IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER.
SAVE THESE INSTRUCTIONS
SAFETY NOTICE
Please read this entire manual before
installation and use of this pellet fuel-
burning room heater. Failure to follow
these instructions could result in property
damage, bodily injury or even death.
Contact your local building or fi re
officials regarding permits and any
information on installation and
inspection requirements in your area.
TESTED and LISTED to ASTM 1509-04,
CAN/ULC S627 AND UL 1482
041113-24
Wood Energy
Technical Training
www.wettinc.ca
PS 45B
INSTALLATION
A N D O P E RAT I N G
INSTRUCTIONS
WARMLAND PELLET STOVE
MODEL: PS45
SERIES: A
5055.5311
Advertisement
Table of Contents
Summary of Contents for Warmland PS45 series A
-
Page 1: Safety Notice
Contact your local building or fi re officials regarding permits and any WARMLAND PELLET STOVE information on installation and inspection requirements in your area. TESTED and LISTED to ASTM 1509-04,... -
Page 2: Table Of Contents
PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE INSTALLING OR OPERATING YOUR WARMLAND PELLET STOVE. Contents Contents Component Information ......18 Igniter ............18 Vacuum Switch ..........18 Introduction ..........3 Auger and Auger Motor ......... 18 HIGH LIMIT Snap Switch (Manual Reset) ..18 Specifi cations .......... -
Page 3: Introduction
Check with your local building/fi re department for requirements in your area. Your Warmland PS45 stove may be able to operate with power from a portable generator. However, the generator’s electrical THERMOSTAT regulator may not be compatible with the stove’s electronics. -
Page 4: Negative Pressure Warning
Young children should be carefully supervised minimum ash. Once you fi nd a pellet brand that burns well, when they are in the same room as the Warmland PS45 Pellet continue using this brand. High ash fuel increases the frequency stove. -
Page 5: Stove Dimensions
Pellet fuel is made from sawdust and scrap wood from many different species of wood. Pellets are either 1/4” or 5/16” in 24” diameter and vary in length. The Warmland PS45 stove will burn either diameter pellets. ASH: The ash content of the fuel and operation of your stove will directly determine the frequency of cleaning. -
Page 6: Installation
Installation CAUTION: DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCT WORK UNLESS SPECIFICALLY APPROVED FOR SUCH INSTALLATIONS. Before You Begin Please read and carefully follow all of the installation and Hearth Protection operating instructions found in this manual. Please pay special attention to the safety instructions provided in this manual. -
Page 7: Clearances To Combustibles
Clearances to Combustibles 3” Clearances Front 48” (1.2m) Side 6" (155mm) Back 3” (76mm) 3” The center of the fl ue is 18-5/8” above the surface upon which the stove rests. Fig# 4a Corner Install IMPORTANT INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER. -
Page 8: Vent Terminal Minimum Clearances
Vent Terminal Minimum Clearances Fig. #5 FIXED CLOSED FIXED OPEN- CLOSED ABLE OPEN- ABLE AREA WHERE TERMINAL GAS METER AIR SUPPLY INLET VENT TERMINAL IS NOT PERMITTED ALL CLEARANCES ARE MINIMUMS A= *12 inches (30 cm) Clearances above non combustible grade *24 inches (60 cm) Clearances above grass, top of plants, wood, combustible veranda, porch, deck, or balcony B= *48 inches (120 cm) -
Page 9: Vent Termination Requirement
Vent Termination Requirement 3 Vent surfaces can become hot enough to cause burns if touched. Non-combustible shielding or guards may be required. 1. Do not terminate the vent in any enclosed or semi-enclosed 4. The Vent must terminate a minimum of 12 inches (30 cm) areas such as a carport, garage, attic, crawlspace, narrow from the wall. -
Page 10: Venting
Venting Installing into a Wood Stove Pipe The Warmland PS45 stove can be vented into existing 6” inside This heater is approved for venting with any 3" or 4" Type PL diameter approved wood stove pipe using approved adapter. and Type L pellet vent pipe listed to UL 641 and ULC S609. - Page 11 Fig #7 Chimney Recommended Recommended Chimney Connector The chimney may incorporate an offset. To do this safely, all sections of listed connector, offset elbows and chimney Caution: This confi guration may section must be screwed to- not be allowed in some gether by at least three sheet areas.
-
Page 12: Thermostat Installation
Thermostat installation Operation The Warmland PS45 stove can be operated manually or by a Filling the Hopper thermostat. The stove comes from the factory in the manual The hopper can be accessed by lifting the top of the stove. The mode. -
Page 13: General Operation
Operating Sounds should be gently cleaned with a soft cloth and glass cleaner. As the Warmland PS45 stove is burning, a number of normal operational sounds may be heard. When the blowers come on, the sound of rushing air can be heard. The lower the burn rate the slower the fan operates. -
Page 14: Routine Checks And Maintenance
Routine Checks and Maintenance Inspection /cleaning weekly monthly yearly Ash Pan - Pedestal or Every 30 bags of fuel burned Ash Pan - Leg Model or Every 15 bags of fuel burned Burn-Pot or Every 5 bags of fuel burned Burn-Pot Liner or more frequently depending on fuel quality Blower - Convection... -
Page 15: Cleaning Glass
Fig. #12 CAUTION: Disposal of Ashes - Ashes should be placed in a metal container with a tight fi tting lid. The closed container should be placed on a non-combustible fl oor or the ground – well away from all combustible materials, pending fi nal disposal. If the ashes are disposed of by burial in soil or otherwise locally dispersed, they should be retained in the closed container until all cinders have been thoroughly cooled. -
Page 16: Cabinet Side Removal
Cabinet Side Removal Fig. #17 Firebox liner Lift hopper lid and remove screw. Remove the two screws screw holding the back of the Cabinet Side to the chassis. Lift up slightly to disengage the screws at the front and back. Pull off. Installation is the reverse. -
Page 17: Cleaning The Combustion Blower
Cleaning the Combustion Blower Door Removal To clean the combustion blower, unplug the stove, remove the left cabinet side. Loosen (do not remove) the six screws CAUTION: Do not open the Firebox door when the stove is (Fig.#19) with a 1/4” nut driver or socket. Rotate the motor hot or operating. -
Page 18: Component Information
The following is a list of other components and their functions. Igniter The Warmland PS45 stove comes equipped with an automatic igniter for lighting the fuel when the stove is in the lighting mode. (Fig. #21) The igniter superheats air that is pulled through the Burn-Pot by the combustion blower to light the fuel. -
Page 19: Wiring Diagram
Wiring Diagram 010210 5050.838 - A PS 45 WIRING PELLET STOVES PS45B 041113-24... -
Page 20: Components List
Components List ITEM QTY. PART NUMBER DESCRIPTION 5037.475 CAST ASH LIP, PELLET STOVE DOOR PSRP.7340 BURN-POT/MIXER ASSEMBLY PS45.7340WLD BURN-POT PS45.7341WLD BURN-POT LINER PS45.7345Weld BURN-POT MIXER PS45.7343WLD BURN-POT GRATE 5096.99 PUMICE BRICK 7311 FIREBOX LINER 5001.035 TUBE CLEANER ROD 5001.011 BURN-POT CLEANER COUPLING 7318 MIXER DRIVE BACKING PLATE PS45.5001015WLD... - Page 21 PELLET STOVES PS45B 041113-24...
- Page 22 PELLET STOVES PS45B 041113-24...
-
Page 23: Rating Label
Rating Label DO NOT REMOVE THIS LABEL/ NE RETIREZ PAS CETTE ÉTIQUETTE. CERTIFIED FOR CANADA AND U.S.A./ CERTIFIÉ AU CANADA ET AUX ÉTATS-UNIS. LISTED ROOM HEATER,/ APPAREIL DE CHAUFFAGE AMBIANT PELLET FUEL-BURNING TYPE./ HOMOLOGUÉ, DE TYPE À GRANULES. ALSO FOR USE IN MOBILE HOMES/ CONÇU AUSSI POUR MAISONS MOBILES WN#16593 ETL#4001507... - Page 24 PACIFIC ENERGY FIREPLACE PRODUCTS LTD. www.pacifi cenergy.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Phone: 250-748-1184...
