AOC LE46H158I Service Manual

AOC LE46H158I Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
46" LCD TV
Service
Service
Service
Description
Table of Contents............................................................1
Important Safety Notice...................................................2
Revision List.........................................................3
1. General Specification..................................................4
2. Operating Instructions............................................5
3. Input/Output Specification.........................................6
4. Mechanical Instructions...........................................8
5. Repair Flow Chart...............................................12
6. PCB Layout........................................................19
6.1 Main Board.......................................................19
6.2 Power Board.....................................................21
6.3 LED Board.......................................................26
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

TABLE OF CONTENTS

SAFETY NOTICE
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
Page
Description
6.4 Key Board...................................................26
6.5 IR Board.......................................................27
7. Adjustment..............................................................28
8. Block Diagram........................................................29
9. Schematic Diagram..........................................30
9.1 Main Board....................................................30
9.2 Power Board..................................................52
9.3 LED Board.....................................................57
9.4 Key Board.....................................................58
9.5 IR Board........................................................59
10. Exploded View..............................................60
11. BOM List......................................................62
1
AOC LE46H158I
Horizontal Frequency
31~68 KHz
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE46H158I and is the answer not in the manual?

Questions and answers

Related Manuals for AOC LE46H158I

Summary of Contents for AOC LE46H158I

  • Page 1: Table Of Contents

    46″ LCD TV AOC LE46H158I Service Service Service Horizontal Frequency 31~68 KHz TABLE OF CONTENTS Description Page Description Page Table of Contents..……........…..1 6.4 Key Board………….…………..……..………..26 Important Safety Notice........……..2 6.5 IR Board………………………….……..………..27 Revision List…………………………………………………3 7. Adjustment..............28 1. General Specification......……...…..4 8. Block Diagram.……..........29 2.

  • Page 2: Important Safety Notice

    Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended.

  • Page 3: Revision List

    Revision List Version Release Date Revision Instructions TPV Model Aug.19,2011 Initial release E46BATNSAJB16N...

  • Page 4: General Specification

    1. General Specification Please refer to user manual.

  • Page 5: Operating Instructions

    2. Operating Instructions Please refer to user manual.

  • Page 6: Input/Output Specification

    3. Input/Output Specification 3.1 RGB Signal Input 15 - Pin Color Display Signal Cable Pin No. Description Pin No. Description Red Video No Pin! Green Video Sync Ground Blue Video Serial Data for DDC Ground H-Sync. Red Ground V-Sync. Green Ground Serial Clock for DDC Blue Ground 3.2 HDMI Digital Connector Pin Assignments...
  • Page 7 3.3 Compatible Mode Table RGB Input Signal Timing HDMI Input Signal Timing...

  • Page 8: Mechanical Instructions

    4. Mechanical Instructions 1. Remove the screws to remove STAND BASE. 2. Remove the screws to remove REAR COVER.
  • Page 9 3. Disconnect the harness in red. 4. Remove the screws to remove BRACKET_STAND.
  • Page 10 5. Remove the screws to remove Speaker, BKT, MAIN BOARD and POWER BOARD. 6. Remove the screws to remove BKT and separate PANEL and BEZEL.
  • Page 11 7. Remove the screws to remove KEY BOARD.

  • Page 12: Repair Flow Chart

    5. Repair Flow Chart 1. No power No power (LED “Off”) Check the AC input and Power “On” the power is “ON”? Power board Replace the power board output=5.2V? Check the IR board and LED Replace the IR board Replace the main board...
  • Page 13 2. Can’t start Can’t start Replace the power board Power board output＝24V? Replace the key board Check the power key is under control? Replace the IR board Check the IR receiver is normal? Replace the main board Replace the Power board...
  • Page 14 3. Abnormal display Abnormal Display Reset the source Check the source Enter factory mode to do “EEPROM initial”&“Reset” Replace the main board Check the main board Check the LVDS cable Replace the LVDS cable Check the panel Replace the panel...
  • Page 15 4. No display No display (LED blue) Check TV is under control and power Replace the main board on/off by remote control and power key? Check the backlight is “On”? Check the LVDS cable Check the B/L signal is available? Reinsert or replace the LVDS cable Replace main board...
  • Page 16 5. Sound problem No sound or sound abnormal Check the audio source connection and the TV system are correct? Reinsert the audio cable or change the TV system Check the TV is muted, adjust the volume or enter the menu to reset? Enter factory mode to do “Reset”...
  • Page 17 6. Remote control malfunction Remote Control malfunction Check the remote control battery is Replace the battery not properly placed or no power? Use the other remote controls Replace the remote control Whether the IR board is Replace the IR board abnormal? Replace the main board...
  • Page 18 7. OSD is unstable or can’t work normally OSD is unstable or can’t work normally Reconnect the key board Key board connected properly? Replace the button function Buttons are OK? Replace the key board Key board is OK? Enter factory mode to do “Reset” Replace the main board...

  • Page 19: Pcb Layout

    6. PCB Layout 6.1 Main Board 715G4649M01000005F...

  • Page 21: Power Board

    6.2 Power Board 715G4686P01000003M...
  • Page 24 715G4919P0G0000040...

  • Page 26: Led Board

    6.3 LED Board 715G4684T01001004S 6.4 Key Board 715G4682K01000004S...

  • Page 27: Ir Board

    6.5 IR Board 715G4781R02000005F...

  • Page 28: Adjustment

    7. Adjustment No need to adjust ADC and White Balance.

  • Page 29: Block Diagram

    8. Block Diagram 10M /100M Ethernet AUDIO IN EJTAG UART USB HUB LAN8720A 2 Speakers EUA2110 AUDIO AMP UART RS232 STANDBY Analog Audio AFE EJTAG DDC Channel (8051) SPI Interf ace SPI Flash Audio Ethernet UART IR Decode GPIO STB GPIO Post-processing Key Pad HDMI CEC...

  • Page 30: Schematic Diagram

    9. Schematic Diagram 9.1 Main Board 715G4649M01000005F MEMC_5V1 FB720 5VSB_IN CN702 5VSB_IN 5V_SW 120OHM R703 NC 100K 1/10W FB721 10K 1/10W R234 R709 PWR_ON MEMC_SCL 16,24 R704 R745 C709 MEMC_SDA 16,24 10K 1/10W PS_ON# MEMC5V_SW# 16,23 C708 V_3.3 V105_SW# 16,23 0.1uF 50V Q702 1K 1/16W...
  • Page 31 3.3VSB NC 0R05 1/10W R222 R244 R240 BC857C 4.7K 1/10W 4.7K 1/10W 3.3VSB TouchKey _VCC Q210 120 OHM spec 100mA max 0.1uF 50V FB203 Q201 LED_R# 13,17 C218 R220 PMBS3906 R219 R233 R247 4.7K 1/10W 1K 1/10W 4.7K 1/10W Q202 LED_B# 13,17 PMBS3906...
  • Page 32 VA_1.1 V_3.3 V_2.5 V_3.3 VA_1.1 V_2.5 SCALER TSXLFF-B1AFFFH BGA 27*27 FB401 FB402 AVDD25_SP16 AVDDH_DRX 120R/600mA 3.3V power_ 120R/600mA C403 C401 C404 C405 for DRX AFE 4.7UF 10V 100N 16V 100N 16V 4.7UF 10V AVSS25_SP16 AVSSH_DRX FB403 FB404 AVDD33_SP16 AVDDL_DRX 120R/600mA 1.1V power_ 120R/600mA C402...
  • Page 33 VD_CORE V_3.3 3.3VSB V_1.5 V_3.3 4.7UF 10V 100N 16V 100N 16V 100N 16V 100N 16V 100N 16V 3.3VSB C447 C448 C449 C450 C451 C452 C446 C453 C454 4.7UF 10V 10UF 10N 50V U401H VDDC: 1.0V, core power VDDF: for VDDM : 1.5V, m em ory I/O power VDDF_ST B: for 100N 16V 100N 16V...
  • Page 34 ZD103 180K 1/10W 5% PHONEJACK MLVG0402 layout close to U401 R147 CN101 VGA_AUR_O PC_RIN Place 75 Ohm at Connector side 100OHM1/16W Modify @10/12 0R05 1/10W R139 VGA_RIN R1123 13,15 HP_RXD PC_R_IN 0R05 1/10W VGA_AUL_O PC_LIN VGA_SDA_IN VGA_GIN R1124 100OHM1/16W R140 PC_G_IN 0R05 1/10W R150...
  • Page 35 3.3VSB 5VSB_IN R532 4.7K 1/10W D501 HDMI0_5VIN NC M24C02-WMN6TP Q505 FB501 HDMI0_DDC_SCL 2N7002 DDC0_SCL U501 HDMI0_HPD BAT54C HDMI0_5VIN R534 4.7K 1/10W R533 NC 4.7K 1/16W 120R/600mA HDMI0_5VIN HDMI0_5VIN HDMI INPUT 0 Q506 5VSB_IN HDMI0_DDC_SDA R535 2N7002 DDC0_SDA I2C Address: 1010 000x HDMI SHLD1 R536...
  • Page 36 3.3VSB 5VSB_IN D503 R506 4.7K 1/10W HDMI2_5VIN NC M24C02-WMN6TP Q509 FB503 HDMI2_DDC_SCL BAT54C 2N7002 U507 DDC2_SCL HDMI2_HPD HDMI2_5VIN R508 4.7K 1/10W R507 NC 4.7K 1/16W 120R/600mA HDMI2_5VIN HDMI2_5VIN HDMI INPUT 2 Q510 5VSB_IN HDMI2_DDC_SDA R509 2N7002 DDC2_SDA I2C Address: 1010 000x HDMI SHLD1 R510...
  • Page 37 V_5_T USB_5V NC 120R/3000mA AIF & DIF switch MEMC_5V1 FB115 IF_CTL IF_CTRL V_3.3 C141 C193 10uF 10V 47uF/16V R194 FB123 120R/3000mA 6.8kOHM +-5% 1/10W V_5_T U1004 R128 TS5A3157DCKR 0R05 1/10W IF_CTL A_IF_AGC T_IFAGC C1070 D_IF_AGC C107 100N 16V R1096 22N 50V 10K+-5%1/16W Tuner_SDA Tuner_SCL...
  • Page 38 +3.3VD +3.3VD R126 R127 4.7K 1/10W 4.7K 1/10W R109 R110 10K+-5%1/16W 10K+-5%1/16W Crystal is 16MHZ U101-1 TNSCL TSCL SRCK_ORR R111 10K+-5%1/16W TS1_CLK TSMDO SRCK TNSDA NC 0R05 OHM TS1_D0 TSDA SRDT_ORR R112 TS1_SY NC XSEL1 SRDT TS1_DEN SBY TE_ORR R113 NC 0R05 OHM XSEL0 SBY TE...
  • Page 39 EJTAG(Core MIPS) V_3.3 3.3VSB V_3.3 4.7K 1/16W R451 R450 R452 R453 R454 CN405 4.7K 1/16W 4.7K 1/16W 4.7K 1/16W NC 4.7K 1/16W R456 R457 R458 R455 CN411 CN412 JTAG_TDI 4.7K 1/16W 4.7K 1/16W JTAG_RSTN 4.7K 1/16W 4.7K 1/16W JTAG_TMS JTAG_TDO STB_MCU_TXD 17 JTAG_TCK HP_TXD...
  • Page 40 V_3.3 V_3.3_ETH 120R/600mA FB201 FB208 120R/600mA Pull-up Resistors should close to Transformer should R223 100N 16V PHY chip ( <400 mil ) close to RJ45( <1000 10K+-5%1/16W C201 mil ) R4274 1.2V Voltage NC 10K+-5%1/16W and far away from C202 49.9 OHM 1% 1/16W 49.9 OHM 1% 1/16W 10uF...
  • Page 41 U401A AE23 Digital_ AD23 AF23 VDAC_OUT Audio_Out AE24 CVBS1_IN CVBS C174 100N 16V AD22 R475 0R05 OHM CVBS2_IN CVBS2 SPDIF_O SPDIF_OUT C169 100N 16V AF24 CVBS3 I2SCLK CVBS4 PC_G_IN Y _G1 C151 100N 16V SCALER TSXLFF-B1AFFFH BGA 27*27 Only MAIN_OL/R intergated PC_B_IN PB_B1 MAIN_OL...
  • Page 42 V_3.3 U401B V_3.3 FRD0/PODD0 POD_A7 FRD1/PODD1 POD_A8 R134 4.7K 1/10W FRD2/PODD2 POD_A9 R133 4.7K 1/10W SCALER TSXLFF-B1AFFFH BGA 27*27 10K 1/10W R4190 FRD3/PODD3 R136 NC 4.7K 1/10W AC11 10K 1/10W R4191 FRD4/PODD4 POD_IREQ R137 NC 4.7K 1/10W AA12 10K 1/10W R4192 FRD5/PODD5 POD_RST...
  • Page 43 U401D TS1_D[0..7] TS1_D0 AC13 AD15 TS1_D0 TS2_D0 KEY_PW_SU_MENU TS1_D1 AD13 AE15 TS1_D1 TS2_D1 TS1_D2 Key Function 10K 1/10W 3.3VSB AE13 AF15 Voltage TS1_D2 TS2_D2 R4198 TS1_D3 AF13 SCALER TSXLFF-B1AFFFH BGA 27*27 AB16 TS1_D3 TS2_D3 TS1_D4 AB14 AC16 TS1_D4 TS2_D4 TS1_D5 AC14 AD16 Parallel_...
  • Page 44 U401E V_1.5 V_1.5 MMDQ0 MMA0 Place each D-cap close MMDQ1 MMA1 MMDQ2 MMA2 SCALER TSXLFF-B1AFFFH BGA 27*27 to each MVREF ball MMDQ3 MMA3 R301 R302 MMDQ4 MMA4 20K OHM 1/16W 1% C302 20K OHM 1/16W 1% MMDQ5 MMA5 C301 100N 16V MMDQ6 MMA6 100N 16V...
  • Page 45 Amp_VCC +24V_AMP 0.1uF 50V U601 C640 R633 R610 10K 1/10W +24V_AMP 4.7K 1/10W Thermal Pad R640 C608 PVCCL AMP_STBY Q604 AMP_SD PMBS3904 C628 D613 1N 50V C610 FAULTZ PVCCL 150UF 35V R614 +24V_AMP LOUT+ LINP BSPL V_3.3 R613 C612 L603 NC 10K 1/10W 1uF 25V 22uH...
  • Page 46 +24V_AMP 5V_SW +24V_AMP SH600 ZD600 R625 SH601 Amp_VCC RLZ18B SH602 NC 0R05 1/10W SH603 C635 C636 100N 50V 150UF 35V 0.1uF 50V R612 C639 R637 10K+-5%1/16W 4.7K 1/10W STBY L602 R632 Q602 22uH Sub_AMP_SD PMBS3904 C638 1K 1/10W R639 100N 50V C641 100N 50V C642...
  • Page 47 5VSB_IN USB_5V R142->H:self-powered R142->L:Bus-powered USB_POW 3V3_P R157=100K to VCC: Gang: input 1, output 0@normal, 1@ suspend FB116 R157=100K to GND: Individual: input 1, output 1@normal,0 @suspend 10K 1/10W R142 120R/3000mA R1114 R1107 NC 100OHM1/16W PWREN2 NC 120R/3000mA USB_POW NC 100OHM1/16W R1105 USB_OVCUR2# FB117...
  • Page 48 VDD18 VDD18 VDD18 R2002 100N 16V 1K 1/16W 1% C2040 C2065 C2066 100N 16V 100P 50V U2004 C2041 R2003 100P 50V 1K 1/16W 1% DRAM_VREF R2052 DRAM_CK_P DRAM_DQ0 DRAM_CK_N DRAM_DQ1 R2061 DRAM_TEST_D1 R2062 DRAM_DQ2 DRAM_TEST_D2 DRAM_DQS0_P DRAM_DQ3 R2063 330OHM 1/10W DRAM_TEST_AN LDQS DRAM_DQS0_N...
  • Page 49 120OHM FB2017 5VSB_IN 10R 1/10W 5% 4.7UF 16V MEMC_5V1 R2093 0.1uF 50V C2135 C2136 C2125 FB2018 NC 120OHM 1st Power up 100uF/16V MEMC_5V1 VCC105 U2001 5V_SW AT1529F11U 2.2uH 30% 120OHM L2001 10uF FB2015 VDD105 C2142 C2141 R2072 R2070 PGND VDD105_SW 0.1uF 50V NC 10K 1/10W 10K 1/10W...
  • Page 50 3V3DIG 3V3DIG 2K 1/10W R2020 2K 1/10W R2021 R2022 C2038 220NF 25V R2023 C2039 2K 1/10W R2025 100N 16V 2K 1/10W 4.7K 1/10W U2002 R2088 MSCL MSDA 0R05 1/10W M24512_RMN6TPA R2082 MEMC_SCL 4,16 SSCL MEMC_SDA 4,16 SSDA R2083 3V3DIG 3V3DIG 0R05 1/10W CN2006 10K 1/10W...
  • Page 51 CONN TX0AP_OA TX0AN_OA TX1AP_OA TX1AN_OA TX2AP_OA TX2AN_OA TXCKAP_OA TXCKAN_OA 0R 1/16W 5% 0R 1/16W 5% TX0AN_OA TX3AP_OA TX3AN_OA TX0AN_OB RP2308 RP2314 P_XA_TX0_N P_Y A_TX0_N TX0AP_OA TX4AP_OA TX4AN_OA TX0AP_OB P_XA_TX0_P P_Y A_TX0_P TX1AN_OA TX1AN_OB TX1AP_OA TX0BP_OA TX0BN_OA TX1AP_OB P_XA_TX1_N P_Y A_TX1_N TX1BP_OA TX1BN_OA MEMC3V3...

  • Page 52: Power Board

    9.2 Power Board 715G4686P01000003M F9901 FUSE R9901 430K 1/4W C9906 C9905 CN901 L9902 470PF 250V L9901 IC9901 C9901 RV9901 470NF 305V Varistor R9902 C9902 220NF 430K 1/4W BD901 C9907 10MH 10MH TS10B06G-06-X0 CAP004DG C9908 470PF 250V R9903 430K 1/4W NR9901 NR9902 HEAT SINK(Q9101,Q9102) NTCR...
  • Page 53 BEAD FB9302 4.7 OHM 1W R9302 C9303 R9301 T9301 47 OHM 1/4W 2N2 500V POWER X'FMR C9313 R9305 C9301 R9303 R9304 47 OHM 1/4W 10NF 2200pF630V 100K 1/4W 100K 1/4W 5.2V D9302 CN9403 C9302 L9103 2200pF630V R9306 R9307 3.5uH FMW-2156 100K 1/4W 100K 1/4W C9304...
  • Page 54 FB9801 L9801 R9801 10 OHM +-5% 3WS 1N5408-11 D9801 BEAD 236UH 680NF D9802 C9801 FMN-1106S NR9801 NTCR 51OHM +-5% 1/8W D9803 R9802 FB9802 C9802 C9805 C9803 C9812 BEAD 47UF 450V 47UF 450V 47UF 450V 47UF 450V BO_DC RB160M-60TE25 Q9804 TK15A60U R9804 R9803 680K OHM +-1% 1/4W...
  • Page 55 R9111 BO_DC 0.1 ohm C9103 R9112 10NF 2Mohm 1/4W +/-1% D9101 24V1 2M 1% 1/4W T9102 R9113 D9107 R9115 SR506 R9114 2K 1/4W R9116 RB160M-60TE25 C9101 C9120 C9105 2M 1% 1/4W 10 OHM 1/8W Q9101 560UF 63V 560UF 63V 100N 50V 2SK4101FS-V R9123 R9124...
  • Page 56 715G4919P0G0000040 LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8 CN8101 Q8109 Q8106 Q8107 Q8102 22 OHM 1/8W 22 OHM 1/8W 22 OHM 1/8W 22 OHM 1/8W CONN R8128 R8127 R8131 R8130 On/Of f VLED LED1 LED2 R8124 R8118 R8117 R8119 AO4828L AO4828L AO4828L...

  • Page 57: Led Board

    9.3 LED Board 715G4684T01001004S LED302 CN0301 CONN Blue ZD0302 RLZ5.6B ZD0301 RLZ5.6B T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL Size TPV MODEL 絬 隔 瓜 絪 腹 Key Component 01. LIGHT BOARD PCB NAME 称...

  • Page 58: Key Board

    9.4 Key Board 715G4682K01000004S...

  • Page 59: Ir Board

    ZD0202 ZD0201 BZX84-C5V1 T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL AOC Ultra Slim IR BOARD Size TPV MODEL 絬 隔 瓜 絪 腹 Key Component 01. IR BOARD PCB NAME 称 爹 <称爹>...

  • Page 60: Exploded View

    10. Exploded View...
  • Page 61 Item Description BEZEL DECO SPONGE BRACKET _SIDE SHIP INSULATING SHEET INSULATING SHEET BRACKET BRACKET INSULATING SHEET Item Part No. Description COVER AC 0Q1G1030 6120 SCREW(LED BOARD/BEZEL/IR BOARD) BRACKET _PANEL 0Q1G1040 8120 SCREW(SPEAKER/BEZEL) INSULATING SHEET 0Q1G 330 8 47 CR3 SCREW(BKT/PANEL) BRACKET STAND BKT X01G8000 4 SCREW(SPEAKER/PANEL)

  • Page 62: Bom List

    11. BOM List Note: The parts information listed below are for reference only, and are subject to change without notice. Please go to http://cs.tpv.com.cn/hello1.asp for the latest information. E46BATNSAJB16N Location Part No. Description Remark 705TQBBCP64 705 ASS'Y FOR BRAZIL PACKING 040G 581689 4A BARCODE LABEL FOR 1 045G 77500...
  • Page 63 P34T0578AME 1C0100 COVER_NECK P34T0579ADT 1L0100 BASE 42 P34T0596ADTA1L0100 BEZEL P34T0597AMD 1C0100 DECO P34T0601ADT 1L0100 NECK_COVER Q11G7010 1 PCB-SUPPORT Q12G6300 25 1 FOOT PAD Q15T1076101CKD BRACKET Q15T1077101CKD BRACKET Q36T 600 35 3 GP NONWOVEN FABRIC Q36T 600 35 3 GP NONWOVEN FABRIC Q36T 600 36 11 GP NONWOVEN FABRIC Q36T 600 37 16 GP...
  • Page 64 CN8103 033G380210B YH WAFER 2.0MM 10P W2015-10RVA-S01 R8175 061G153M10859B SY RST MOF 0.1R 5% 3WS PITCH=20MM R8146 061G153M10859B SY RST MOF 0.1R 5% 3WS PITCH=20MM C8121 067G215C1007KE EC 10UF 20% 50V 8*9 C8117 067G215C1007KE EC 10UF 20% 50V 8*9 C8102 067G215C1007KE EC 10UF 20% 50V 8*9 C8103...
  • Page 65 R8173 061G0805152 JI RST 0805 1.5K 5% 1/8W R8173 061G0805152 JT RST CHIP 1K5 1/8W 5% TZAI YUAN R8163 061G0805204 JF RST CHIPR 200KOHM +-5% 1/8W FENGHUA R8163 061G0805204 JT RST CHIP R 200KOHM 1/8W +/-5% TZAI YUAN R8123 061G0805220 JF RST CHIPR 22 OHM +-5% 1/8W FENGHUA R8124 061G0805220 JF...
  • Page 66 C8113 065G060310232K CAP CHIP 0603 1NF K 50V X7R C8113 065G060310232K CAP CHIP 0603 1N 50V X7R +/-10% C8105 065G080510232K CAP 0805 1000PF 10% 50V X7R C8105 065G080510232K CAP CHIP 0805 1N 50V X7R +/-10% C8111 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C8101 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10%...
  • Page 67 R8112 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN R8113 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN R8114 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN R8115 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN R8116 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN...
  • Page 68 C9121 063G211J3334ZU CAP MPP 33NF 5% 630V C9313 065G 1M1033ZS CAP CER 10NF 20% 1KV Y5U C9103 065G 1M1033ZS CAP CER 10NF 20% 1KV Y5U C9114 065G 3J1006ES CAP CER 10PF J 3KV SL C9104 065G306K3312ZS CAP Y1 330PF 10% 250V Y5P C9314 065G306K4712ZS CAP Y1 470PF 10% 250V Y5P...
  • Page 69 705TXA93148 D9102/D9103 ASS'Y D9102 093G 60324 SCHOTTKY FMWN-2308 30A 80V TO-220 D9103 093G 60324 SCHOTTKY FMWN-2308 30A 80V TO-220 0M1G1730 8120 SCREW 3X8 HS9103 Q90T0236 2 HEAT SINK 705TXA93149 BD901 ASS'Y BD901 093G 50460937 BRIDGE TS10B06G-06-X0 10A 800V KBJ 0M1G1730 8120 SCREW 3X8 HS9901 Q90T0222 7...
  • Page 70 R9108 061G08052402FT RST CHIP 24K 1/8W 1% R9117 061G0805243 JF RST CHIPR 24KOHM +-5% 1/8W FENGHUA R9117 061G0805243 JT RST CHIP 24K 1/8W 5% TZAI YUAN R9818 061G0805273 JF RST CHIPR 27KOHM +-5% 1/8W FENGHUA R9818 061G0805273 JT RST CHIP 27K 1/8W 5% TZAI YUAN R9118 061G0805470 JF RST CHIPR 47OHM +-5% 1/8W FENGHUA...
  • Page 71 R9312 061G1206249 JF RST CHIPR 2.4 OHM +-5% 1/4W FENGHUA R9311 061G1206249 JF RST CHIPR 2.4 OHM +-5% 1/4W FENGHUA R9311 061G1206249 JT RST CHIPR 2.4 OHM +-5% 1/4W TZAI YUAN R9312 061G1206249 JT RST CHIPR 2.4 OHM +-5% 1/4W TZAI YUAN R9308 061G1206339 JF RST CHIPR 3.3 OHM +-5% 1/4W FENGHUA...
  • Page 72 D9402 093G 60S 15 T SCHOTTKY RB160M 60 TR 1A 60V SOD-123 D9403 093G 60S 15 T SCHOTTKY RB160M 60 TR 1A 60V SOD-123 D9404 093G 60S 15 T SCHOTTKY RB160M 60 TR 1A 60V SOD-123 D9803 093G 60S 15 T SCHOTTKY RB160M 60 TR 1A 60V SOD-123 T9102 006G 31500...
  • Page 73 J9047 095G 90 23 JUMPER WIRE J9046 095G 90 23 JUMPER WIRE J9045 095G 90 23 JUMPER WIRE J9044 095G 90 23 JUMPER WIRE J9042 095G 90 23 JUMPER WIRE J9041 095G 90 23 JUMPER WIRE J9040 095G 90 23 JUMPER WIRE J9039 095G 90 23...
  • Page 74 C9312 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C9306 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C9122 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C9117 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C9110 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10% C9106 065G080510432K CAP CHIP 0805 100N 50V X7R +/-10%...
  • Page 75 C610 067G215P1516KE EC 150UF 20% 35V 10*9 C636 067G215P1516KE EC 150UF 20% 35V 10*9 C2146 067G315M1016KE EC 100UF 20% 35V 8*7 3000 HR C7744 067G315M1016KE EC 100UF 20% 35V 8*7 3000 HR CN121 088G 302506 C PHONE JACK 4P BLACK - CN122 088G 302506 C PHONE JACK 4P BLACK -...
  • Page 76 C744 067G311F4703NT CAP S105C 47UF M 16V C747 067G311F4703NT CAP S105C 47UF M 16V C750 067G311F4703NT CAP S105C 47UF M 16V C2120 067G311R1013LT EC SMD 100UF 20% 16V 6.3*5.3 C199 067G311R1013LT EC SMD 100UF 20% 16V 6.3*5.3 C196 067G311R1013LT EC SMD 100UF 20% 16V 6.3*5.3 C2125 067G311R1013LT EC SMD 100UF 20% 16V 6.3*5.3...
  • Page 77 FB209 071T 56G301 TA CHIP BEAD 2012 300R 25% 4000MA 709T4649 XS002 COMSUPTIVE ASS'Y 055G 100610 TIN CREAM W/O PB E715 715G4649M01000005F MAIN PCB FR4 4L 193*246*1.6MM E715 715G4649M01000005K MAIN PCB FR4 4L 193*246*1.6MM 2nd Source 040G 457624 1B LABEL-CPU U2401 056G 562F12 SCALER FRC9459S-EF-A2-T PBGA372-1...
  • Page 78 Q504 057G 417 4 PMBS3904/PHILIPS-SMT(04) Q602 057G 417 4 PMBS3904/PHILIPS-SMT(04) Q604 057G 417 4 PMBS3904/PHILIPS-SMT(04) Q605 057G 417 4 PMBS3904/PHILIPS-SMT(04) Q701 057G 417 4 PMBS3904/PHILIPS-SMT(04) Q202 057G 417 6 PMBS3906/PHILIPS-SMT(06) Q201 057G 417 6 PMBS3906/PHILIPS-SMT(06) Q210 057G 420519 T BC857C Q203 057G 763 79 FET AO4449 -7A/-30V SOIC-8...
  • Page 79 RP101 061G 1253308JF RST CHIP AR 8P4R 33 OHM +-5% 1/16W RP102 061G 1253308JF RST CHIP AR 8P4R 33 OHM +-5% 1/16W RP102 061G 1253308JY RST CHIP AR 8P4R 33 OHM +-5% 1/16W RP101 061G 1253308JY RST CHIP AR 8P4R 33 OHM +-5% 1/16W R402 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA...
  • Page 80 R445 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA R448 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA R475 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA R478 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA R479 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA R480 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA...
  • Page 81 R4156 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R4140 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R4139 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R4138 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R4135 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R4130 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN...
  • Page 82 R511 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R513 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R515 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R524 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R526 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN R528 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN...
  • Page 83 R2013 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA R2012 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA R2011 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA R2014 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA R2015 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA...
  • Page 84 R708 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA R704 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA R2043 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA R2053 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA R701 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA R548 061G0402102 JF RST CHIPR 1KOHM +-5% 1/16W FENGHUA...
  • Page 85 R544 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA R540 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA R530 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA R527 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA R517 061G0402103 JF RST CHIPR 10KOHM +-5% 1/16W FENGHUA R110 061G0402103 JY RST CHIPR 10KOHM +-5% 1/16W YAGEO...
  • Page 86 R305 061G04022400FF RST CHIPR 240 OHM +-1% 1/16W FENGHUA R312 061G04022400FF RST CHIPR 240 OHM +-1% 1/16W FENGHUA R313 061G04022400FF RST CHIPR 240 OHM +-1% 1/16W FENGHUA R313 061G04022400FT RST CHIPR 240 OHM +-1% 1/16W TZAI YUAN R312 061G04022400FT RST CHIPR 240 OHM +-1% 1/16W TZAI YUAN R305 061G04022400FT RST CHIPR 240 OHM +-1% 1/16W TZAI YUAN...
  • Page 87 R418 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA R447 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA R130 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA R105 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA R104 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA R458 061G0402472 JF RST CHIPR 4.7KOHM +-5% 1/16W FENGHUA...
  • Page 88 R225 061G04024999FF RST 0402 49.9R 1% 1/16W R226 061G04024999FF RST 0402 49.9R 1% 1/16W R227 061G04024999FF RST 0402 49.9R 1% 1/16W R228 061G04024999FF RST 0402 49.9R 1% 1/16W R228 061G04024999FT RST 0402 49.9R 1% 1/16W R227 061G04024999FT RST 0402 49.9R 1% 1/16W R225 061G04024999FT RST 0402 49.9R 1% 1/16W...
  • Page 89 R310 061G04027509FY RST CHIP 75R 1/16W 1% R311 061G04027509FY RST CHIP 75R 1/16W 1% R203 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R199 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R128 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA R1125 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA...
  • Page 90 R2071 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN R2074 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN R706 061G0603102 JF RST CHIPR 1K OHM +-5% 1/10W FENGHUA R632 061G0603102 JF RST CHIPR 1K OHM +-5% 1/10W FENGHUA R233 061G0603102 JF RST CHIPR 1K OHM +-5% 1/10W FENGHUA...
  • Page 91 R1102 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA R4191 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA R749 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA R748 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA R746 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA...
  • Page 92 R1109 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA R1110 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA R151 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA R152 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA R157 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA R170 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA...
  • Page 93 R2022 061G0603202 JF RST CHIPR 2K OHM +-5% 1/10W FENGHUA R2021 061G0603202 JF RST CHIPR 2K OHM +-5% 1/10W FENGHUA R2020 061G0603202 JY RST CHIPR 2K +-5% 1/10W YAGEO R2021 061G0603202 JY RST CHIPR 2K +-5% 1/10W YAGEO R2023 061G0603202 JY RST CHIPR 2K +-5% 1/10W YAGEO R2022 061G0603202 JY...
  • Page 94 R635 061G0603333 JT RST CHIP 33K 1/10W 5% TZAI YUAN R635 061G0603333 JY RST CHIPR 33KOHM 1/10W YAGEO R725 061G0603361 JT RST CHIP 360R 1/10W 5% TZAI YUAN R752 061G06033900FT RST CHIP 390R 1/10W 1% R752 061G06033900FY RST CHIP 390R 1/10W 1% R726 061G0603391 JF RST CHIPR 390 OHM +-5% 1/10W FENGHUA...
  • Page 95 R241 061G0603472 JY RST CHIPR 4.7KOHM £«-5£¥ 1/10W YAGEO R244 061G0603472 JY RST CHIPR 4.7KOHM £«-5£¥ 1/10W YAGEO R247 061G0603472 JY RST CHIPR 4.7KOHM £«-5£¥ 1/10W YAGEO R1104 061G0603472 JY RST CHIPR 4.7KOHM £«-5£¥ 1/10W YAGEO R529 061G0603472 JY RST CHIPR 4.7KOHM £«-5£¥ 1/10W YAGEO R525 061G0603472 JY RST CHIPR 4.7KOHM £«-5£¥...
  • Page 96 R1108 061G0603823 JI RST 0603 82K 5% 1/10W R175 061G0603823 JI RST 0603 82K 5% 1/10W R169 061G0603823 JI RST 0603 82K 5% 1/10W R168 061G0603823 JI RST 0603 82K 5% 1/10W R176 061G0603823 JI RST 0603 82K 5% 1/10W R751 061G06039100FF RST CHIPR 910 OHM +-1% 1/10W FENGHUA...
  • Page 97 C339 065G040210332K CAP 0402 10NF 10% 50V X7R C338 065G040210332K CAP 0402 10NF 10% 50V X7R C330 065G040210332K CAP 0402 10NF 10% 50V X7R C329 065G040210332K CAP 0402 10NF 10% 50V X7R C411 065G040210332K CAP 0402 10NF 10% 50V X7R C4120 065G040210332K CAP 0402 10NF 10% 50V X7R...
  • Page 98 C487 065G040210332K CAP CHIP 0402 10N 50V X7R +/-10% C488 065G040210332K CAP CHIP 0402 10N 50V X7R +/-10% C1103 065G040210332K CAP CHIP 0402 10N 50V X7R +/-10% C4109 065G040210332K CAP CHIP 0402 10N 50V X7R +/-10% C497 065G040210332K CAP CHIP 0402 10N 50V X7R +/-10% C496 065G040210332K CAP CHIP 0402 10N 50V X7R +/-10%...
  • Page 99 C198 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C200 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2002 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2004 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2005 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2006 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10%...
  • Page 100 C2073 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C171 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2087 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2077 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2076 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C2075 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10%...
  • Page 101 C350 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C351 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C401 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C404 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C406 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10% C407 065G040210412K CAP CHIP 0402 100N 16V X7R +/-10%...
  • Page 102 C111 065G040210412K CAP CHIP 0402 100NF K 16V X7R C112 065G040210412K CAP CHIP 0402 100NF K 16V X7R C113 065G040210412K CAP CHIP 0402 100NF K 16V X7R C118 065G040210412K CAP CHIP 0402 100NF K 16V X7R C119 065G040210412K CAP CHIP 0402 100NF K 16V X7R C120 065G040210412K CAP CHIP 0402 100NF K 16V X7R...
  • Page 103 C2019 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2021 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2027 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2026 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2025 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2024 065G040210412K CAP CHIP 0402 100NF K 16V X7R...
  • Page 104 C2092 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2096 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2097 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2106 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2108 065G040210412K CAP CHIP 0402 100NF K 16V X7R C2110 065G040210412K CAP CHIP 0402 100NF K 16V X7R...
  • Page 105 C416 065G040210412K CAP CHIP 0402 100NF K 16V X7R C417 065G040210412K CAP CHIP 0402 100NF K 16V X7R C420 065G040210412K CAP CHIP 0402 100NF K 16V X7R C421 065G040210412K CAP CHIP 0402 100NF K 16V X7R C424 065G040210412K CAP CHIP 0402 100NF K 16V X7R C425 065G040210412K CAP CHIP 0402 100NF K 16V X7R...
  • Page 106 C139 065G040210412K CAP 0402 100NF 10% 16V X7R C144 065G040210412K CAP 0402 100NF 10% 16V X7R C146 065G040210412K CAP 0402 100NF 10% 16V X7R C2008 065G040210412K CAP 0402 100NF 10% 16V X7R C2009 065G040210412K CAP 0402 100NF 10% 16V X7R C150 065G040210412K CAP 0402 100NF 10% 16V X7R...
  • Page 107 C2039 065G040210412K CAP 0402 100NF 10% 16V X7R C204 065G040210412K CAP 0402 100NF 10% 16V X7R C2040 065G040210412K CAP 0402 100NF 10% 16V X7R C2043 065G040210412K CAP 0402 100NF 10% 16V X7R C2046 065G040210412K CAP 0402 100NF 10% 16V X7R C2049 065G040210412K CAP 0402 100NF 10% 16V X7R...
  • Page 108 C320 065G040210412K CAP 0402 100NF 10% 16V X7R C319 065G040210412K CAP 0402 100NF 10% 16V X7R C314 065G040210412K CAP 0402 100NF 10% 16V X7R C313 065G040210412K CAP 0402 100NF 10% 16V X7R C312 065G040210412K CAP 0402 100NF 10% 16V X7R C311 065G040210412K CAP 0402 100NF 10% 16V X7R...
  • Page 109 C450 065G040210412K CAP 0402 100NF 10% 16V X7R C451 065G040210412K CAP 0402 100NF 10% 16V X7R C452 065G040210412K CAP 0402 100NF 10% 16V X7R C460 065G040210412K CAP 0402 100NF 10% 16V X7R C463 065G040210412K CAP 0402 100NF 10% 16V X7R C462 065G040210412K CAP 0402 100NF 10% 16V X7R...
  • Page 110 C2041 065G060310131J CAP CHIP 0603 100P 50V NP0 +/-5% C2064 065G060310131J CAP CHIP 0603 100P 50V NP0 +/-5% C2066 065G060310131J CAP CHIP 0603 100P 50V NP0 +/-5% C138 065G060310232K CAP CHIP 0603 1000PF K 50V X7R C188 065G060310232K CAP CHIP 0603 1000PF K 50V X7R C189 065G060310232K CAP CHIP 0603 1000PF K 50V X7R...
  • Page 111 C1051 065G060310432K CAP 0603 100NF 10% 50V X7R C706 065G060310432K CAP 0603 100NF 10% 50V X7R C705 065G060310432K CAP 0603 100NF 10% 50V X7R C703 065G060310432K CAP 0603 100NF 10% 50V X7R C708 065G060310432K CAP 0603 100NF 10% 50V X7R C709 065G060310432K CAP 0603 100NF 10% 50V X7R...
  • Page 112 C725 065G060310432K CAP 0603 100NF 10% 50V X7R C728 065G060310432K CAP 0603 100NF 10% 50V X7R C729 065G060310432K CAP 0603 100NF 10% 50V X7R C731 065G060310432K CAP 0603 100NF 10% 50V X7R C737 065G060310432K CAP 0603 100NF 10% 50V X7R C739 065G060310432K CAP 0603 100NF 10% 50V X7R...
  • Page 113 C220 065G060310512K CAP 0603 1UF 10% 16V X7R C224 065G060310512K CAP 0603 1UF 10% 16V X7R C733 065G060310512K CAP 0603 1UF 10% 16V X7R C713 065G060310512K CAP 0603 1UF 10% 16V X7R C4128 065G060310512K CAP 0603 1UF 10% 16V X7R C135 065G060310512K CAP 0603 1UF 10% 16V X7R...
  • Page 114 C211 065G060322332K TPV CHIP 0603 22N 50V X7R +/-10% C2038 065G060322422K CAP CHIP0603 220NF K 25V X7R C212 065G060322422K CAP CHIP0603 220NF K 25V X7R C607 065G060322422K CAP CHIP0603 220NF K 25V X7R C617 065G060322422K CAP CHIP0603 220NF K 25V X7R C616 065G060322422K CAP CHIP0603 220NF K 25V X7R...
  • Page 115 C405 065G0603475A5K CAP CHIP 0603 4.7UF K 10V X5R C403 065G0603475A5K CAP CHIP 0603 4.7UF K 10V X5R C402 065G0603475A5K CAP CHIP 0603 4.7UF K 10V X5R C419 065G0603475A5K CAP CHIP 0603 4.7UF K 10V X5R C431 065G0603475A5K CAP CHIP 0603 4.7UF K 10V X5R C432 065G0603475A5K CAP CHIP 0603 4.7UF K 10V X5R...
  • Page 116 C309 065G080510602K CAP 0805 10UF 10% 6.3V X7R C308 065G080510602K CAP 0805 10UF 10% 6.3V X7R C730 065G080510602K CAP 0805 10UF 10% 6.3V X7R C732 065G080510602K CAP 0805 10UF 10% 6.3V X7R C735 065G080510602K CAP 0805 10UF 10% 6.3V X7R C740 065G080510602K CAP 0805 10UF 10% 6.3V X7R...
  • Page 117 C2135 065G080547515K MLCC 0805 4U7 16V X5R +/-10% C2145 065G080547515K MLCC 0805 4U7 16V X5R +/-10% C2135 065G080547515K CAP CHIP 0805 4.7UF K 16V X5R C2145 065G080547515K CAP CHIP 0805 4.7UF K 16V X5R C178 065G080547515K CAP CHIP 0805 4.7UF K 16V X5R C153 065G0805475A2K CAP 0805 4.7UF 10% 10V X7R...
  • Page 118 FB2006 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 FB2005 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 FB2010 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 FB2011 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 FB719 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30 FB417 071G 59A121 TA CHIP BEAD 120R/3000MA HCB1608KF-121T30...
  • Page 119 CN509 088G 34019K AV HDMI HEADER R/A 19P BLACK H=8.4 CN508 088G 34019K AV HDMI HEADER R/A 19P BLACK H=8.4 CN507 088G 34019K AV HDMI HEADER R/A 19P BLACK H=8.4 CN506 088G 34019K AV HDMI HEADER R/A 19P BLACK H=8.4 D101 093G 60505 SCHOTTKY BAT54C 0.2A 30V SOT-23...
  • Page 120 LEPFBXA5C LED BOARD 709T4684 XM002 COMSUPTIVE ASS'Y CN0301 033G8032 3F HR CONNECTOR 3P 1.25 LED302 081G 15X01 GP CHIP LED ORANGE/BLUE GPTD12048OBC1 ZD0301 093G 39S 24 T RLZ 5.6B LLDS ZD0302 093G 39S 24 T RLZ 5.6B LLDS 709T4684 XS002 COMSUPTIVE ASS'Y 715G4684T01001004S DAUGHTER PCB FR4 DS 52.5X14.1X1.6MM...
