9400D) • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. The supplied screws are designed as indicated by illustration when measured from the attaching surface of the Wall-Mount Bracket.
Page 4
Cord (not damage and/or injuries: supplied) Use only Sony supplied AC power cords (mains lead), not those of other brands. Insert the plug fully into the AC power outlet (mains socket). Screw (not ...
Page 5
Ask your dealer or Sony service centre to have it checked by • If the TV is placed in the changing room of qualified service personnel.
To Sony Dealers and Contractors: Precautions The following instructions are for Sony dealers and contractors only. Be sure to read safety precautions described below and pay Viewing the TV special attention to safety during the installation, maintenance and checking of this product.
Optional Equipment Keep optional components or any equipment emitting electromagnetic radiation away from the TV set. Otherwise picture distortion and/or noisy sound may occur. Wireless Function of the unit • Do not operate this unit near medical equipment (pacemaker, etc.), as this may result in the malfunction of the medical equipment.
Parts and Controls Controls and Indicators KD-75X9400D, KD-65/55X9300D only Except KD-75X9400D, KD-65/55X9300D Remote Control sensor* / Light *1 Do not place anything near the sensor. sensor* / Illumination LED / 3D Sync *2 Only on limited region/country/TV model. Transmitter* The illumination LED lights up or blinks according to the status of the TV.
Using Remote Control Remote Control Parts Description The remote control shape, location, availability and function of remote control button may vary depending on your region/country/TV model. / (Input select/Text hold) EXIT In TV mode: Display and select the input Return to the previous screen or exit from source.
Page 10
Google Play AUDIO Access the “Google Play” online service. Change the language for the programme currently being viewed. NETFLIX (Only on limited region/ ///.//>/ country/TV model) Operate media contents on TV and Access the “NETFLIX” online service. connected BRAVIA Sync-compatible device. Colour buttons (Subtitle setting) Execute corresponding function at that time.
Connection Diagram For more information on connections, refer to the Help Guide (page 2). KD-75X9400D, KD-65/55X9300D only DVD player with DVI-Audio Out component output Headphone/Home Audio System/ Subwoofer Digital still camera/ Camcorder/USB storage media HDMI Device VCR/Video game equipment/ DVD player/Camcorder...
Page 12
Except KD-75X9400D, KD-65/55X9300D DVD player with HDMI component output Device Digital still camera/ Camcorder/ USB storage media Headphone/ Home Audio System/ Subwoofer HDMI Device DVI-HDMI (DVI) VCR/Video game equipment/ Adapter / DVD player/Camcorder HDMI Device Home Audio System with ARC...
Page 13
USB 1/2, USB 3 < 12 mm • Connecting a large USB device may interfere with other connected devices < 21 mm beside it. • When connecting a large USB device, *2 When connecting mono equipment, connect to the connect to the USB 1 port.
To Sony Dealers and Contractors Sufficient expertise is required for installing this product. Be sure to read this instruction manual thoroughly to do the installation work safely. Sony is not liable for any damages or injury caused by mishandling or improper installation.
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation.
Page 16
Use only a flat head screwdriver to install the Wall-Mount Attachment. Use of another tool might result in over torqueing the Wall-Mount Attachment and damaging the TV. Except KD-75X9400D, KD-65/55X9300D Remove the screws from the rear of the TV. KD-65X8500D...
SU-WL500 (KD-75X9400D only) Remove the screws. Attach the Mounting Hook using the four screws supplied with the Wall-Mount Bracket. Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference.
Page 18
Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 25-26 (Specifications) for the TV’s weight. Screen centre point Unit: mm Length for mounting...
Page 19
Install the TV on the wall. Model Name Screw location Hook location 75X9400D e, j Screw location Hook location When installing the Mounting Hook on the TV. When installing the TV onto the Base Bracket. Refer to the instructions supplied with the Wall-Mount Bracket for your model to install the TV on the wall.
SU-WL450 (KD-65/55X9300D, KD-65/55X8500D only) Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 25-26 (Specifications) for the TV’s weight.
Page 21
Attach the Attachment parts for Wall-Mount Bracket. Check the Attachment parts by referring to “1” of the Wall-Mount Bracket Installation Guide. Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference. Standard mounting KD-65/55X9300D ...
Page 22
Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style. KD-65/55X9300D KD-65/55X8500D KD-65/55X9300D Pulley Spacer (20 mm) Screw (+PSW 6 x 20) Belt KD-65/55X8500D ...
Page 23
Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. Detach the Table-Top Stand from the TV. KD-65/55X9300D KD-65/55X8500D Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the Wall”...
TV. If the problem persists, contact your dealer or Sony service centre with the number of times the illumination LED flashes red (interval time is three seconds). Disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre.
TV. Specifications See below illustration for location of the buttons on the TV. System KD-75X9400D, KD-65/55X9300D only Panel system LCD (Liquid Crystal Display) Panel, LED Backlight TV system Analogue: I, D/K, B/G, M Rear of TV...
Page 26
Dimensions (Approx.) (w × h × d) 10BASE-T/100BASE-TX connector (Depending on with Table-Top Stand the operating environment of the network, KD-75X9400D: 1,672 × 1,017 × 327 mm connection speed may differ. 10BASE-T/ KD-65X9300D: 1,458 × 891 × 275 mm 100BASE-TX communication rate and KD-65X8500D: 1,454 ×...
• The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners. • ®2016 RealNetworks, Inc. Patents Pending.
Page 32
8 毫米 - 12 毫米 螺絲 (先前卸下) AC 電源線 為了避免火災、觸電或損壞及 / 或受傷等危險,請遵照下列指示來處 理 AC 電源線和插座 : 僅使用 Sony 隨附的 AC 電源線,不能使用其他品牌的電源線。 將插頭完全插入 AC 電源插座。 僅可在 220 V - 240 V AC 電源上使用電視機。 導線 連接訊號線時,為了安全起見請務必拔下 AC 電源線,以免被訊號 (無附帶)...
• 請在適當光線條件下觀賞電視,因為在光線不足條件下或長時間觀 痕跡。 賞電視會損傷您的眼睛。 • 請勿在容易受到振動的地方使用壁掛式支架。 • 使用耳機時,請調整音量以免音量過高損傷聽力。 (僅限 3D 兼容型號) • 在觀看 3D 視訊影像或打立體的 3D 電玩期間,有些人可能會感到 不適 (如眼睛疲勞、疲累或噁心) 。Sony 建議所有觀賞者在觀看 3D 視訊影像或打立體的 3D 電玩期間要定期休息。休息的長度和頻 率因人而異。由您自行決定。若您感到任何不適,請停止觀看 3D 視訊影像或打立體的 3D 電玩,直到不適感消失;若有必要,請就 醫。關於最新資訊,也請您參閱 (i)用於電視機的其他設備或媒 體的使用說明書,以及 (ii)我們的網站 (http://www.sony-asia.com/support) 。兒童 (尤其是低於六歲 的兒童) 的視力還在發育。 讓兒童觀看 3D 視訊影像或打立體的 3D 電玩前,請諮詢醫師...
