- Page 1 TS-500-GPS TS-500 INSTALLATION AND CONFIGURATION MANUAL www.galsys.co.uk TEL: +44 (0) 121 608 4433 galleonsupport.com FAX: +44 (0) 121 608 4477...
-
Page 2: Table Of Contents
What should be shipped.......................... 4 Standard Parts ............................. 4 Optional Parts ............................4 Technical Specification ..........................5 System Overview ............................. 6 TS-500-GPS ............................6 GPS Antenna ............................7 Setting up the Unit ..........................8 Connecting everything up ........................8 Unit Location ........................... 8 Connect to Network ........................ -
Page 3: Introduction
Windows workstation or server into a stratum 1 NTP time server. However in contrast to the TS-400-GPS, the TS-500-GPS can track up to a maximum of 12 satellites and utilises a pulse per second (PPS) output for added accuracy. -
Page 4: What Should Be Shipped
TS-500-GPS WHAT SHOULD BE SHIPPED STANDARD PARTS TS-500-GPS Antenna with 10m (15m max.) of cable Instruction Manual Power Lead NTP Software CD OPTIONAL PARTS Gold and Premium Support Packages Digital Wall Clocks Additional Software Licenses (available from 5 to 300+ clients) www.galsys.co.uk... -
Page 5: Technical Specification
TS-500-GPS TECHNICAL SPECIFICATION Type of receiver Active Antenna GPS 12 channel Power Supply 85-260V, 47-63Hz Protocols SNTP via TimeSync Software Connections RS232 Serial Interface Must be mounted externally (preferably with 360 Mounting view of the sky) Requires Microsoft Windows XP or later or... -
Page 6: System Overview
Windows workstation or server into a stratum 1 NTP time server. However in contrast to the TS-400-GPS, the TS-500-GPS can track up to a maximum of 12 satellites and utilises a pulse per second (PPS) output for added accuracy. -
Page 7: Gps Antenna
TS-500-GPS GPS ANTENNA Tracking up to 12 satellites at the same time, GPS offers an accurate signal capable of a reliable and consistent reading anywhere in the world. Used extensively for synchronising time from one location to another, GPS signals are received globally and maintain a high level of accuracy. -
Page 8: Setting Up The Unit
CONNECTING EVERYTHING UP Unit Location Choose a suitable location for the TS-500-GPS; please bear in mind that the cable is limited to 10/15m and will need to be close to the computer you wish to synchronise it with. Connect to Network Connect the TS-500-GPS to a Computer via the Serial RS232 cable or the USB adapter cable. -
Page 9: Troubleshooting
TS-500-GPS TROUBLESHOOTING Use this section to quickly troubleshoot minor issues or common problems. For any further support, please contact us using our Support Website, which can be found at: galleonsupport.com Q) The GPS Unit cannot see enough satellites. What can be done to improve this? A) The ideal location for the GPS Antenna is the on the roof of the building with a 180... -
Page 10: Technical Support
TS-500-GPS TECHNICAL SUPPORT SUPPORT WEBSITE Should you require any Technical Support on this product, please go to galleonsupport.com where you can find access to the Knowledgebase, for general information. For any further questions please submit a ticket detailing the problems or technical issues you are having, and a member of the Technical Support Team will be available to support you. - Page 11 TS-500-GPS The Technical Support Knowledgebase. The Technical Support Ticket System. www.galsys.co.uk TEL: +44 (0) 121 608 4433 galleonsupport.com FAX: +44 (0) 121 608 4477...
-
Page 12: Warranty And Maintenance
Galleon systems. This Warranty does not apply if repairs are required due to acts of nature beyond Galleon systems’ control such as, but not limited to, lightning strikes, power surges, misuse, damage, neglect, or if repairs/modifications have been made or attempted by anyone other than personnel authorised by Galleon Systems.
