Ranger 7600
DOWNLOADABLE CONTROL COMMUNICATOR
INSTALLATION MANUAL

TABLE OF CONTENTS

PAGE
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Standard And Optional Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Feature Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Terminal Drawing And Special Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Terminal Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
How To Program The Ranger 7600 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Keypad Programming Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Optional #8950 Programmer Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programming Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-28
Programming Worksheets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29-32
APPENDIX 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
APPENDIX 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Local Telephone Company Interface Information . . . . . . . . . . . . . . . . . 35
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
SPECIFICATIONS & WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
CADDX CONTROLS, INC.
GLADEWATER, TEXAS
800-727-2339

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RANGER 7600 and is the answer not in the manual?

Questions and answers

Related Manuals for CADDX RANGER 7600

Summary of Contents for CADDX RANGER 7600

  • Page 1 HOW TO PROGRAM THE RANGER 7600 ........

  • Page 2: Ranger

    See page 11 for a description of all zone types. Read the USER’S MANUAL before you begin the installation for the best overall description of how the Ranger 7600 functions. After installation of the security system, complete the information on page 1 of the user’s manual and explain the system operation to all security system owners/operators.

  • Page 3: Feature Definitions

    (Page 9). QUICK ARM FEATURE - The Ranger 7600 has a one button "Quick Arm" code which can be used to arm the system by pressing one digit at the keypad. (Page 17, Location 139.) SECONDARY EXIT DELAY - Used most often for garage doors, this zone type is a second entry/exit delay that has its own delay times, independent of the standard entry/exit delay zone.
  • Page 4 TERMINAL DRAWING & SPECIAL NOTES...

  • Page 5: Terminal Description

    TERMINAL DESCRIPTION DESCRIPTION Connect one side of zone 1 loop. The other side of loop to common terminal 3. Open or short causes alarm. Connect one side of zone 2 loop. The other side of loop to common terminal 3. Open or short causes alarm.
  • Page 6 PROGRAMMING The 7600 can be placed into the "Program" mode by use of the new 9075 Smart Programmer, or the original 8950 programmer, or for Keypad programming, by utilizing the 9050 LCD Keypad or the 8601 LED Keypad. These methods are described below. Using a Programmer Plug the optional 8950 Programmer into the 4-pin male outlet marked “PROGRAMMER”...

  • Page 8: Programming Instructions

    052. If this location contains a "0", the built-in communicator will be disabled, and the Ranger 7600 will function as a local only control.
  • Page 9 1800HZ TRANSMIT 2300HZ HANDSHAKE DOUBLE ROUND PARITY 40 PPS. "2" ADEMCO/SILENT KNIGHT FAST 1900HZ TRANSMIT 1400HZ HANDSHAKE DOUBLE ROUND PARITY 20 PPS. "3" CADDX MODEM PROPRIETARY "4" SESCOA / FRANKLIN FAST 1800HZ TRANSMIT 2300HZ 20PPS "5" EXTENDED RADIONICS SLOW 1800HZ TRANSMIT 2300HZ HANDSHAKE DOUBLE ROUND PARITY 20 PPS EXTENDED HEX CAPABILITY "6"...
  • Page 10 LOCATIONS 000-003: PROGRAMMING THE MASTER ARM/DISARM CODE Locations 000-003 contain master arm/disarm code (user number 1). Location 000 contains the first digit of the code; location 003 contains the fourth digit of the code. THE CODE MUST CONTAIN FOUR (4) DIGITS. The master code can then be used in the run mode to enter arm/disarm codes 1-7.

  • Page 11: Programming Worksheets

    PRIORITY - A short on a Priority zone (non-bypassable) will communicate to the central station when the Ranger 7600 is armed or disarmed. An open will create a Trouble condition. Keypad LED will be steady for FIRE, and flashing for Trouble. Only Zones 1-4 can be used as Priority.

  • Page 12: Appendix 1

    LOCATION 088-089: PROGRAMMING FOR AUXILIARY 1, [1] & [3] DOUBLE KEYPRESS The Ranger 7600 has the ability to report an Auxiliary 1 code and activate the Priority siren each time the [1] and [3] keys are pressed simultaneously on the keypad. The desired reporting code is programmed in locations 088-089.

  • Page 13: Appendix 2

    LOCATION 098-099: PROGRAMMING FOR AUTOTEST REPORTS The Ranger 7600 has the ability to send autotest reports at intervals from 1 to 15 days. Locations 098-099 contain the communicator codes sent for autotest. Location 098 contains the standard communicator code, and location 099 contains the extended code.
  • Page 14 LOCATION 116-117: PROGRAMMING TO REPORT START OF TEST MODE The Ranger 7600 has the ability to signal the central station that a test mode has begun. This test mode can be used to alert the central station not to dispatch alarms sent during the test. The test mode is entered by pressing[r]-[9]-[0]- [#] (followed by the master code).
  • Page 15 LOCATION 124: PROGRAMMING FOR PRIORITY ZONE TROUBLE REPORTING The Ranger 7600 has the ability to report a trouble code each time a Priority zone opens. The desired trouble code is programmed in location 124. If this location contains a "0", the Priority Trouble will not be reported. When Contact ID is selected, program the location with any number to activate this report.
  • Page 16 LOCATION 139: ENABLING QUICK ARM The Ranger 7600 can be programmed to "Quick Arm" with the 3 key by programming a "1" in location 139. A "0" in this location will disable this feature. If the "Quick Arm" digit is the same as the first digit of the "Go To Program...
  • Page 17 LOCATION 140: PRIORITY SIREN CUTOFF INHIBIT If a “1" is programmed in location 140, a Priority zone type siren will sound continuously until an arm/disarm code is entered. If this location contains a “0", the Priority zone type siren will shutdown after the amount of time programmed in location 077 has elapsed.

  • Page 18: Notes

    LOCATION 145-148: PROGRAMMING THE AUXILIARY OUTPUT The 7600 has one auxiliary output located on terminal 11 on the control PC board. This output can be activated by four different conditions selected from the 16 options in the following table. To utilize this output, program locations 145-148 with a number from "0"...
  • Page 19 LOCATION 151: PROGRAMMING THE NUMBER OF RINGS TO ANSWER DOWNLOAD CALL Location 151 contains the number of rings the 7600 must detect before answering the telephone when initiating a download. If a number from "1" to "15" is programmed in this location, the control will answer after THIS number of rings has been detected.
  • Page 20 LOCATION 160: PROGRAMMING THE CLOCK, CURRENT MINUTES - TENS DIGIT Location 160 contains the current minutes - tens digit. The time is entered in 24 hour time. If the current time is 5:25 PM, the 24 hour time is 17:25, so location 160 should contain a "2", which is the current minutes - tens digit. If the current time is 9:36 AM, the 24 hour time is 09:36, and this location should contain a "3".
  • Page 21 LOCATION 176: SPLIT REPORTING - PROGRAMMING TAMPER, DOWNLOAD COMPLETE, AND AUTOTEST TO REPORT TO THE SECONDARY PHONE NUMBER. The 7600 is capable sending certain reports to the secondary telephone number. This feature known as split reporting can be used to send alarm reports to one number and supervisory reports to another number. When using split reporting with the 7600, the primary telephone number always takes priority over the secondary telephone number.
  • Page 22 LOCATION 180: PROGRAMMING THE LOOP RESPONSE TIME Location 180 is used to program the loop response time for all zones programmed as fast loop response in locations 186-193. The response time is equal to 20 milliseconds times the number programmed in this location ("1" = 20 milliseconds and "5"...
  • Page 23 LOCATION 197: FORCE ARMING Programming a "1" in location 197 will allow the Ranger 7600 to be armed without all zones secure (no "Ready" LED illuminated). At the end of the exit delay, unsecured zones will automatically bypass, while zones that secure will become armed.
  • Page 24 LOCATION 204: DUAL REPORTING - PROGRAMMING TAMPER, DOWNLOAD COMPLETE, AND AUTOTEST TO REPORT TO THE BOTH PHONE NUMBERS The 7600 is capable of sending certain reports to both the primary and secondary phone numbers. When using dual reporting, the primary phone number always takes priority over the secondary number. There are 6 reports that can be individually programmed to report to both phone numbers.
  • Page 25 LOCATION 210: PROGRAMMING TO REPORT EXIT ERROR The Ranger 7600 has the ability to report an exit error code if an entry/exit zone is violated at the moment the exit delay expires. The desired exit error code is programmed in location 210. If this location contains a "0", exit errors will not be reported.
  • Page 26 LOCATIONS 212-239: PROGRAMMING THE ARM/DISARM CODES FOR USERS 8-14 Locations 212-239 contain the arm/disarm codes for user numbers 8-14. These codes can be accessed only in the program mode, or through downloading. LOCATION 240: ENTERING THE NUMBER OF DIAL ATTEMPTS TO SECONDARY PHONE NUMBER Location 240 is used to enter the number of dial attempts (1 to 15 attempts) the communicator will try to the second phone number before ending the notification process.
  • Page 27 LOCATION 252-253: PROGRAMMING REPORT KEYPAD AUXILIARY 3 The Ranger 7600 has the ability to report a Silent Auxiliary 3 code each time the [7] and [9] keys are pressed simultaneously on the keypad. The desired Auxiliary 3 code is programmed in locations 252-253. If both locations are "0", the Auxiliary 3 double keypress is disabled.
  • Page 28 Locations 256-263 contain the eight digit access code the 7600 must receive from the downloading software before the panel will permit downloading to occur. The factory default code is listed in the instructions provided with the CADDX download software package. LOCATIONS 264-279: CALL BACK TELEPHONE NUMBER The presence of a phone number in locations 264-279 will cause the control panel to dial back this number after a successful panel access code has been entered.
  • Page 29 ARM/DISARM CODES 1-7 LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 DEFAULT USER #1 ARM / DISARM CODE "1-2-3-4" 000-003 USER #2 ARM / DISARM CODE "15" DISABLED 004-007 008-011 USER #3 ARM / DISARM CODE "15" DISABLED 012-015 USER #4 ARM / DISARM CODE "15"...
  • Page 30 LOCATION PAGE DESCRIPTION ZONE ID EVENT/EXT CODE DEFAULT CLOSING COMMUNICATOR CODE MAN NUMBER "0" DISABLED OPENING COMMUNICATOR CODE MAN NUMBER "0" DISABLED ZONE 1 COMMUNICATOR CODE "1 - 0" 104-105 106-107 ZONE 2 COMMUNICATOR CODE "2 - 0" 108-109 ZONE 3 COMMUNICATOR CODE "3 - 0"...
  • Page 31 LOCATION PAGE DESCRIPTION DATA DEFAULT PROGRAM CLOCK, CURRENT MONTH UNDEFINED UNDEFINED PROGRAM CLOCK, CURRENT YEAR - TENS DIGIT (19 UNDEFINED PROGRAM CLOCK, CURRENT YEAR - ONES DIGIT (199 PROGRAM CLOCK, CURRENT DAY OF MONTH - TENS DIGIT UNDEFINED PROGRAM CLOCK, CURRENT DAY OF MONTH - ONES DIGIT UNDEFINED PROGRAM CLOCK, CURRENT HOUR - TENS DIGIT UNDEFINED...
  • Page 32 LOCATION PAGE DESCRIPTION DATA DEFAULT EXIT ERROR COMMUNICATOR CODE "0" RECENT CLOSING COMMUNICATOR CODE "0" USER #8 ARM / DISARM CODE "15" DISABLED 212-215 216-219 USER #9 ARM / DISARM CODE "15" DISABLED 220-223 USER #10 ARM / DISARM CODE "15"...
  • Page 33 APPENDIX 1 - REPORTING IN SIA FORMAT The 7600 has the ability to report SIA level 1 transmissions to either or both phone numbers. Each report in SIA consists of an Event Code and a Zone or User ID. The Zone is programmed in the first digit of each report. When programming the event code (the second digit) for zones 1-6 (locations 105, 107, 109, 111, 113, or 115), programming a zero will cause the event code to follow the zone type for that zone.
  • Page 34 APPENDIX 2 - REPORTING IN CONTACT ID The 7600 has the ability to report Ademco Contact ID transmissions to either or both phone numbers. Each report in Contact ID consists of an Event Code and a Zone or User ID. The Zone is programmed in the first digit of each report.
  • Page 35 If the problem is with the device the customer shall discontinue use until it is repaired. EQUIPMENT INFORMATION MANUFACTURER OF CONNECTING EQUIPMENT: CADDX CONTROLS, INC. FCC REGISTRATION NUMBER: GCQ4DC-17266-AL-E, RINGER EQUIVALENCE: 0.0 B...
  • Page 36 NOTES...
  • Page 37 INSIDE BACK COVER IS BLANK...
  • Page 38 PARTS AND WORKMANSHIP FOR TWENTY-FOUR (24) MONTHS FROM DATE OF MANUFACTURING. IF ANY DEFECT APPEARS DURING THE WARRANTY PERIOD RETURN IT TO CADDX, POSTAGE PREPAID. THE UNIT WILL BE REPAIRED AND RETURNED. FOR THE REMAINING 36 MONTHS OF WARRANTY, THE UNIT WILL BE REPAIRED FOR A FEE NOT TO EXCEED $10.00 PLUS SHIPPING AND HANDLING.
