Sony BDP-S2000ES Service Manual

SERVICE MANUAL
Ver. 1.0 2007.09
System
Laser: Semiconductor laser
Outputs
(Jack name: Jack type/Output level/Load impedance)
AUDIO OUT L/R:
Phono jack/2 Vrms/10 kilohms
DIGITAL OUT (OPTICAL):
Optical output jack/–18 dBm (wave length 660 nm)
DIGITAL OUT (COAXIAL):
Phono jack/0.5 Vp-p/75 ohms
5.1CH OUTPUT:
Phono jack/2 Vrms/10 kilohms
HDMI OUT:
HDMI 19-pin standard connector
COMPONENT VIDEO OUT(Y, P
Phono jack/Y: 1.0 Vp-p/P , P
B R
= 0.7 Vp-p/75 ohms
VIDEO: Phono jack/1.0 Vp-p/75 ohms
S VIDEO: 4-pin mini DIN/Y:
1.0 Vp-p, C: 0.286 Vp-p/75 ohms
SPECIFICATIONS
, P ):
B R
: progressive or interlace
TM
BDP-S2000ES
General
Power requirements:
120 V AC, 60 Hz
Power consumption: 33 W
Dimensions (approx.):
430 × 105 × 362 mm (17 × 4
incl. projecting parts
Mass (approx.): 7.6 kg (16
Operating temperature:
5 ºC to 35 ºC (41ºF to 95ºF)
Operating humidity:
25 % to 80 %
Supplied accessories
• Video cord (phono plug × 1) (1)
• Stereo audio cord (phono plug × 2) (1)
• Power cord (1)
• Remote commander (remote) (1)
• Size AA (R6) batteries (2)
Specifications and design are subject to change without notice.
BLU-RAY DISC PLAYER
RMT-B101A
US Model
Canadian Model
× 14
1 3
/ / in.) (width/height/depth)
4 8
3
/ lb)
4
