PHD High Definition Wall Mount Loudspeakers
PHD42
Stock Number
FG01147 - Silver
FG01287 - Black
Details
NARROW FRONTAL AREA ENCLOSURES
Reduces cabinet diffraction and reflection effects to preserve accurate imaging and natural tonal balance
PORTED BASS SYSTEM DESIGN
Delivers accurate and powerful bass output for music and movie soundtracks
TCC™ WOOFER CONES
Are comprised from a proprietary blend of injection-molded polypropylene, talc, carbon and ceramic materials that
have an ideal stiffness-to-mass ratio for precise detail and powerful bass tones
HYPERBOLIC DOME MIDRANGE DRIVERS
Feature tri-laminate Teteron material and fluid cooling to produce high sound pressure levels with exceptional clarity
and natural midrange tones that blend seamlessly with PHD high frequencies
TETERON TWEETERS
Employ a tri-laminate soft dome and fluid cooling system to deliver smooth and precise treble tones in a uniform
pattern over a wide area for crystal clear highs everywhere in the room
NILES HD HIGH DEFINITION VOICE MATCHING
Ensures compatibility with other Niles HD High Definition in-wall and ceiling mount models to accommodate a wide
variety of system designs
WOOFER TECHNOLOGY
I
Patent pending, Cone Forward™ design positions the woofer cone at the front of the baffle for
natural sounding bass and clear, open midrange
I
Dual 5-1/4" injection-molded TCC™ (talc, carbon, and ceramic-filled) polypropylene woofers offer
extreme rigidity to reduce breakup and lower distortion
I
1-1/2" Teteron hyperbolic dome midrange driver is fluid-cooled and provides high sound pressures
to reproduce critical mid frequencies with exceptional accuracy
MIDRANGE TECHNOLOGY
I
1-1/2" fluid-cooled tri-laminate Teteron hyperbolic dome midrange driver reproduces critical
midrange sounds with exceptional accuracy
TWEETER TECHNOLOGY
I
1" Teteron dome tweeter is fluid cooled and delivers ultra-wide dispersion to reproduce clear and
detailed high frequencies
AUDIOPHILE FEATURES
I
Adjustable, dispersion-controlling, midrange/tweeter pod enables precise imaging regardless of
placement and accommodates vertical or horizontal installations
I
Bass-reflex design enhances low frequency response and dynamic impact
I
3-way loudspeaker design provides exceptional detail over a wide listening area
I
Rigid extruded aluminum enclosure delivers accurate bass response with low distortion
I
Contemporary finish matches popular flat panel displays
TONE CONTROLS
I
Variable (+3dB to -3dB) midrange and treble controls adjust from the front baffle and enable fine-
tuning after installation
INSTALLATION
I
Integrated wall mount bracket makes installation quick and easy
I
Silver includes both black and silver grilles to complement popular décor
SPECIFICATIONS
I
Impedance: 4 ohm
I
Recommended amplifier power: 10W to 200W
I
Frequency response: 63Hz – 21kHz +/-3dB
I
Sensitivity: 89dB with 2.83V pink noise input, measured at 1 meter on axis
I
Dimensions: 6.2" Wide x 24.8" High x 5.6" Deep (including wall bracket)
Warranty: Five-year limited
