FEATURES
• Artistically crafted cabinet with shaped
MicroPerf
aluminum grilles look natural
TM
and realistic
• 6.5" dual voice coil injection-molded TCC (talc,
carbon, and ceramic) filled polypropylene woofer
with butyl rubber surround
• Dual 1" fluid-cooled tri-laminate Teteron
tweeters mounted at a custom angle for
optimum dispersion
• Separate left and right channel inputs provide
stereo sound in a single loudspeaker projecting
quality stereo sound over a larger area than
conventional loudspeakers
• Weatherproof design ensures performance
outdoors
• Designed to accommodate live plants
• Dual 3-foot burial-rated connection cables with
waterproof wire-nuts to insure trouble free
connection
• Can be wired in one-speaker stereo-input mode
or two-speaker stereo mode
B
H
F
L E N D I N G
I G H
N i l e s A u d i o C o r p o r a t i o n
1 2 3 3 1 S . W . 1 3 0 S t r e e t M i a m i , F l o r i d a 3 3 1 8 6
3 0 5 - 2 3 8 - 4 3 7 3
1 - 8 0 0 - B U Y - H I F I w w w . n i l e a u d i o . c o m
©2007 Niles Audio Cor pora tion. Al l r ights re s er ve d. Nil es , th e Nile s lo gos an d
Blending High F idelity and Ar chitecture ar e regi stered t rade mar ks of Nile s Au dio Corpo rat io n.
A ll other tr ademar ks a re the pr operty of thei r re sp ec tiv e o wn e rs. D S 0 0 6 2 8 A
