DCR-PC109/PC109E
SERVICE MANUAL
Ver 1.0 2004. 01
Revision History
Revision History
How to use
How to use
Acrobat Reader
Acrobat Reader
Link
Link
SPECIFICATIONS
SPECIFICATIONS
SERVICE NOTE
SERVICE NOTE
DISASSEMBLY
DISASSEMBLY
• For ADJUSTMENTS (SECTION 6), refer to SERVICE MANUAL, ADJ (987670651.pdf).
• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (987670641.pdf). (EXCEPT J MODEL)
• For MECHANISM ADJUSTMENTS, refer to the "DV MECHANICAL ADJUSTMENT MANUAL
Z MECHANISM " (EXCEPT J: 9-876-210-11) (J: 9-876-210-01).
• Reference number search on printed wiring boards is available.
On the VC-352 board
This service manual provides the information that is premised the circuit board replacement service and not intended repair
inside the VC-352 board.
Therefore, schematic diagram, printed wiring board, mounted parts location and electrical parts list of the VC-352 board are not
shown.
The following pages are not shown.
Schematic diagram ............................. Pages 4-23 to 4-64
Printed wiring board ............................ Pages 4-79 to 4-82
Photo : DCR-PC109
BLOCK DIAGRAMS
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
Mounted parts location ............................. Pages 4-87 to 4-88
Electrical parts list ................................... Pages 5-17 to 5-25
DIGITAL VIDEO CAMERA RECORDER
RMT-831
LEVEL
DCR-PC109
Canadian Model
Japanese Model
DCR-PC109E
North European Model
Australian Model
Chinese Model
DCR-PC109/PC109E
Hong Kong Model
Tourist Model
Z MECHANISM (MDX-Z200)
PRINTED WIRING BOARDS
PRINTED WIRING BOARDS
REPAIR PARTS LIST
REPAIR PARTS LIST
2
US Model
Korea Model
AEP Model
UK Model
E Model
