In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.
IMPORTANT SERVICE SAFETY PRE-
CAUTION ............................................... . ............i
CHAPTER 1. OPERATION MANUAL
[1]
Specifications ................................. . ....... 1-1
[2]
Operation Manual .......................... . ....... 1-2
[3]
Dimensions ........................................ . ....... 1-4
[1]
Removing Of Major Parts ........... . ....... 2-1
CHAPTER 3. ADJUSTMENT PROCEDURE
[1]
Adjustment Procedure ............... . ....... 3-1
CHAPTER 4. TROUBLESHOOTING TABLE
[1]
TROUBLESHOOTING TABLE............... . ....... 4-1
[1]
Major Ic Informations.................. . ....... 5-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LCD COLOUR TELEVISION
LC-19D1E/S-BK/WH
MODELS
CONTENTS
No. S58J9LC19D1ES
CHAPTER 6. BLOCK DIAGRAM/WIRING DIAGRAM
[1]
Block Diagram.........................................6-1
[2]
Power Block Diagram ..........................6-2
[3]
Wiring Diagram .......................................6-3
[1]
[2]
DIGITAL TUNER UNIT PRINTED WIRING
BOARD..........................................................7-5
[3]
[4]
R/C, LED UNIT PRINTED WIRING
BOARD........................................................7-13
[5]
CHAPTER 8. SCHEMATIC DIAGRAM
[1]
DESCRIPTION OF SCHEMATIC DIA-
GRAM............................................................8-1
[2]
Schematic Diagram ................................8-2
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
LC-19D1E/S-BK/WH

Advertisement

Table of Contents
loading

Related Manuals for Sharp LC-19D1E/S-BK/WH

Summary of Contents for Sharp LC-19D1E/S-BK/WH

  • Page 1: Service Manual

    TopPage LC-19D1E/S-BK/WH SERVICE MANUAL No. S58J9LC19D1ES LCD COLOUR TELEVISION LC-19D1E/S-BK/WH MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig- inal condition and only parts identical to those specified should be used.

  • Page 2: Safety Precaution

    LC-19D1E/S-BK/WH LC19D1E-BK SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.
  • Page 3 LC-19D1E/S-BK/WH Precautions for using lead-free solder Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 4: Specifications

    4.9 kg (Display only), 5.4 kg (Display with stand) Operating temperature As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.

  • Page 5: Operation Manual

    LC-19D1E/S-BK/WH [2] OPERATION MANUAL Remote control unit AV MODE (Standby/On) Select an audio and video setting. Enter standby mode or turn on the power. (Mute) (Display information) Switch the sound on and off. (Sound mode) DTV MENU Select the sound multiplex mode.
  • Page 6 LC-19D1E/S-BK/WH TV (Front/Side view) Power button MENU button (Input Source) button ) (Channel buttons) ( / ) (Volume buttons) Operation without a remote control unit TV control panel buttons Remote control buttons OPC indicator (Standby/On) indicator OPC sensor Remote control sensor...

  • Page 7: Dimensions

    LC-19D1E/S-BK/WH [3] DIMENSIONS [mm] 68.2 75.0 (68,2) (75,0) 462.0 49.0 (462,0) (49,0) 411.8 (411,8) 196.0 240.0 (196,0) (240,0) 100.0 (100,0) 1 – 4...
  • Page 8 LC-19D1E/S-BK/WH CHAPTER 2. LC19D1E-BK REMOVING OF MAJOR PARTS Service Manual [1] REMOVING OF MAJOR PARTS 1. Detach the RS232C COVER and BASS CONE COVER [1]. 2. Remove the 1 screw [2] and detach the STAND HINJI COVER. 3. Remove the 4 screws [3] and detach the STAND.
  • Page 9 LC-19D1E/S-BK/WH 7. Remove the 3 screws [6], 1screw [7] and detach the VESA ANG. 8. Remove the 2 shaft screws [8], 2 shaft screws [9], 3 screws [10] and detach the MAIN SHIELD. 9. Remove the1 screw [11] and detach the C.I. CARD ANG.
  • Page 10 LC-19D1E/S-BK/WH 11.Remove the 3 screws [12] Detach the CONTROL-BTN, SW UNIT BARRIER and detach the SW UNIT from CONTROL-BTN [11]. 12.Detach the SOURCE PWB SLD. 13.Remove the 2 screws [13] and detach the SP-HOLDER UNIT-L/R. 14.Remove the 11 screws [14] and detach the MAIN UNIT, POWER UNIT and SUB UNIT.
  • Page 11 LC-19D1E/S-BK/WH 16.Remove the 7 hooks [16] and detach the LCD PANEL MODULE from CAB-A. CAB-A LCD PANEL MODULE 2 – 4...
  • Page 12 LC-19D1E/S-BK/WH CHAPTER 3. LC19D1E-BK ADJUSTMENT PROCEDURE Service Manual [1] ADJUSTMENT PROCEDURE 1. After replacement of any PWB and/or IC for repair, note the following. When replacing the following units, be sure to prepare the new units loaded with updated software.
  • Page 13 LC-19D1E/S-BK/WH 2.2. How to connect Writer when upgrading MAIN/SUB MICON. 1. How to connect a tool for MAIN MICON Remove a cover above the EXT5 of the TV’s rear cabinet and connect 20P connector of I/O tool. Connect a 20P connector of RC32C ROM writer to a I/O tool.
  • Page 14 LC-19D1E/S-BK/WH 6. Choose “Create a new project workspace”. 7. Select “CPU family: M16C and Tool chain: None”. 3 – 3...
  • Page 15 LC-19D1E/S-BK/WH 8. Selects “R8C E8 system”. 9. Press “Complete”. 3 – 4...
  • Page 16 LC-19D1E/S-BK/WH 10.Press “Ok”. If second time, you can select “open a recent project work”. Choose “OK 11.Select “MCU Group: R8C/2A Grup, Devie: R5F212A8, Mode: program flash and Power supply: Power Target from Emulator (MAX 300mA) and 3.3V”. 3 – 5...
  • Page 17 LC-19D1E/S-BK/WH 12.Select “User Flash Area”. 13.Select “500000 bps”. 3 – 6...
  • Page 18 LC-19D1E/S-BK/WH 14.Input all zero (00000000000000). 15.Next display. 3 – 7...
  • Page 19 LC-19D1E/S-BK/WH 16.enter menu “debug”→”debug settings...”→”add” to add firmware file (Mot file). After it you can see firmware in “Download modules”. 3 – 8...
  • Page 20 LC-19D1E/S-BK/WH 18.Enter menu “Debug” → “DOWNLOAD modules” and select the firmware. 19.After updating. Then shut down “High Performance Embedded Workshop”, unplug 20PIN connector, and E8 firmware updating finish. 3 – 9...
  • Page 21 LC-19D1E/S-BK/WH 3.2. Main microprocessor software version upgrade 1. How to install 1) Create a folder to install the RC32C on the host PC. (Ex: RC32C) 2) Copy all the files located in RC32C folder on CD-ROM to the created folder on the host PC. (Ex.: copy e: rc32c *.* c: rc32c<Enter> e: a drive name of CD-ROM.)
  • Page 22 LC-19D1E/S-BK/WH 2. RC32C startup 1) Connect the LCD’s 20pin port which near FXT5 to the ROM writer using SDI interface cable, which comes with the RC32C. 2) Plug AC on, make sure power indicator on. 3) Connect the flash ROM writer to the host PC via USB cable.
  • Page 23 LC-19D1E/S-BK/WH (2) Click "Select" to specify FTD file. FTD file select key (3) Select FTD file for flash ROM rewrite, and then click "Open". Click 3 – 12...
  • Page 24 LC-19D1E/S-BK/WH (4) The details of FTD file are indicated on "ROM Info." tag. 4. Rewrite Flash ROM After the FTD file selection, select the area to rewrite; All, Block or Byte/HalfWord/Word. (Click the respective tag.) <Rewrite all area (All)> (1) Select “All” tag.
  • Page 25 LC-19D1E/S-BK/WH (2) Click “Select” to specify data file (.mot). Data file select key (3) Click “Write” to start the writing. Writing start During the writing, the mouse pointer turns into an hourglass. When the writing is completed, it turns back to the mouse pointer and the screen changes to the screen of the step (1).
  • Page 26 LC-19D1E/S-BK/WH 3.3. How to update the Digital Board Software. The method of updating digital board software on Flash Memory (IC4202) through the Digital Processor (IC4001) is as follows. • PCMCIA CARD (Compact Flash Memory) Method. NOTE: The PCMCIA method is only compatible with those PCs running XP Windows Version.
  • Page 27 LC-19D1E/S-BK/WH 2. Start "StorageMediaManager_ATV-DTV 1.3.2.exe". (Displayed as follows.) 3. Format the Drive Click the right button at E: drive (The drive that the media for PCMCIA update in.) And , choose "Format Drive". 4. Choose folder Choode this folder. 3 – 16...
  • Page 28 LC-19D1E/S-BK/WH 5. Write DTV software 1) Choose folder and "drag and drop" the DTV software. Drag & Drop the DTV Choose the folder which you stored the DTV software that you want to write in. 2) Wait for the finish.
  • Page 29 LC-19D1E/S-BK/WH 4. Entering and exiting the adjustment process mode 1. Press the “MAIN POWER” key, and make the TV set under operation off. (Or, remove the AC code of the television under operation from the outlet.) 2. While holding down the “VOL (-)” and “INPUT” keys on the set at once, Press the “MAIN POWER” key on the set to turn on the power. (Or, insert the AC power cord in the outlet to turn on the power.)

  • Page 30: Adjustment Process Mode Menu

    LC-19D1E/S-BK/WH 6. Adjustment process mode menu Page Line Item Description Remarks (adjustment detail, etc.) MODEL C165EA Model name display B882E E002-0 INCH SIZE Inch number display ERROR NO RESET Lamp Error count and Reset PUBLIC MODE Setting of Hotel Mode...

  • Page 31: Table Of Contents

    LC-19D1E/S-BK/WH Page Line Item Description Remarks (adjustment detail, etc.) SOUND4 HPFEN Setting of HPF ON/OFF except a HDMI input. Turn ON at 1. Setting of HPF 1st order IIR or 2nd order IIR except a HDMI input. HPFAPP 1st at 0. 2nd at 1.
  • Page 32 LC-19D1E/S-BK/WH Page Line Item Description Remarks (adjustment detail, etc.) D2-2 DVP2-2 adjustment Point 6 adjustment Point 6 adjustment Point 6 adjustment Point 5 adjustment Point 5 adjustment Point 5 adjustment Point 4 adjustment Point 4 adjustment Point 4 adjustment Point 3...
  • Page 33 N358 COLOR setting (Composite, S video) N358 AV TINT N358 TINT setting (Composite, S video) N358 AV SHARP V OVER N358 V picture quality setting (Composite, S video) N358 AV SHARP V UNDER N358 V picture quality setting (Composite, S video)
  • Page 34 SECAM TV TINT SECAM TINT setting (TV) SECAM AV TINT SECAM TINT setting (Composite, S video) SECAM TV SHARP V OVER SECAM V picture quality setting (TV) SECAM AV SHARP V OVER SECAM V picture quality setting (Composite, S video)
  • Page 35 1125I/50Hz SHARP H1 UNDER 1125I/50Hz H picture quality setting 1 (COMPONENT) 1125I/50Hz SHARP H2 OVER 1125I/50Hz H picture quality setting 2 (COMPONENT) 1125I 50Hz SHARP H2 UNDER 1125I/50Hz H picture quality setting 2 (COMPONENT) 750P/50Hz CONT 750P/50Hz CONTRAST setting (COMPONENT)
  • Page 36 DTV 525I COLOR 525I/60Hz COLOR setting (DTV) DTV 525I TINT 525I/60Hz TINT setting (DTV) DTV 525I SHARP V OVER 525I/60Hz V picture quality setting (DTV) DTV 525I SHARP V UNDER 525I/60Hz V picture quality setting (DTV) DTV 525I SHARP H1 OVER...
  • Page 37 HDMI 525P COLOR 525P COLOR setting (HDMI) HDMI 525P TINT 525P TINT setting (HDMI) HDMI 525P SHARP V OVER 525P V picture quality setting (HDMI) HDMI 525P SHARP V UNDER 525P V picture quality setting (HDMI) HDMI 525P SHARP H1 OVER...
  • Page 38 HDMI 1125I COLOR 1125I COLOR setting (HDMI) HDMI 1125I TINT 1125I TINT setting (HDMI) HDMI 1125I SHARP V OVER 1125I V picture quality setting (HDMI) HDMI 1125I SHARP V UNDER 1125I V picture quality setting (HDMI) HDMI 1125I SHARP H1 OVER...
  • Page 39 M2-21 DVP-M2 21 TEXTALL SHARP V TEXT ALL V picture quality setting (TV) TEXTALL SHARP H1 TEXT ALL SHARP H picture quality setting 1 (TV) TEXTALL SHARP H2 TEXT ALL SHARP H picture quality setting 2 (TV) M2-22 DVP-M2 22...
  • Page 40 SCART BRIGHT setting SCART COLOR SCART COLOR setting SCART TINT SCART TINT setting SCART SHARP V OVER SCART V picture quality setting SCART SHARP V UNDER SCART V picture quality setting SCART SHARP H1 OVER SCART H picture quality setting 1...
  • Page 41 LC-19D1E/S-BK/WH 7. Video signal adjustment procedure 1. AD-Converter Level Adjustment 1) Preparation * Prepare signal generator LEADER LT448. 2) 1080i input a) The method of a 1080i 75% COLOUR BAR signal input * Signal name: Select COLOUR BAR Please use the 3rd of three kinds of COLOUR BAR button which is compatible with LT446. (Press a button 3 times.) * Turn a rotary switch then select 02.
  • Page 42 LC-19D1E/S-BK/WH 2. TAMP adjustment 1) Receive PAL Standard colour bar signal (E-12ch). 2) Display the DVP layer page 1 of the adjustment process (DVP1) When reading values [TAMP 1L] [TAMP 1H] in this page are not in the value of the following table, select [TAMP ALL] in the same page (turn to OFF→ON), and adjust the maximum value of [YDATA] to become a value of the following table.

  • Page 43: Standard Value

    LC-19D1E/S-BK/WH 8. White Balance Adjustment 1. [Preparation of the adjustment] 1) “Luminance meter reference device” Minolta CA-210 2) Conditions of the set for adjustment and inspection Modulated light: MAX (+16) 3) A set needs to be ageing for 30 minutes or more.
  • Page 44 LC-19D1E/S-BK/WH 9. Lamp error detection 1. Function This LCD color TV set incorporates a lamp error detection feature that automatically turns off the power for safety under abnormal lamp or lamp circuit conditions. If by any chance anything is wrong with the lamp or lamp circuit or if the lamp error detection feature is activated for some rea- son, the following will result.
  • Page 45 LC-19D1E/S-BK/WH 10. Public Mode 1. How to enter Hotel menu 1) While pressing "INPUT" and "VOLOME UP" key on the main unit at the same time, Press the "MAIN POWER" key. If the hotel menu screen of 4 paragraphs goes out, it is a success.
  • Page 46 LC-19D1E/S-BK/WH 2) Explanation of Hotel menu Explanation Public mode It is an item that sets whether to use the hotel mode function in the adjustment process. Hotel mode means: The state (state of PUBLIC MODE=ON) after the hotel mode function is executed.
  • Page 47 LC-19D1E/S-BK/WH CHAPTER 4. LC19D1E-BK TROUBLESHOOTING TABLE Service Manual [1] TROUBLESHOOTING TABLE No power supplied (Front LED does not turn on). Power switched on but no power supplied. (Front LED does not turn Red →Green ) Are the power cord connector correctly connected to the body? Reconnect the power cord correctly and switch on the power again.
  • Page 48 LC-19D1E/S-BK/WH Power supply (troubleshooting): A power supply does not come to each main circuit or IC. (2) The power supply of a VIDEO system/IC801 (DVP) does not operate. Checklist: 1) The check of the front page POW (1) is completed.• • • UR12V is output to SC1204 (MAIN-PCB).
  • Page 49 LC-19D1E/S-BK/WH Power supply (troubleshooting): A power supply does not come to each main circuit or IC. (3) The power supply of a AUDIO system does not operate. Checklist: 1) The check of the front page POW (1) is completed. • • • UR12V is output to SC1204 (MAIN-PCB).
  • Page 50 LC-19D1E/S-BK/WH Power supply (troubleshooting): A power supply does not come to each main circuit or IC. (4) The power supply of a PANEL system does not operate. Checklist: 1) The check of the front page POW (1) is completed. • • • UR12V is output to SC1204 (MAIN-PCB).
  • Page 51 LC-19D1E/S-BK/WH No sound (1) (during the reception of DTV broadcasting) No audio output during DTV reception Checklist : 1) Is the volume set to MIN or MUTE on the remote control ? • • • Set the desired volume. 2) Is ANT-CABLE disconnected or connected improperly ? • • • Connect it correctly as per the operation manual.
  • Page 52 LC-19D1E/S-BK/WH No sound (2) (during the reception of TV broadcasting) No audio output during UHF/VHF reception Checklist: 1) Is the volume set to MIN or MUTE on the remote control? • • • Set the desired volume. 2) Is ANT-CABLE disconnected or connected improperly? • • • Connect it correctly as per the operation manual.
  • Page 53 LC-19D1E/S-BK/WH No sound from external input devices (3)-1 No sound from EXT1 (SCART) connecting an external input device. <EXT1> Check pins (6) and (2) of SCART1 and connection to an external Is SCART-L-IN audio signal input from pin (6) of SCART1 termi- input device.
  • Page 54 LC-19D1E/S-BK/WH No sound from external input devices (3)-2 No sound from EXT4 (MDMI-AUDIO) connecting an external input device. <EXT4> Is HDMI-L audio signal input from J504 to pin (8) of IC301 (A- Selector)? Is HDMI-R audio signal input from J504 to pin (5) of IC301 (A-...
  • Page 55 LC-19D1E/S-BK/WH No sound from external input devices (3)-3 No sound from EXT5 (AUDIO) connecting an external input device. <EXT5> Is PC-S-L audio signal input from J401 to pin (7) of IC301? Is PC-S-R audio signal input from J401 to pin (3) of IC301?
  • Page 56 L C - 1 9 D 1 E / S - B K /W H No sound except from speakers (4)-1 No audio output from headphone (J505). (AV-UNIT) Is there audio output signal on pins (2) and (3) of the headphone Check Headphone terminal (J505) and the connection to an terminal (J505)? external device.
  • Page 57 LC-19D1E/S-BK/WH <0n input of the DTVtuner> No picture on the display (1)-1 No picture appears on LCD during the DTV tuner reception. Checklist: on the remote control set up correctly ? • • • set it as "DTV" with the INPUT SOURCE button 1) Is "INPUT SOURCE"...
  • Page 58 LC-19D1E/S-BK/WH <0n input of the DTVtuner> No picture on the display (1)-2 No picture appears on LCD during the DTV tuner reception. Checklist: on the remote control set up correctly ? • • • set it as "DTV" with the INPUT SOURCE button 1) Is "INPUT SOURCE"...
  • Page 59 LC-19D1E/S-BK/WH <On input of the tuner (U/V)> No picture on the display (2) No picture appears on LCD during the tuner (U/V) reception. Checklist: on the remote control set up correctly? • • • Set it as “TV” with the INPUT SOURCE button 1) Is “INPUT SOURCE”...
  • Page 60 LC-19D1E/S-BK/WH <During external connection> No picture on the external monitor (3) SCART1: NNo picture appears on EXT1 -connected monitor during the DTV or tuner (U/V) reception. Checklist: on the remote control set up correctly? • • • See the operation manual and 1) Are input terminal on back of TV and “INPUT SOURCE”...
  • Page 61 LC-19D1E/S-BK/WH <When EXT1 is used for external input> No picture on the display (4)-1 No EXT1-Composite output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT1” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 62 LC-19D1E/S-BK/WH <When EXT1 is used for external input> No picture on the display (4)-2 No EXT1-RGB output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT1” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 63 LC-19D1E/S-BK/WH <When EXT1 is used for external input> No picture on the display (4)-3 No EXT1-Y/C output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT1” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 64 LC-19D1E/S-BK/WH <When EXT2 is used for external input> No picture on the display (5)-1 No EXT2-Composite output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT2” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 65 LC-19D1E/S-BK/WH <When EXT2 is used for external input> No picture on the display (5)-2 No EXT2-Y/C output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT2” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 66 LC-19D1E/S-BK/WH <When EXT3 is used for external input> No picture on the display (6) No EXT3 Component output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT3” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 67 LC-19D1E/S-BK/WH <When EXT4 is used for external input> No picture on the display (7) No EXT4 (HDMI) output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT4” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 68 LC-19D1E/S-BK/WH <When EXT5 is used for external input> No picture on the display (8) No EXT5 (PC- terminal) output of the external input system. Checklist: on the remote control set up correctly? • • • Set it as “EXT5” with the INPUT SOURCE button on the remote 1) Is “INPUT SOURCE”...
  • Page 69 LC-19D1E/S-BK/WH 19INV Backlight failure to light up Do all the fluorescent tubes light up? Check the individual fluorescent Replace any defective fluorescent tubes for light-up failure. tube (s) with new one (s). Remove CN2 connector of POWER Exchange the power supply units.
  • Page 70 LC-19D1E/S-BK/WH LED blinking timing table 250ms 1sec Type of error Kind of LED Power LED operation (1 cycle) Remarks H:OFF STANDBY Lamp error Blinking once L:ON H:OFF STANDBY Blinking once Lamp error L:ON At five time H:OFF The lamp is turned off when accumulation it is abnormal usually.

  • Page 71: Major Ic Informations

    LC-19D1E/S-BK/WH CHAPTER 5. LC19D1E-BK MAJOR IC INFORMATIONS Service Manual [1] MAJOR IC INFORMATIONS 1. MAJOR IC INFORMATIONS NO REF NO Name Part Code Description Drawing NO [MAIN UNIT] DVP-M2 is 1 chip picture signal processing LSI for flat panel displays corresponding to a multi-format (NATC/PAL/SECAM).
  • Page 72 LC-19D1E/S-BK/WH NO REF NO Name Part Code Description Drawing NO The WM8983 is a low power, high quality stereo codec designed for portable multimedia applications. The device integrates preamps for stereo differential mics, and includes drivers for speaker, headphone and differential or stereo line output.
  • Page 73 LC-19D1E/S-BK/WH NO REF NO Name Part Code Description Drawing NO Voltage Regula- This IC is a regulator IC for super-low current consumption that uses IC205 VHIMM3271AN-1Y tor: 1.0V-REG CMOS process. In this Model, this IC generates 1.0V-regurator. This IC can be used for the power regulator circuit up to 0.15A in cur-...
  • Page 74 LC-19D1E/S-BK/WH 2. Detailed ICs Information 2.1. IC202 (RH-iXB964WJZZQ) (STV0362) 2.1.1 Block Diagram 2.1.2 Pin Connections and short description DVB-T RECEIVER Pin No Pin Name Pin Function NOT_RESET Hardware reset, active Low. XTAL_I Crystal oscillator input/external clock(2.5V) XTAL_O Crystal oscillator output.
  • Page 75 LC-19D1E/S-BK/WH Pin No Pin Name Pin Function D/NOT_P MPEG data valid/parity ERROR MPEG packet error AGC_RF RF AGC control (5V tolerant ) AGC_IF IF AGC control (5V tolerant ) TEST Reserved test mode, must be grounded. GPIO0 General-purpose input/output port 0.
  • Page 76 LC-19D1E/S-BK/WH Pin Name Pin Function No Connction VOUT Voltage Output pin with ON/OFF control. (150mA) 2.3. IC303 (VHiBD5426MU-1Y) 2.3.1 Block Diagram 2.3.2 Pin Connections and short description STERO-POWER-AMP. Pin No. Pin Name Pin Function BSP2P ch2 The plus side boost strap terminal 2P (Lch+)
  • Page 77 LC-19D1E/S-BK/WH Pin No. Pin Name Pin Function VCCP1N ch1 Power supply terminal of the minus side power amplifier output (Rch-) N.C. No connection BSP1N ch1 The minus side boost strap terminal 2N (Rch-) WARNING Warning output terminal . It is a terminal which tells warning of operation.
  • Page 78 LC-19D1E/S-BK/WH 2.4. IC501 (VHiMM1492BJ-1Y) 2.4.1 Block Diagram 5 – 8...
  • Page 79 LC-19D1E/S-BK/WH 2.4.2 Pin Connections and short description A/V SWITCH (12C BUS) Pin No. Pin Name Pin Function V1-V Video input terminal V1-Y (Composite or Y) V2-V *Sync chip clamp V2-Y V3-V STV-V YIN2 YIN1 MTV-V V1-L Audio input terminal V1-R...
  • Page 80 LC-19D1E/S-BK/WH 2.5. IC502 (VHiM3221EIP-1Y) 2.5.1 Block Diagram 2.5.2 Pin Connections and short description RS232C-DRIVER/RECEIVER Pin No. Pin Name Pin Function Receiver Enable Control . Drive low for normal operation. Drive high to force the receiver outputs (R_OUT) into a high-impedance state.
  • Page 81 LC-19D1E/S-BK/WH 2.6. IC701 (VHiBD9306AF-1Y) 2.6.1 Block Diagram 2.6.2 Pin Connections and short description 1ch Step Down switching regulato Pin No. Pin Name Pin Function Timing Resistor external terminal. Timing Capacitor external terminal. Control terminal. Gate drive output terminal. Power supply terminal.
  • Page 82 LC-19D1E/S-BK/WH 2.7. IC506, IC4605 (VHiNJM4565V-1Y) 2.7.1 Block Diagram 2.7.2 Pin Connections and short description DUAL OP-AMP Pin No. Pin Name Pin Function A OUTPUT A output A +INPUT A + input A -INPUT A - input Ground B +INPUT B + input...
  • Page 83 LC-19D1E/S-BK/WH 2.8. IC507 (VHiTL52055D-1Y) 2.8.1 Block Diagram 2.8.2 Pin Connections and short description 3-Video-SW Pin No. Pin Name Pin Function 1ch Input B. 1ch Control Signal. 1ch Output. GND2 2ch Ground 2ch Output. 3ch Output. 3ch Contrl Signal. 3ch Input A.
  • Page 84 LC-19D1E/S-BK/WH 2.9. IC508 (VHiMM1507XN-1) 2.9.1 Block Diagram 2.9.2 Pin Connections and short description 2-INPUT,1-OUTPUT SW Pin No. Pin Name Pin Function control signal Video out Power Supply Input video signal 2 Ground. Input video signal 1 5 – 14...
  • Page 85 LC-19D1E/S-BK/WH 2.10. IC4001 (RH-iXC243WJZZQ) 2.10.1 Block Diagram 2.10.2 Pin Connections and short description DIGITAL PROCESSOR Analog power supply pin Pin No. Pin Name Pin Function sheet name Audio DAC VDDAADAC 3.3v power for audio DAC P3V3 GNDAADAC Ground for audio DAC...
  • Page 86 LC-19D1E/S-BK/WH Pin No. Pin Name Pin Function sheet name LMI SDRAM VDDDLL 1.2V for DLL. P1V2 GNDDLL Ground for DLL. ground VDDDE0 1.2V for delay element 1. P1V2 VSSDE0 Ground for delay element 1. ground VDDDE1 1.2V for delay element 2.
  • Page 87 LC-19D1E/S-BK/WH Pin No. Pin Name Pin Function sheet name FMIADDR14 Adress data 14 (for flash ) FMIADDBE14 FMIADDR13 Adress data 13 (for flash ) FMIADDBE13 FMIADDR12 Adress data 12 (for flash ) FMIADDBE12 FMIADDR11 Adress data 11 (for flash )
  • Page 88 LC-19D1E/S-BK/WH Pin No. Pin Name Pin Function sheet name NOT_LMICAS Latch column address strobe NLMICASBE LMICLKEN Clock enable LMICLKENBE LMICLKEN Clock LMICLKBE NOT_LMICLK inverted clock(DDR). Not used when SDR connected to LMI LMINCLKBE LMI_VREF Input reference voltage (DDR). Connected to ground when SDR LMIVREF is connected to LMI.
  • Page 89 LC-19D1E/S-BK/WH Alternative function Description Usual assignment sheet name PIO0[7] PIO port 0 [7] FERESET PIO0[6] PIO port 0 [6] TSSWITCH PIO0[5] PIO port 0 [5] NOTREADY PIO0[4] PIO port 0 [4] NOTRE- SETCI PIO0[3] PIO port 0 [3] FLASHWP PIO0[2]...
  • Page 90 LC-19D1E/S-BK/WH 2.11. IC4201 (RH-iXB765WJZZ) 2.11.1 Block Diagram 2.11.2 Pin Connections and short description 256Mb DDR SDRAM Pin No. Pin Name Pin Function 45,46 CK, CK Clock : CK and CK are differential clock inputs. All address and control input signals are sampled on the positive edge of CK and negative edge of CK.
  • Page 91 LC-19D1E/S-BK/WH Pin No. Pin Name Pin Function 28-32, 35-42 A [0 : 12] Address Inputs : Provide the row address for ACTIVE commands, and the column address and AUTO PRECHARGE bit for READ/WRITE commands, to select one location out of the memory array in the respective bank.
  • Page 92 LC-19D1E/S-BK/WH 2.12.2 Pin Connections and short description 16Mbit Flash Memory Pin No Pin Name Pin Function 1-9,16-25,48 A0-A19 Address Inputs 29,31,33,35,38,40,42,44 DQ0-DQ7 Data Inputs/Outputs 30,32,34,36,39,41,43 DQ8-DQ14 Data Inputs/Outputs DQ15A?1 Data Input/Output or Address Input Chip Enable Output Enable Write Enable...
  • Page 93 LC-19D1E/S-BK/WH 2.14. IC4401 (VHiLCX245FT-1Y) 2.14.1 Block Diagram 2.14.2 Pin Connections and short description Bus Tranceiver Pin No. Pin Name Pin Function Directory. A-Bus. Output/Input Terminal A1. A-Bus. Output/Input Terminal A2. A-Bus. Output/Input Terminal A3. A-Bus. Output/Input Terminal A4. A-Bus. Output/Input Terminal A5.
  • Page 94 LC-19D1E/S-BK/WH 2.15. IC4402 (VHiLCX16244-1Y) 2.15.1 Block Diagram 2.15.2 Pin Connections and short description Quad Bus Buffer Pin No. Pin Name Pin Function Output Enable terminal 1 Output terminal 1Y1 Output terminal 1Y2 Ground Output terminal 1Y3 Output terminal 1Y4 Power supply...
  • Page 95 LC-19D1E/S-BK/WH Pin No. Pin Name Pin Function Output terminal 3Y1 Output terminal 3Y2 Ground Output terminal 3Y3 Output terminal 3Y4 Power supply Output terminal 4Y1 Output terminal 4Y2 Ground Output terminal 4Y3 Output terminal 4Y4 Output Enable terminal 4 Output Enable terminal 3...
  • Page 96 LC-19D1E/S-BK/WH 2.16. IC4405 (VHiLCX126FT-1Y) 2.16.1 Block Diagram 2.16.2 Pin Connections and short description Quad Bus Buffer Pin No. Pin Name Pin Function Enable terminal 1 Input terminal 1A Output terminal 1Y Enable terminal 2 Input terminal 2A Output terminal 2Y...
  • Page 97 LC-19D1E/S-BK/WH 2.17. IC4603 (VHiTHS7314D-1Y) 2.17.1 Block Diagram 2.17.2 Pin Connections and short description 3CH V-AMP Pin No. Pin Name Pin Function CH.1 IN Video input - channel 1 CH.2 IN Video input - channel 2 CH.3 IN Video input - channel 3...
  • Page 98 LC-19D1E/S-BK/WH — MEMO — 5 – 28...

  • Page 99: Chapter 6. Block Diagram/Wiring Diagram 1] Block Diagram

    LC-19D1E/S-BK/WH LC19D1E-BK CHAPTER 6. BLOCK DIAGRAM/WIRING DIAGRAM Service Manual [1] BLOCK DIAGRAM SYSTEM BLOCK DIAGRAM 6 – 1...

  • Page 100: Power Block Diagram

    LC-19D1E/S-BK/WH [2] POWER BLOCK DIAGRAM POWER BLOCK DIAGRAM 6 – 2...

  • Page 101: Wiring Diagram

    LC-19D1E/S-BK/WH [3] WIRING DIAGRAM WIRING DIAGRAM 6 – 3...

  • Page 102: Chapter 7. Printed Wiring Board 1] Main Unit Printed Wiring Board

    LC-19D1E/S-BK/WH LC19D1E-BK CHAPTER 7. PRINTED WIRING BOARD Service Manual [1] MAIN UNIT PRINTED WIRING BOARD MAIN Unit ( Side- LUG1202 S M T DUNTKE683WE P2001 P801 P2003 R909 C1010 R1023 R1016 SC9201 IC702 R1008 AUDIO(R/L) R9327 C9230 R9325 D2001 R9333...
  • Page 103 LC-19D1E/S-BK/WH MAIN Unit (Chip Side- R905 P2001 P2003 P801 LUG1202 LUG1201 SC9201 C1010C1011 R1023R1024 C1014 R730 C1007 R1012 R1016 R1014 Q2002 R9327 R9330 R9333 R9325 R1017 R1002 R1001 R1011 R1008 C1005 R9326 R9328R9329 R9331 R9332 R9334 C9230 FB405 R1003 R1007...
  • Page 104 LC-19D1E/S-BK/WH MAIN Unit ( Side- S M T FB2001 C2012 C2013 C2011 R921 R922 FB2002 R907 C1021 R901 R1020 C1002 IC701 C9228 C9235 C9229 C1009 C9204 C9302 R911 R9369 C9306 C9203 C1004 C730 C1003 FB9203 R718 IC2003 R2002 R822 R1019...
  • Page 105 LC-19D1E/S-BK/WH MAIN Unit (Chip Side- C2012 C2013 C2011 FB2001 FB2002 R921 R922 R907 C1021 C1002 C1009 Q707 R701 C9235 R901 R911 C1004 C9302 C730 C1003 R718 R9369 C733 R1019 R902 C9304 R706 R705 R734 IC9202 R735 C731 R9371 C701 C9231...

  • Page 106: Digital Tuner Unit Printed Wiring Board

    LC-19D1E/S-BK/WH [2] DIGITAL TUNER UNIT PRINTED WIRING BOARD DIGITAL TUNER Unit (Side-A) J504 E F G H R525 R513 P500 R570 P502 C542 IC503 Q511 P501 IC505 FB502 C512 IC508 R631 R519 D517 D531 R561 C525 R537 R632 IC507 FB509...
  • Page 107 LC-19D1E/S-BK/WH DIGITAL TUNER Unit (Chip Side-A) R513 R525 Q520 R570 Q511 Q512 IC503 D531 FB502 C542 R519 R537 R631 D517 R561 C512 IC508 C525 R632 C581 L501 C539 C530 IC507 R263 C219 IC204 C586 Q209 C524 R227 L203 C217 IC209...
  • Page 108 LC-19D1E/S-BK/WH DIGITAL TUNER Unit (Side-B) J504 P501 P502 P500 Q515 Q526 D512 IC509 Q522 R625 IC203 J505 C577 IC501 R623 Q524 7 – 7...
  • Page 109 LC-19D1E/S-BK/WH DIGITAL TUNER Unit (Chip Side-B) Q515 Q514 Q502 Q504 IC509 Q518 Q503 Q212 Q526 Q505 Q513 Q522 Q523 IC203 Q524 IC501 Q506 Q508 D527 Q509 7 – 8...

  • Page 110: Sub Unit Printed Wiring Board

    LC-19D1E/S-BK/WH [3] SUB UNIT PRINTED WIRING BOARD SUB Unit (Side-A) E F G H LUG4002 C4613 R4635 C4645 C4617 C4622 IC4601 FB4602 C4646 C4636 FB4401 C4402 C4418 C4623 C4624 C4634 C4618 R4622 C4401 IC4602 R4619 R4257 C4631 R4655 D4605 C4237...
  • Page 111 LC-19D1E/S-BK/WH SUB Unit (Chip Side-A) C4613 C4617 R4635 C4645 C4619 C4622 FB4602 C4418 C4646 C4623 IC4601 C4636 FB4401 C4624 C4402 C4618 C4634 R4622 C4620 C4401 R4619 R4257 IC4604 IC4602 C4631 D4605 R4458 R4459 L4602 C4237 R4671 C4045 C4008 C4635 IC4406...
  • Page 112 LC-19D1E/S-BK/WH SUB Unit (Side-B) D4603 R4639 R4640 R4638 R4653 C4603 C4602 R4654 C4605 FB4603 R4628 R4636 C4614 R4447 C4239 D4604 C4419 R4420 R4634 C4423 FB4604 C4416 R4431 R4415 R4434 C4403 R4416 IC4204 FB4403 R4414 R4417 C4405 R4402 R4670 R4426 C4422...
  • Page 113 LC-19D1E/S-BK/WH SUB Unit (Chip Side-B) D4603 R4653 C4603 R4639 R4638 R4640 C4602 R4654 C4605 FB4603 R4628 C4239 R4447 C4614 R4636 D4604 C4419 R4420 C4423 R4431 C4403 C4416 R4414 R4434 FB4604 Q4602 IC4204 R4415 R4416 FB4403 R4417 R4670 C4405 C4422 R4664...

  • Page 114: R/C, Led Unit Printed Wiring Board

    LC-19D1E/S-BK/WH [4] R/C, LED UNIT PRINTED WIRING BOARD Chip R/C, LED Unit (Side-A) R/C, LED Unit ( Side-A) R/C, LED Unit (Side-B) R/C, LED Unit ( Side-B) R122 Q103 R109 R108 R104 P101 R135 R124 C105 R101 Q107 7 – 13...

  • Page 115: Key Unit Printed Wiring Board

    LC-19D1E/S-BK/WH [5] KEY UNIT PRINTED WIRING BOARD Side-A Chip Side-A Side-B Chip Side-B KEY Unit ( KEY Unit ( KEY Unit ( KEY Unit ( P151 D155 D155 7 – 14...

  • Page 116: Description Of Schematic Dia Gram

    LC-19D1E/S-BK/WH LC19D1E-BK CHAPTER 8. SCHEMATIC DIAGRAM Service Manual [1] DESCRIPTION OF SCHEMATIC DIAGRAM VOLTAGE MEASUREMENT CONDITION: 1. The voltages at test points are measured on exclusive AC adaptor and the stable supply voltage of AC 230V. Signals are fed by a colour bar signal generator for servicing purpose and the above voltages are measured with a 20k ohm/V tester.

  • Page 117: Schematic Diagram

    LC-19D1E/S-BK/WH [2] SCHEMATIC DIAGRAM MAIN Unit-1 8 – 2...
  • Page 118 LC-19D1E/S-BK/WH MAIN Unit-2 8 – 3...
  • Page 119 LC-19D1E/S-BK/WH MAIN Unit-3 8 – 4...
  • Page 120 LC-19D1E/S-BK/WH MAIN Unit-4 8 – 5...
  • Page 121 LC-19D1E/S-BK/WH MAIN Unit-5 8 – 6...
  • Page 122 LC-19D1E/S-BK/WH MAIN Unit-6 8 – 7...
  • Page 123 LC-19D1E/S-BK/WH MAIN Unit-7 8 – 8...
  • Page 124 LC-19D1E/S-BK/WH MAIN Unit-8 8 – 9...
  • Page 125 LC-19D1E/S-BK/WH MAIN Unit-9 8 – 10...
  • Page 126 LC-19D1E/S-BK/WH DIGITAL TUNER Unit-1 AND SHADED COMPONENTS=SAFETY RELATED PARTS 8 – 11...
  • Page 127 LC-19D1E/S-BK/WH DIGITAL TUNER Unit-2 8 – 12...
  • Page 128 LC-19D1E/S-BK/WH SUB Unit-1 8 – 13...
  • Page 129 LC-19D1E/S-BK/WH SUB Unit-2 8 – 14...
  • Page 130 LC-19D1E/S-BK/WH SUB Unit-3 8 – 15...
  • Page 131 LC-19D1E/S-BK/WH SUB Unit-4 8 – 16...
  • Page 132 LC-19D1E/S-BK/WH R/C, LED Unit 8 – 17...
  • Page 133 LC-19D1E/S-BK/WH KEY Unit 8 – 18...
  • Page 134 LC-19D1E/S-BK/WH — MEMO — 8 – 19...
  • Page 135 LC-19D1E/S-BK/WH PartsGuide PARTS GUIDE No. S58J9LC19D1ES LCD COLOUR TELEVISION LC-19D1E/S-BK/WH MODELS CONTENTS PRINTED WIRING BOARD KEY Unit (DUNTKE249WE01) ASSEMBLY CABINET PARTS LCD PANEL LCD PANEL MAIN Unit (DUNTKE683FM07) [10] SUPPLIED ACCESSORIES DIGITAL TUNER Unit Unit (DUNTKE243FM02) [11] PACKING PARTS DIGITAL Unit (DUNTKE523FM01)
  • Page 136 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [1] PRINTED WIRING BOARD ASSEMBLY MAIN Unit DUNTKE683FM07 DIGITAL TUNER Unit DUNTKE243FM02 SUB Unit DUNTKE523FM01 R/C LED Unit DUNTKE248WE01 SW Unit DUNTKE249WE01 RDENCA242WJQ1 POWEWR Unit (Unit Replacement Item [2] LCD PANEL 18.5"...
  • Page 137 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] MAIN Unit (DUNTKE683FM07) C708 Capacitor 10 16V Ceramic RC-KZA237WJZZY C709 Capacitor 4700p 25V Ceramic VCKYCZ1EB472KY C710 Capacitor 1 25V Ceramic RC-KZA104WJZZY C711 Capacitor 10 16V Ceramic RC-KZA237WJZZY C712 Capacitor 10 16V Ceramic...
  • Page 138 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] MAIN Unit (DUNTKE683FM07) C874 Capacitor 10 16V Ceramic RC-KZA237WJZZY C875 Capacitor 10 16V Ceramic RC-KZA237WJZZY C876 Capacitor 0.1 10V Ceramic VCKYCZ1AB104KY C877 Capacitor 10 16V Ceramic RC-KZA237WJZZY C878 Capacitor 0.1 10V Ceramic...
  • Page 139 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] MAIN Unit (DUNTKE683FM07) C9228 Capacitor 0.01 25V Ceramic VCKYCZ1EB103KY C9229 Capacitor 0.01 25V Ceramic VCKYCZ1EB103KY C9230 Capacitor 0.01 25V Ceramic VCKYCZ1EB103KY C9231 Capacitor 220p 50V Ceramic VCCCCZ1HH221JY C9232 Capacitor 220p 50V Ceramic...
  • Page 140 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] MAIN Unit (DUNTKE683FM07) L703 Coil Peaking 33µH VPCBM330K1R7NY L704 Coil CILPA192WJ RCiLPA192WJZZY L705 Coil Peaking 47µH VPCEM470M3R7NY L706 Coil CILPA898WJ RCiLPA898WJZZY LUG1201 QLUGHA006WJZZY LUG1202 QLUGHA006WJZZY P301 Plug 4pin (SP) QPLGNA173WJZZY...
  • Page 141 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] MAIN Unit (DUNTKE683FM07) R701 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R702 Resistor 220k 1/16W Metal Oxide VRS-CZ1JF224JY R703 Resistor 4.7k 1/16W Metal Oxide VRS-CZ1JF472JY R704 Resistor 10k 1/16W Metal Oxide...
  • Page 142 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] MAIN Unit (DUNTKE683FM07) R888 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R889 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R895 Resistor 10k 1/16W Metal Oxide VRS-CK1JF103JY R896 Resistor 10k 1/16W Metal Oxide...
  • Page 143 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [3] MAIN Unit (DUNTKE683FM07) R8709 Resistor 47 1/16W Metal Oxide VRS-CZ1JF470JY R8717 Resistor 3.9 1/16W Metal Oxide VRS-CZ1JF3R9JY R8718 Resistor 3.9 1/16W Metal Oxide VRS-CZ1JF3R9JY R8719 Resistor 3.9 1/16W Metal Oxide...
  • Page 144 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DIGITAL TUNER Unit Unit (DUNTKE243FM02) C256 Capacitor 0.1 16V Ceramic VCKYCY1CB104KY C258 Capacitor 12p 50V Ceramic VCCCCZ1HH120JY C259 Capacitor 10p 50V Ceramic VCCCCZ1HH100DY C261 Capacitor 0.1 16V Ceramic VCKYCY1CB104KY C262 Capacitor 0.1 10V Ceramic...
  • Page 145 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DIGITAL TUNER Unit Unit (DUNTKE243FM02) C584 Capacitor 10 16V Ceramic RC-KZA237WJZZY C585 Capacitor 10 16V Ceramic RC-KZA237WJZZY C586 Capacitor 10 16V Ceramic RC-KZA237WJZZY C587 Capacitor 1 10V Ceramic VCKYCY1AB105KY C588 Capacitor 0.1 16V Ceramic...
  • Page 146 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DIGITAL TUNER Unit Unit (DUNTKE243FM02) L501 Coil CILPA898WJ RCiLPA898WJZZY LUG201 QLUGHA009WJZZY LUG202 QLUGHA009WJZZY P202 Connector 23pin QCNCMA250WJZZ P500 Connector 23pin (MA) QCNCMA250WJZZ P501 QCNCMA250WJZZ Connector 23pin (MB) P502 Connector 23pin (MC)
  • Page 147 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DIGITAL TUNER Unit Unit (DUNTKE243FM02) R526 Resistor 3.3k 1/16W Metal Oxide VRS-CZ1JF332JY R527 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY R528 Resistor 100 1/16W Metal Oxide VRS-CY1JF101JY R531 Resistor 10k 1/16W Metal Oxide...
  • Page 148 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [4] DIGITAL TUNER Unit Unit (DUNTKE243FM02) R652 Resistor 3.3k 1/16W Metal Oxide VRS-CY1JF332JY R653 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R654 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R655 Resistor 10k 1/16W Metal Oxide...
  • Page 149 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DIGITAL Unit (DUNTKE523FM01) C4425 Capacitor 1000p 50V Ceramic VCKYCZ1HB102KY C4601 Capacitor 10 16V Ceramic RC-KZA510WJPZY C4602 Capacitor 10 16V Ceramic RC-KZA510WJPZY C4603 Capacitor 10 16V Ceramic RC-KZA510WJPZY C4604 Capacitor 10 16V Ceramic...
  • Page 150 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DIGITAL Unit (DUNTKE523FM01) L4603 Coil Peaking 5.6µH VPSBN5R6JR90NY LUG4001 QLUGHA009WJZZY LUG4002 QLUGHA009WJZZY LUG4003 QLUGHA009WJZZY P4001 Plug, 4pin (RS) QPLGN0463TAZZY Q4001 VS2SC3928AR-1Y Transistor 2SC3928A-T112-1R Q4002 Transistor 2SC3928A-T112-1R VS2SC3928AR-1Y Q4003 Transistor 2SC3928A-T112-1R...
  • Page 151 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DIGITAL Unit (DUNTKE523FM01) R4254 Resistor 0 1/16W Metal Oxide VRS-CZ1JF000JY R4255 Resistor 0 1/16W Metal Oxide VRS-CZ1JF000JY R4257 Resistor 10k 1/16W Metal Oxide VRS-CZ1JF103JY R4258 Resistor 5.6k 1/16W Metal Oxide...
  • Page 152 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [5] DIGITAL Unit (DUNTKE523FM01) R4619 Resistor 150k 1/16W Metal Oxide VRS-CZ1JF154FY R4620 Resistor 33 1/16W Metal Oxide VRS-CZ1JF330FY R4621 Resistor 82k 1/16W Metal Oxide VRS-CZ1JF823FY R4622 Resistor 39k 1/16W Metal Oxide...
  • Page 153 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [7] KEY Unit (DUNTKE249WE01) D151 Zener Diode PDZ15B,115 RH-EX0269TAZZY D152 Zener Diode PDZ15B,115 RH-EX0269TAZZY D155 Zener Diode PDZ15B,115 RH-EX0269TAZZY P151 Plug 4pin (LF) QPLGNA324WJZZY R151 Resistor 8.2k 1/16W Metal Oxide VRS-CY1JF822JY...
  • Page 154 LC-19D1E/S-BK/WH [8] CABINET PARTS...
  • Page 155 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [8] CABINET PARTS CAB-A Ass'y (LC-19D1E/K/S BK) CCABAB811WJ15 CAB-A Ass'y (LC-19D1E/K/S WH) CCABAB811WJ16 CAB-A Not Available SP NET (LC-19D1E/K/S BK) GCOVAC325WJ4A SP NET (LC-19D1E/K/S WH) GCOVAC325WJ4B LED DEC COVER HDECQA765WJ4A MASK HIMELON-S, x2...
  • Page 156 LC-19D1E/S-BK/WH [9] LCD PANEL 30-1 30-2 30-3 PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [9] LCD PANEL 18.5" WXGA LCD Panel Module R1LK185T3GW10W 30-1 Sheild Plate (Bezel) LANGK4033TPZZ 30-2 BL Unit KLMPY0752TPZZ 30-3 Screw (S-PWB fix), x3 LX-BZ2308TPZZ...
  • Page 157 LC-19D1E/S-BK/WH [10] SUPPLIED ACCESSORIES PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [10] SUPPLIED ACCESSORIES Remote Control Unit (LC-19D1E/K/S BK) RRMCGA608WJSA Remote Control Unit (LC-19D1E/K/S WH) RRMCGA608WJSB AC Code for EUROPE without U.K. QACCKA021WJPZ AC Code for U.K. QACCBA073WJPZ Cable Clamp (LC-19D1E/K/S BK)
  • Page 158 LC-19D1E/S-BK/WH [11] PACKING PARTS PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [11] PACKING PARTS PACK CASE SPAKCE216WJZZ HOSO PP SPAKPA995WJ1Z PACK AD-BOTTOM SPAKXB742WJ1Z SPAKXB741WJ1Z PACK AD-TOP SSAKAA072WJZZ SACK, x2 FOR STAND PP SPAKPA909WJZZ POLY BUG, x2 SSAKAA010WJZZ PACK CASE LABEL...
  • Page 159 LC-19D1E/S-BK/WH PRICE PART PARTS CODE DESCRIPTION RANK MARK DELIVERY [12] SERVICE JIG FFC 80pins L=500mm, Main Unit to LCD Panel Module Unit QCNW-C458WJQZ 15pins, Main Unit to Power Unit QCNW-D431WJZZ Board to Board Connector 23pins L=1000mm, Main to Sub Unit...
  • Page 160 LC-19D1E/S-BK/WH COPYRIGHT © 2008 BY SHARP CORPORATION ALL RIGHTS RESERVED. No Part of this publication may be reproduced, stored in a retrieval system, or transmitted in any from or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

Table of Contents
