Terbly V250SP User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

PROFESSIONAL MOVING HEAD USER'S
MANUAL
V250SP
KEEP THIS MANUAL FOR FUTURE NEEDS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V250SP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Terbly V250SP

Summary of Contents for Terbly V250SP

  • Page 1 PROFESSIONAL MOVING HEAD USER’S MANUAL V250SP KEEP THIS MANUAL FOR FUTURE NEEDS...
  • Page 2 XM158 V1.0-NR...
  • Page 3 Thank you for your patronage. We are confident that our excellent products and service can satisfy you. For your own safety, please read this user manual carefully before installing the device. Keep this device away from rain and moisture ! Unplug mains lead before opening the housing.

  • Page 4: Safety Instructions

    _Editable program: Edit and save the program to inside EEPROM via the control board or external controller, up to 48 scenes can be saved and then can be run in Stand Alone or sound activated. _Number of scenes in Program Run can be changed individually SAFETY INSTRUCTIONS Be careful with your operations.With a dangerous voltage you can Suffer a dangerous electric shock when touching wires!

  • Page 5: General Guidelines

    Never touch the device during operation! The housing may heat up Never look directly into the light source, as sensitive persons may suffer an epileptic shock. Please be aware that damages caused by manual modifications to the device are not subject to warranty.
  • Page 6 Only install the lamp with the device unplugged from the mains. The lamp has to be replaced when it is damaged or deformed. Before replacing the lamp let the lamp cool down, because during operation, the lamp can reach very high temperature.

  • Page 7: Mounting The Device

    Please remember the lamp is not a hot-restrike type, you must wait for approximately 10 minutes after having turned off the lamp before you can turn it back on again. Do not operate this device with open cover b) Mounting the device The applicable temperature for the lighting is between -25°C to 45°C.
  • Page 8 Overhead mounting requires extensive experience, including amongst others calculating working load limits, installation material being used, and periodic safety inspection of all installation material and the device. If you lack these qualifications, do not attempt the installation yourself. Improper installation can result in bodily injury. The electric connection must only be carried out by a qualified electrician.

  • Page 9: Dmx-512 Control Connection

    Screw one clamp each via a M12 screw and nut onto the Omega holders. Insert the quick-lock fasteners of the first Omega holder into the respective holes on the bottom of the device. Tighten the quick-lock fasteners fully clockwise. Install the second Omega holder. Pull the safety-rope through the holes on the bottom of the base and over the trussing system or a safe fixation spot.

  • Page 10: Control Board

    Address Address Address 1 All fixtures should be given a DMX starting address when using a DMX signal, so that the correct fixture responds to the correct control signals. This digital starting address is the channel number from which the fixture starts to “listen” to the digital control information sent out from the DMX controller.
  • Page 11 Lamp On or Off ON/OFF Lamp on/off Automatic La-On ON/OFF Lamp on/off when Power on Lamp On Via DMX ON/OFF Lamp on via DMX Lamp Off Via DMX ON/OFF Lamp off via DMX Lamp Off No DMX OFF, OFF~19M Lamp off if no DMX Lamp On at Temp.

  • Page 12: Function Mode

    Select Programs Auto Pro Part 1 Program 1 ~ 10 Program 1 Select programs to be run Auto Pro Part 2 Program 1 ~ 10 Program 2 Auto Pro Part 3 Program 1 ~ 10 Program 3 Edit Program Program 1 Program Test (“STEP XX”) Testing program...

  • Page 13: Software Version

    lamp. • Select “Clear lamp time” by turning the encoder. • Press the encoder, the display shows “ON” or “OFF”. • Press the encoder to confirm. • Press the Mode/Esc-button in order to return to the main menu. Temp. Info. Base Temp With this function you can display the temperature in the projector base (near LCD-display) in Celsius.

  • Page 14: Status Setting

    Lamp Off if no DMX With this function you can select to switch off the lamp off automatically if there is no DMX signal). Select “ON” by turning the encoder if you wish to enable this function or “OFF” if you don’t. Lamp on at temp.

  • Page 15: Initial Effect

    Movement Speed With this function, you can select scan mode from 1 to 4. Mic Sensitivity With this function, the default is 70%, you can select the desired microphone sensitivity from 0 % to 99 %. Service setting Service Password With this function, you can set the service password.

  • Page 16: Users Mode Set

    Users mode set In this menu, user can select different channels list by different sequence: For example, after the user enter this manual, if select Auto Program = CH 15, means in this User’s mode, the “Dimmer” is in Channel 11. User mode With this function, you can create user defined channel orders.
  • Page 17 ･ Turn the encoder to select “Master” or “Alone”. The selection "Alone" means Stand Alone-mode and "Master" that the device is defined as master. ･ Press the Enter button to confirm. ･ Press the Mode/Esc button in order to return to the main menu. 3.
  • Page 18 DMX channel´s functions and their values (16 DMX channels): Channel 1 - Color Wheel : 0-13 Open / white Color 1 14-27 Color 2 28-41 Color 3 42-55 Color 4 56-69 Color 5 70-83 Color 6 84-97 Color 7 98-111 Color 8 112-127 128-189...
  • Page 19 140-159 Gobo 4 shake slow to fast 160-179 Gobo 5 shake slow to fast 180-199 Gobo 6 shake slow to fast 200-219 Gobo 7 shake slow to fast 220-255 Rot. gobo wheel cont. rotation slow to fast Channel 3 - Rotating gobo index, rotating gobo rotation : 0-127 Gobo indexing 128-189...
  • Page 20 4-63 Forwards rotation from fast to slow 64-67 No rotation 68-127 Backwards rotation from slow to fast 128-135 Macro 1 136-143 Macro 2 144-151 Macro 3 152-159 Macro 4 160-167 Macro 5 168-175 Macro 6 176-183 Macro 7 184-191 Macro 8 192-199 Macro 9 200-207...

  • Page 21: Error Codes

    0-191 Frost 0~100% 192-223 Pulse opening fast to slow 224-254 Pulse closing slow to fast 100% Frost Channel 14– Lamp on/off, reset, internal programs: 0-19 Color&Gobo change normal 20-29 Color change to any position 30-39 Color&Gobo change to any position 40-59 Lamp on 60-79...

  • Page 22: Cleaning And Maintenance

    Rotating gobo-wheel error: The gobo-wheel is not located in the default position after start-up or after a reset command. This message will appear after a fixture reset if the magnetic-indexing circuit malfunctions (sensor failed or magnet is missing) or there is a stepper motor failure (defective motor or a defective motor IC drive on the main PCB). Rotating gobo indexing error: The gobo is not located in the default position after start-up or after a reset command.

  • Page 23: Technical Specifications

    We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth. Never use alcohol or solvents. There are no serviceable parts inside the device except for the lamp. Please refer to the instructions under “Installation instructions”. Should you need any spare parts, please order genuine parts from your local dealer.
