  • Page 1 TRF-ZW2 Z-Wave Gateway Owner’s Manual...
  • Page 2 TECHNICAL OR EDITORIAL ERRORS/OMISSIONS MADE IN THIS MANUAL. The information in this manual may be subject to change without prior notice. URC - Control the Experience is a registered trademark of Universal Remote Control, Inc. Total Control is a registered trademark of Universal Remote Control, Inc.

  • Page 3: Table Of Contents

    Table of Contents READ ME FIRST CONGRATULATIONS FEATURES AND BENEFITS PACKAGE CONTENTS DEVICE LAYOUT INSTALLATION USING THE TRF-ZW2 RESTRICT INSTALLER OFFSITE ACCESS HARDWARE SPECIFICATION LIMITED WARRANTY STATEMENT END USER AGREEMENT FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE STATEMENT...

  • Page 4: Read Me First

    (LAN) architecture as well as Wi-Fi configuration and other system connections. Once configured to operate with your URC control system most changes to the TRF-ZW2, or the system, may be performed locally (at your home), or from any remote location (via internet with your permission).

  • Page 5: Congratulations

    URC control system, integrating them seamlessly together into a single user interface for control. Incorporating this gateway as part of a URC control system enables a myriad of potential additions to your home. Easily expand your system by adding virtually any Z-Wave enabled device to your connected home.

  • Page 6: Package Contents

    Wi-Fi connectivity allows for optimized placement and simplified installation. Package Contents What’s Included with your new product • TRF-ZW2 Z-Wave Extender • 12V Power Adaptor • Ethernet Cable • Warranty Card If any of these items are missing, contact URC’s Technical Support Department at (914) 835-4484...

  • Page 7: Device Layout

    12V Power Receptacle USB Port RJ-45 Ethernet Port • 12V Power Receptacle: connects to the included DC adapter • Ethernet Port: bridges the TRF-ZW2 and your local area network (LAN) • USB Port: provides features and support for advanced applications...
  • Page 8 Device Layout LED Indicator Lights Service LED Service LED Z-Wave LED • On - Cloud service connected and working properly • Off - No cloud service installed • Flashing - Cloud service not communicating Wi-Fi LED Z-Wave LED WAN LED •...

  • Page 9: Installation

    Use the supplied network (Ethernet) cable to connect the TRF-ZW2’s Ethernet port to your local area network (router or network switch) Connect the supplied DC adapter to the TRF-ZW2 and plug the adapter into an AC receptacle Upon power-up the TRF-ZW2 checks for an available firmware upgrade. If an upgrade is available it is installed automatically.

  • Page 10: Using The Trf-Zw2

    Setup Through Web-portal End-user As an end-user your URC certified custom professional integrator performs the initial setup of your Z-Wave system. An e-mail is sent to the address you provide your integrator; this includes a temporary password granting you access to the Z-Wave User Portal.

  • Page 11: Restrict Installer Offsite Access

    Restrict Installer Offsite Access By default your professional integrator, after system setup is complete, continues to have access to your Z-Wave system via the URC Web- portal. This includes the ability to remotely control your Z-Wave devices. URC recommends restricting this access. Upon logging in for the first time (using the temporary password e-mailed to the address...

  • Page 12: Hardware Specification

    Hardware Specification Hardware CPU: 600MHz MIPS SoC Flash Memory: NAND 128MB Memory: DDR2 128MB USB Port: 1 WAN Port: 1 Wireless: Z-Wave Plus™ and 802.11 a/b/g/n Wi-Fi Dimensions 4.55in x 3.13in x 1.2in (HxWxD) Weight: 12 oz. (shipping weight) Certifications: FCC, CE, RoHS, Z-Wave Plus Power Supply Input: AC 100-240VAC, 50-60Hz Output: DC 12V/1A...

  • Page 13: Limited Warranty Statement

    (1) year from the date of purchase of the product by the end-user, but no longer than thirty-six (36) months from the date of shipment of the URC equipment by URC to an authorized URC dealer or distributor, except that with respect to Total Control®...
  • Page 14 It is likely that such data, software, or other materials will be lost during service and URC will not be responsible for any such damage or loss. A dated purchase receipt, bill of sale, installation contract or other verifiable proof of purchase is required.

  • Page 15: End User Agreement

    2. URC'S LIMITATIONS OF LIABILITY IN NO EVENT SHALL URC BE LIABLE FOR INDIRECT, SPECIAL, INCIDENTAL, EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES OF ANY KIND OR LOSS OF PROFITS OR BUSINESS OPPORTUNITY, EVEN IF URC IS ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

  • Page 16: Federal Communications Commission Compliance Statement

    Federal Communications Commission Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 17 Notes...
  • Page 18 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com TRF-ZW2_OM_final_12.08.15_REV5_RH...
