Product Specifications

Specifications

Power requirements
Number of inputs/outputs
Video (In)
Video (Out)
S Video (In)
Audio (In)
Audio (Out)
Component input
Speaker output (W)
Power consumption (W)
In use (max.)
In standby
TV
Weight (lbs)
Television system
Channel coverage
Antenna
Supplied accessories
Screen Aspect Ratio
SPECIFICATIONS
120V, 60 Hz
3
1
2
5
1
2
2
2
15W x2
300W
2W
145.5 (R49W36), 158.7 (R56W36)
American TV Standard, NTSC, ATSC with STB
VHF: 2 - 13
UHF: 14 - 69
CATV: 1 - 125
75 ohm external terminal for VHF/UHF
Remote control, batteries 2 size AA (Alkaline battery)
16 x 9
Design and specifications are subject to change without prior notice.
1 Vp-p, 75 ohms unbalanced, sync negative
Y: 1 Vp-p, 75 ohms unbalanced, sync negative
C: 0.280 Vp-p (burst signal), 75 ohms
500 mVrms (100% modulation), Impedance: 47 kilohms
More than 408 mVrms at the maximum volume setting (variable)
Impedance (output): 2 kilohms
Y: 1.0 Vp-p, 75 ohms w/sync
PB: 0.7 Vp-p, 75 ohms
PR: 0.7 Vp-p, 75 ohms

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R56W36 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zenith R56W36

Summary of Contents for Zenith R56W36

  • Page 1: Specifications

    15W x2 Power consumption (W) In use (max.) 300W In standby Weight (lbs) 145.5 (R49W36), 158.7 (R56W36) Television system American TV Standard, NTSC, ATSC with STB Channel coverage VHF: 2 - 13 UHF: 14 - 69 CATV: 1 - 125...

  • Page 2: Description Of Controls

    DESCRIPTION OF CONTROLS Front Panel Controls CATV V I D E O on/off CATV V I D E O tv/video menu enter On/Off TV/VIDEO Menu Enter Standby indicator (Illuminates brightly when the TV is in standby mode. Dims when the TV is switched on.) Stopper LED (Light Emitting Diodes) Displays Illuminate brightly when the set is switched on.
  • Page 3 DESCRIPTION OF CONTROLS Rear Connections Panel Connecting external equipment to your TV. ANT/CABLE1 S-VIDEO In INPUT A connection available RF Connector: with some high-end Ant/Cable 1, Ant/Cable equipment that provides S-VIDEO LOOP OUT even better picture quality and Loop Out for Video 1.
  • Page 4 DESCRIPTION OF CONTROLS Front Connection Panel (Video 3) There are four jacks on the right front side behind the screen on your projection TV that make connecting Audio/Video devices like video games and camcorders very simple. The jacks are like those found on the back jack connection panel.
  • Page 5 DESCRIPTION OF CONTROLS Remote Control Functions in TV Mode MODE Selects the remote operating INDICATOR LIGHTS mode: TV, VCR, Cable, DVD Show active remote mode and Satellite. Select other oper- every time any button is ating modes, for the remote to vcr cable dvd sat pressed.
  • Page 6 DESCRIPTION OF CONTROLS Remote Control Functions in TV Mode vcr cable dvd sat mode light power POWER (Aspect Ratio Control) Turns your TV or any other Changes the screen format or tv/video comp sleep programmed equipment on aspect ratio. or off, depending on mode. auto conv AUTO CONVERGENCE CAPTION...

  • Page 7: Programming Codes

    FUTURETECH 028 040 042 SCOTT 004 028 043 YUPITERU 004 006 008 109 116 124 048 116 143 ZENITH 001 072 073 009 034 056 SEARS 004 007 015 095 103 157 073 074 091 004 006 062 028 030 057...
  • Page 8 041 067 068 SAMSUNG 032 040 102 DAEWOO 005 007 010 MARANTZ 012 031 033 104 105 107 ZENITH 001 034 048 064 065 108 067 069 109 112 113 056 058 072 110 111 112 MARTA 115 120 122...
  • Page 9 PERSONAL CABLE 117 AMPLICA GENERAL INSTRUMENT003 004 016 PHILIPS WINEGARD 128 146 BIRDVIEW 051 126 129 029 031 059 PICO ZENITH 001 081 082 PRESIDENT 019 102 083 084 091 CAPETRONICS HITACHI 139 140 PRIMESTAR 030 110 111 CHANNEL MASTER013 014 015...
  • Page 10 VIEWSTAR 012 015 018 REMBRANT 086 087 088 ANTRONIK M-NET ARCHER 005 007 014 MACOM SAMSUNG 030 068 ZENITH 001 060 093 MAGNAVOX 010 012 064 SCIENTIFIC ATLANTA003 011 041 CABLE STAR 042 043 045 CENTURION MEMOREX CENTURY MOVIE TIME...

  • Page 11: Adjustment Instruction

    ADJUSTMENT INSTRUCTION These instructions are applied to only SP-02PC chassis. 3. Raster Slant/Focus Adjustment 3-1. Preliminary steps Notes (1) Select INSTART key on the Remote Control and then 1.Because this is not a hot chassis, it is not necessary to use select “3.

  • Page 12: Centering Magnet Adjustment

    ADJUSTMENT INSTRUCTION (2) Make Blue raster using lens cover and coincide the center of Blue raster to “A” with turning the Blue centering 50mm 45mm magnet. (3) Make Red raster using lens cover and coincide the center of Red raster to “B” with turning the Red centering magnet. (4) After finishing adjustment, press the INSTART key exit adjustment mode.

  • Page 13: Deflection Adjustment

    ADJUSTMENT INSTRUCTION 9-2. Green Lens Adjustment 168V!0.5V (1) Turn the lens until the chromatic aberration changed Blue to Red point. (2) Observing all screen, if the tendency of chromatic aberration is non-linear, adjust to appear Red chromatic aberration in 3.5 Cross-Hatch section at center screen. At this time, in case that the difference of bright line of Red chromatic aberration is not equal at both sides, adjust to 8.

  • Page 14: Convergence Adjustment

    ADJUSTMENT INSTRUCTION 9-5. (5) Red Convergence Adjustment (manually) After adjustment Red,Green & Blue lens, remove lens 1) Change cursor color in Red. (Use TV/VIDEO button) cover and receive Cross-Hatch pattern and check the 2) If you need, cover the Blue lens. overall focus.

  • Page 15: Sub Bright Adjustment

    ADJUSTMENT INSTRUCTION 12. SUB BRIGHT, SUB COLOR TINT Adjustment 12-1. SUB BRIGHT Adjustment 0 1 2 3 4 5 6 7 8 9 US14CH (1) Select INSTART key on the Remote Control and then select “6. SUB-BRIGHTNESS” with key No. 6. (CH 14 of NTSC will be received automatically) (2) Select “...
  • Page 16 ADJUSTMENT INSTRUCTION Adjustment Value Adjustment Value 2150 V-SIZE 2150 BLK-OFF 2150 H-SIZE 2150 AKB-OFF 2150 R-DRIVE 2150 UP-BLK 2150 G-DRIVE 2150 LO-BLK 2150 B-DRIVE 2150 EW-DC 2150 R-CUT 2150 V-POSITION 2150 G-CUT 2150 VSAW-DCH 2150 B-CUT 2150 V-LIN 2150 SUB BRIT 2150 S-CORRECTION 2150...
  • Page 17 ADJUSTMENT INSTRUCTION Adjustment Value Adjustment Value 2150 AFC-COMP 2151 2150 MP-PARA-DC 2151 H WIDTH 2150 MP-PARA-AMP 2151 HSEP-SEL 2150 HC-PARA-DC 2151 HD-TC 2150 ASP-SW 2151 HYSW 2150 VDRV-SW 2151 HS-MASK 2150 HC-PARA-AMP 2151 MACRO 2150 HC-PARA-PHASE 2151 SEL-DUM 2019 2151 CLK-SEL 2019 DPIC off...
  • Page 23 ? ' 6 K f ? ? ' 6 K f ? ' 6 K ? f ? POWER S/W ' @ 6 K g N @ @ ? e ? V 4 @ @ @ ? f ? @ @ ? e ? ? V ' @ @ ? e ? ? @ @ ? e ? ' @ @ @ @ @ @ @ @ @ @ ) f ?

  • Page 26: Block Diagram

    BLOCK DIAGRAM...

  • Page 27: Digital Board

    BLOCK DIAGRAM DIGITAL BOARD YUV & H/V (27MHz) CLAMP c-VDP H/V SYNC CONTROL c-VDP...
  • Page 28 EXPLODED VIEW(R56W36)

  • Page 29: Exploded View Parts List

    PCB ASSEMBLY,SUB PSW SP02PC RU-49/56NZ23 M/I 6871VSMN15C PCB ASSEMBLY,SUB CONT SP02PC RU-49/56NZ23 LED KEY 6871VSMN16E PCB ASSEMBLY,SUB CONT SP02PC RU-56NZ23.AAMLKX KEY CONTROL 3809V00A22C BACK COVER ASSEMBLY,RU-56NZ23 NON 40AF , ZENITH 3809V00A23D BACK COVER ASSEMBLY,RU-56NZ23 2PHONE LOWER 5018V00029A MIRROR,PLASTIC NON NON . PLASTIC(56W_R2) 4810V00221H BRACKET,MAIN PN-48A8 NP00PA HIPS-40AF .
  • Page 30 EXPLODED VIEW(R49W36)
  • Page 31 PCB ASSEMBLY,SUB PSW SP02PC RU-49/56NZ23 M/I 6871VSMN15C PCB ASSEMBLY,SUB CONT SP02PC RU-49/56NZ23 LED KEY 6871VSMN16C PCB ASSEMBLY,SUB CONT SP02PC RU-49/56NZ23 KEY 3809V00A15C BACK COVER ASSEMBLY,RU-49NZ23 NON 40AF , ZENITH 3809V00A16D BACK COVER ASSEMBLY,RU-49NZ23 2PHONE LOWER 5018V00028A MIRROR,PLASTIC NON NON . PLASTIC(49W_R2) 4810V00221H...

  • Page 32: Replacement Parts List

    REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit CQ : Polyestor RS : Metal Oxide Film RUN DATE : 2003.3.6 in the P/No. means as follows; CE : Electrolytic RN : Metal Film RF : Fusible...
  • Page 33 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION SD08 0IPRPTD001A BCS5030G1 TDK 2P SENSOR Q2004 0TR150400BA CHIP 2SA1504S(ASY) KEC BCS5030G1 TDK 2P SENSOR CHIP 2SC3875S(ALY) KEC SD09 0IPRPTD001A Q2005 0TR387500AA SD10 0IPRPTD001A BCS5030G1 TDK 2P SENSOR Q2006 0TR387500AA CHIP 2SC3875S(ALY) KEC...
  • Page 34 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION Q231 0TR387500AA CHIP 2SC3875S(ALY) KEC Q801 0TR385200AA 2SC3852A SANKEN CHIP 2SC3875S(ALY) KEC KTC3198 TO92 50V 150MA Q232 0TR387500AA Q803 0TR319809AA Q233 0TR387500AA CHIP 2SC3875S(ALY) KEC Q804 0TR322709AA KTC3227Y,TP(KTC1627A),KEC Q234 0TR387500AA...
  • Page 35 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION D004 0DS113379BA 1SS133 T72 DO34 90V D607 0DS113379BA 1SS133 T72 DO34 90V 1SS133 T72 DO34 90V RBV606 NA 600V 6A 150A NA 10UA D005 0DS113379BA D801 0DD606000AA D006 0DS113379BA 1SS133 T72 DO34 90V...
  • Page 36 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION D909R 0DR210009AC BAV21 DO35 200V 0.2A 1A ZD902R 0DZ180009AG ZENERS,MTZJ18B BAV21 DO35 200V 0.2A 1A D910B 0DR210009AC CAPACITOR D910G 0DR210009AC BAV21 DO35 200V 0.2A 1A D910R 0DR210009AC BAV21 DO35 200V 0.2A 1A C003 0CE107DD618...
  • Page 37 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C1016 0CE476DF618 47UF STD 16V M C1205 0CE475DK618 4.7UF STD 50V 20% 0.1UF 2012 50V 10% 0.1M 50V Z F C1018 0CK104DK56A C1206 0CN1040K949 C1019 0CE105DK618 1UF STD 50V M C1207 0CE475DK618 4.7UF STD 50V 20%...
  • Page 38 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C1700 0CE108DF618 1000UF STD 16V M C2050 0CE108DJ618 1000UF STD 35V M 4.7UF SRE,SE 50V 20% 0.1UF 2012 50V 10% C171 0CE4753K618 C2051 0CK104DK56A C171 0CK104DK56A 0.1UF 2012 50V 10% C2052 0CE107SF6DC 100UF MVG 16V M...
  • Page 39 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C2206 0CK104DK56A 0.1UF 2012 50V 10% C2606 0CE107SF6DC 100UF MVG 16V M 47UF MVG 16V M 0.1UF 2012 50V 10% C2207 0CE476SF6DC C2607 0CK104DK56A C221 0CK104DK56A 0.1UF 2012 50V 10% C261 0CK104DK56A 0.1UF 2012 50V 10%...
  • Page 40 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C282 0CK104DK56A 0.1UF 2012 50V 10% C337 0CK104DK56A 0.1UF 2012 50V 10% 0.1UF 2012 50V 10% 0.1UF 2012 50V 10% C2820 0CK104DK56A C340 0CK104DK56A C2821 0CK104DK56A 0.1UF 2012 50V 10% C341 0CK104DK56A 0.1UF 2012 50V 10%...
  • Page 41 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C412 0CE107DK618 100UF STD 50V M C476 181-014N MPP 1600V 0.01UF J 470UF STD 16V 20% 180P 500V K B C413 0CE477DF618 C477 0CK1810W515 C414 0CE477DF618 470UF STD 16V 20% C478 181-001B CE 200V 470UF M LUG (105)
  • Page 42 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C552 0CK104DK56A 0.1UF 2012 50V 10% C752 0CK104DK56A 0.1UF 2012 50V 10% 100UF STD 16V M 1UF STD 50V M C553 0CE107DF618 C758 0CE105DK618 C554 0CK104DK56A 0.1UF 2012 50V 10% C764 0CE107DF618 100UF STD 16V M...
  • Page 43 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C857 181-091D DEHR33A102KN2A 1000PF 1KV 10%,10% C914G 0CK5610W515 560P 500V K B 3300UF SMS,SG 25V 20% 560P 500V K B C858 0CE3386H610 C914R 0CK5610W515 C859 0CE108DJ618 1000UF STD 35V M C919B 0CK1010K515 100P...
  • Page 44 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION CX58 0CK104DK56A 0.1UF 2012 50V 10% L200 0LA1000K139 INDUCTOR,100UH K 0.1UF 2012 50V 10% INDUCTOR,2.2UH K CX62 0CK104DK56A L201 0LA0221K119 CX63 0CK104DK56A 0.1UF 2012 50V 10% L202 0LA0221K119 INDUCTOR,2.2UH K CX64...
  • Page 45 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION P003A 387-A08A CONNECTOR ASSEMBLY,8P 2.5MM R037 0RD4700F609 470 OHM 1/6 W 0.05 CONNECTOR ASSEMBLY,14P 2.5MM 470 OHM 1/6 W 0.05 P005A 6631V25A04A R039 0RD4700F609 P401A 387-A08A CONNECTOR ASSEMBLY,8P 2.5MM R041 0RD4700F609 470 OHM 1/6 W 0.05...
  • Page 46 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION R2057 0RN1001G509 1K OHM 1/4 W 2.00% R2748 0RD1000F609 100 OHM 1/6 W 5% 1 OHM 1 W 5.00% 1.6K OHM 1/6 W 5.00% R2095 0RF0101J607 R2780 0RD1601F609 R2096 0RF0101J607...
  • Page 47 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION R40A 0RD4702F609 47K OHM 1/6 W 5% 0RD2200F609 220 OHM 1/6 W 5.00% 10K OHM 1/6 W 5% 47K OHM 1/2 W 5.00% R40C 0RD1002F609 R430 0RS4702H609 R40D 0RD0222F609 22 OHM 1/6 W 5.00%...
  • Page 48 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION R481 0RS3902K607 39K OHM 2 W 5.00% R603 0RD5100F609 510 OHM 1/6 W 5.00% 39K OHM 2 W 5.00% 5.1K OHM 1/6 W 5.00% R482 0RS3902K607 R612 0RD5101F609 R483 0RN2002F409...
  • Page 49 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION R907G 0RN2701F409 2.7K OHM 1/6 W 1.00% R934 0RD0271H609 2.7 OHM 1/2 W 5.00% 2.7K OHM 1/6 W 1.00% 100 OHM 1/2 W 5.00% R907R 0RN2701F409 R937 0RD1000H609 R910B 180-C02Q...
  • Page 50 REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION RT33 0RD2200F609 220 OHM 1/6 W 5.00% FB802 125-022K FILTER,EMC FERRITE 1UH 4.7K OHM 1/6 W 5% FILTER,EMC FERRITE 1UH 0RD4701F609 FB803 125-022K 0RD1002F609 10K OHM 1/6 W 5% FB809 125-022K FILTER,EMC FERRITE 1UH...
  • Page 51 FILTER,EMC HH1M3216501 L708 6210TCE001G ACCESSORIES L728 6210TCE001G FILTER,EMC HH1M3216501 L729 6210TCE001G FILTER,EMC HH1M3216501 3828VA0220N MANUAL,OWNERS SP02PC ZENITH EN L801 150-F06Z FILTER,EMC SQE3535 10MH 0.85PHY 6710V00103A REMOTE CONTROLLER,SP02PC 48KEY ZENITH L803 150-F06Z FILTER,EMC SQE3535 10MH 0.85PHY FILTER,EMC SQE3535 10MH 0.85PHY L804...
